Graphics Namespace Reference

Namespaces
	Aurora
	Mesh
	Render
	Shader

Classes
class	CameraManager
class	CBGT
	Loader for CBGT, BioWare's Compressed BackGround Tiles, an image format found in Sonic, used as area background images. More...
struct	ColorPosition
class	CubeMapCombiner
class	Cursor
	An abstract cursor. More...
class	DDS
	DDS texture. More...
struct	DXT1Texel
struct	DXT23Texel
struct	DXT45Texel
class	Font
	An abstract font. More...
class	FPSCounter
	A class counting frames per second. More...
class	GLContainer
	A container of OpenGL elements. More...
class	GraphicsManager
	The graphics manager. More...
class	GUIElement
	An element of the GUI. More...
class	ImageDecoder
	A generic interface for image decoders. More...
class	IndexBuffer
	Buffer containing indices data. More...
class	NBFS
class	NCGR
	Image decoder for Nintendo's tile-based graphics format. More...
class	NCLR
	Simple utility class to load NCLR palette files. More...
class	Object
	A renderable game object. More...
class	Queueable
class	QueueManager
	The graphics queue manager. More...
class	Renderable
	An object that can be displayed by the graphics manager. More...
struct	Resolution
class	SBM
	SBM font bitmap data. More...
class	Surface
class	Texture
	A texture. More...
class	TGA
	TarGa image. More...
class	TPC
	BioWare's own texture format, TPC. More...
class	TTFRenderer
class	TXB
	Another one of BioWare's own texture formats, TXB. More...
class	TXI
	Texture information. More...
struct	VertexAttrib
	Generic vertex attribute data. More...
class	VertexBuffer
	Buffer containing vertex data. More...
class	WindowManager
	The graphics manager. More...
class	WinIconImage
	Windows cursor. More...
class	XEOSITEX
class	YUVToRGBLookup
class	YUVToRGBManager

Typedefs
typedef GLuint	TextureID
typedef GLuint	ListID
typedef std::vector< ColorPosition >	ColorPositions
typedef std::vector< VertexAttrib >	VertexDecl
	Vertex data layout. More...
typedef SDL_DisplayMode	DisplayMode

Enumerations
enum	TXICommand {   TXICommandAlphaMean = 0, TXICommandArturoHeight = 1, TXICommandArturoWidth = 2, TXICommandBaselineHeight = 3,   TXICommandBlending = 4, TXICommandBumpMapScaling = 5, TXICommandBumpMapTexture = 6, TXICommandBumpyShinyTexture = 7,   TXICommandCanDownsample = 8, TXICommandCaretIndent = 9, TXICommandChannelScale = 10, TXICommandChannelTranslate = 11,   TXICommandClamp = 12, TXICommandCodepage = 13, TXICommandCols = 14, TXICommandCompressTexture = 15,   TXICommandControllerScript = 16, TXICommandCube = 17, TXICommandDBMapping = 18, TXICommandDecal = 19,   TXICommandDefaultBPP = 20, TXICommandDefaultHeight = 21, TXICommandDefaultWidth = 22, TXICommandDistort = 23,   TXICommandDistortAngle = 24, TXICommandDistortionAmplitude = 25, TXICommandDownsampleFactor = 26, TXICommandDownsampleMax = 27,   TXICommandDownsampleMin = 28, TXICommandEnvMapTexture = 29, TXICommandFileRange = 30, TXICommandFilter = 31,   TXICommandFontHeight = 32, TXICommandFontWidth = 33, TXICommandFPS = 34, TXICommandIsBumpMap = 35,   TXICommandIsDoubleByte = 36, TXICommandIsLightMap = 37, TXICommandLowerRightCoords = 38, TXICommandMaxSizeHQ = 39,   TXICommandMaxSizeLQ = 40, TXICommandMinSizeHQ = 41, TXICommandMinSizeLQ = 42, TXICommandMipMap = 43,   TXICommandNumChars = 44, TXICommandNumCharsPerSheet = 45, TXICommandNumX = 46, TXICommandNumY = 47,   TXICommandOnDemand = 48, TXICommandPriority = 49, TXICommandProcedureType = 50, TXICommandRows = 51,   TXICommandSpacingB = 52, TXICommandSpacingR = 53, TXICommandSpeed = 54, TXICommandTemporary = 55,   TXICommandTextureWidth = 56, TXICommandUnique = 57, TXICommandUpperLeftCoords = 58, TXICommandWaterHeight = 59,   TXICommandWaterWidth = 60, TXICommandXBoxDownsample = 61, TXICommandMAX }
	All supported commands in a TXI. More...
enum	PixelFormat { kPixelFormatRGB = GL_RGB, kPixelFormatRGBA = GL_RGBA, kPixelFormatBGR = GL_BGR, kPixelFormatBGRA = GL_BGRA }
enum	PixelFormatRaw {   kPixelFormatRGBA8 = GL_RGBA8, kPixelFormatRGB8 = GL_RGB8, kPixelFormatRGB5A1 = GL_RGB5_A1, kPixelFormatRGB5 = GL_RGB5,   kPixelFormatDXT1 = GL_COMPRESSED_RGB_S3TC_DXT1_EXT, kPixelFormatDXT3 = GL_COMPRESSED_RGBA_S3TC_DXT3_EXT, kPixelFormatDXT5 = GL_COMPRESSED_RGBA_S3TC_DXT5_EXT }
enum	PixelDataType { kPixelDataType8 = GL_UNSIGNED_BYTE, kPixelDataType1555 = GL_UNSIGNED_SHORT_1_5_5_5_REV, kPixelDataType565 = GL_UNSIGNED_SHORT_5_6_5 }
enum	QueueType {   kQueueTexture = 0, kQueueNewTexture, kQueueWorldObject, kQueueVisibleWorldObject,   kQueueGUIFrontObject, kQueueGUIBackObject, kQueueGUIConsoleObject, kQueueVisibleGUIFrontObject,   kQueueVisibleGUIBackObject, kQueueVisibleGUIConsoleObject, kQueueVideo, kQueueVisibleVideo,   kQueueGLContainer, kQueueNewShader, kQueueMAX }
enum	RenderableType {   kRenderableTypeVideo = 0, kRenderableTypeObject, kRenderableTypeGUIFront, kRenderableTypeGUIBack,   kRenderableTypeConsole }
enum	RenderPass { kRenderPassOpaque = 0, kRenderPassTransparent = 1, kRenderPassAll = 2 }
enum	VertexAttribIdEnum { VPOSITION = 0, VNORMAL, VCOLOR, VTCOORD }
	Vertex attribute data index enum, hardcoded for now. More...

Functions
static void	outputGLDebug (GLenum source, GLenum type, GLuint id, GLenum severity, GLsizei length, const GLchar *message, const void *userParam)
static SDL_Surface *	createStaticIconSurface ()
static void	setStaticIcon (SDL_Window &window)
void	setWindowIcon (SDL_Window &window)
static void	writePixel (Common::WriteStream &file, const byte *&data, PixelFormat format)
static Common::WriteStream *	openTGA (const Common::UString &fileName, int width, int height)
static void	writeMipMap (Common::WriteStream &stream, const ImageDecoder::MipMap &mipMap, PixelFormat format)
void	dumpTGA (const Common::UString &fileName, const ImageDecoder *image)
	Dump image into a TGA file. More...
static uint32	convert565To8888 (uint16 color)
static uint32	interpolate32 (double weight, uint32 color_0, uint32 color_1)
void	decompressDXT1 (byte *dest, Common::SeekableReadStream &src, uint32 width, uint32 height, uint32 pitch)
void	decompressDXT3 (byte *dest, Common::SeekableReadStream &src, uint32 width, uint32 height, uint32 pitch)
static uint64	readUint48LE (Common::SeekableReadStream &src)
void	decompressDXT5 (byte *dest, Common::SeekableReadStream &src, uint32 width, uint32 height, uint32 pitch)
bool	constructFilename (Common::UString &filename)
static bool	writeBMP (const Common::UString &filename, const byte *data, int width, int height)
bool	takeScreenshot ()
	Saves a screenshot to a file. More...
static uint32	getTXBDataSize (byte encoding, PixelFormatRaw format, int32 width, int32 height)
TXICommand	parseTXICommand (const Common::UString &str, Common::UString &args)
	Parse a TXI command from a string. More...
static uint32	getDataSize (PixelFormatRaw format, int32 width, int32 height)
	Return the number of bytes necessary to hold an image of these dimensions and in this format. More...
static bool	hasValidDimensions (PixelFormatRaw format, int32 width, int32 height)
	Are these image dimensions valid for this format? More...
static void	flipHorizontally (byte *data, int width, int height, int bpp)
	Flip an image horizontally. More...
static void	flipVertically (byte *data, int width, int height, int bpp)
	Flip an image vertically. More...
static void	rotate90 (byte *data, int width, int height, int bpp, int steps)
	Rotate a square image in 90° steps, clock-wise. More...
static uint32	deSwizzleOffset (uint32 x, uint32 y, uint32 width, uint32 height)
	De-"swizzle" a texture pixel offset. More...
static bool	queueComp (Queueable *a, Queueable *b)

Variables
PFNGLCOMPRESSEDTEXIMAGE2DPROC	glCompressedTexImage2D
static const byte	kStaticIcon [32 *32 *4]
	Static version of the xoreos icon. More...
static const Resolution	kResolutions []

Typedef Documentation

ColorPositions

typedef std::vector<ColorPosition> Graphics::ColorPositions

Definition at line 114 of file types.h.

DisplayMode

typedef SDL_DisplayMode Graphics::DisplayMode

Definition at line 36 of file windowman.h.

ListID

typedef GLuint Graphics::ListID

Definition at line 46 of file types.h.

TextureID

typedef GLuint Graphics::TextureID

Definition at line 45 of file types.h.

VertexDecl

typedef std::vector<VertexAttrib> Graphics::VertexDecl

Vertex data layout.

Definition at line 63 of file vertexbuffer.h.

Enumeration Type Documentation

PixelDataType

enum Graphics::PixelDataType

Enumerator
kPixelDataType8
kPixelDataType1555
kPixelDataType565

Definition at line 65 of file types.h.

PixelFormat

enum Graphics::PixelFormat

Enumerator
kPixelFormatRGB
kPixelFormatRGBA
kPixelFormatBGR
kPixelFormatBGRA

Definition at line 48 of file types.h.

PixelFormatRaw

enum Graphics::PixelFormatRaw

Enumerator
kPixelFormatRGBA8
kPixelFormatRGB8
kPixelFormatRGB5A1
kPixelFormatRGB5
kPixelFormatDXT1
kPixelFormatDXT3
kPixelFormatDXT5

Definition at line 55 of file types.h.

QueueType

enum Graphics::QueueType

Enumerator
kQueueTexture	A texture.
kQueueNewTexture	A newly created texture.
kQueueWorldObject	An object in 3D space.
kQueueVisibleWorldObject	A visible object in 3D space.
kQueueGUIFrontObject	A GUI object, in front of the world objects.
kQueueGUIBackObject	A GUI object, behind the world objects.
kQueueGUIConsoleObject	A Debug Console object, in front of the Front GUI.
kQueueVisibleGUIFrontObject	A visible GUI object, in front of the world objects.
kQueueVisibleGUIBackObject	A visible GUI object, behind the world objects.
kQueueVisibleGUIConsoleObject	A visible Debug Console object, in front of the Front GUI.
kQueueVideo	A video.
kQueueVisibleVideo	A currently playing video.
kQueueGLContainer	An object containing OpenGL structures.
kQueueNewShader	An object containing shader information.
kQueueMAX	For range checks.

Definition at line 71 of file types.h.

RenderableType

enum Graphics::RenderableType

Enumerator
kRenderableTypeVideo
kRenderableTypeObject
kRenderableTypeGUIFront
kRenderableTypeGUIBack
kRenderableTypeConsole

Definition at line 89 of file types.h.

RenderPass

enum Graphics::RenderPass

Enumerator
kRenderPassOpaque	Only render opaque parts.
kRenderPassTransparent	Only render transparent parts.
kRenderPassAll	Render all parts.

Definition at line 97 of file types.h.

TXICommand

enum Graphics::TXICommand

All supported commands in a TXI.

Enumerator
TXICommandAlphaMean
TXICommandArturoHeight
TXICommandArturoWidth
TXICommandBaselineHeight
TXICommandBlending
TXICommandBumpMapScaling
TXICommandBumpMapTexture
TXICommandBumpyShinyTexture
TXICommandCanDownsample
TXICommandCaretIndent
TXICommandChannelScale
TXICommandChannelTranslate
TXICommandClamp
TXICommandCodepage
TXICommandCols
TXICommandCompressTexture
TXICommandControllerScript
TXICommandCube
TXICommandDBMapping
TXICommandDecal
TXICommandDefaultBPP
TXICommandDefaultHeight
TXICommandDefaultWidth
TXICommandDistort
TXICommandDistortAngle
TXICommandDistortionAmplitude
TXICommandDownsampleFactor
TXICommandDownsampleMax
TXICommandDownsampleMin
TXICommandEnvMapTexture
TXICommandFileRange
TXICommandFilter
TXICommandFontHeight
TXICommandFontWidth
TXICommandFPS
TXICommandIsBumpMap
TXICommandIsDoubleByte
TXICommandIsLightMap
TXICommandLowerRightCoords
TXICommandMaxSizeHQ
TXICommandMaxSizeLQ
TXICommandMinSizeHQ
TXICommandMinSizeLQ
TXICommandMipMap
TXICommandNumChars
TXICommandNumCharsPerSheet
TXICommandNumX
TXICommandNumY
TXICommandOnDemand
TXICommandPriority
TXICommandProcedureType
TXICommandRows
TXICommandSpacingB
TXICommandSpacingR
TXICommandSpeed
TXICommandTemporary
TXICommandTextureWidth
TXICommandUnique
TXICommandUpperLeftCoords
TXICommandWaterHeight
TXICommandWaterWidth
TXICommandXBoxDownsample
TXICommandMAX

Definition at line 37 of file txitypes.h.

VertexAttribIdEnum

enum Graphics::VertexAttribIdEnum

Vertex attribute data index enum, hardcoded for now.

Enumerator
VPOSITION	Vertex position.
VNORMAL	Vertex normal.
VCOLOR	Vertex color.
VTCOORD	Vertex texture coordinates, VTCOORDi = VTCOORD + i.

Definition at line 35 of file vertexbuffer.h.

Function Documentation

constructFilename()

bool Graphics::constructFilename

(

Common::UString &

filename

)

Definition at line 38 of file screenshot.cpp.

References Common::DateTime::formatDateTimeISO(), Common::FilePath::getUserDataFile(), Common::FilePath::isRegularFile(), and Common::DateTime::kUTC.

Referenced by takeScreenshot().

Here is the call graph for this function:

Here is the caller graph for this function:

convert565To8888()

static uint32 Graphics::convert565To8888 ( uint16  color )

inlinestatic

Definition at line 32 of file s3tc.cpp.

Referenced by decompressDXT1(), decompressDXT3(), and decompressDXT5().

Here is the caller graph for this function:

createStaticIconSurface()

static SDL_Surface* Graphics::createStaticIconSurface ( )

static

Definition at line 301 of file icon.cpp.

References kStaticIcon.

Referenced by setStaticIcon().

Here is the caller graph for this function:

decompressDXT1()

void Graphics::decompressDXT1	(	byte *	dest,
		Common::SeekableReadStream &	src,
		uint32	width,
		uint32	height,
		uint32	pitch
	)

Definition at line 64 of file s3tc.cpp.

References Graphics::DXT1Texel::color_0, Graphics::DXT1Texel::color_1, convert565To8888(), interpolate32(), Graphics::DXT1Texel::pixels, and READ_DXT1_TEXEL.

Referenced by Graphics::ImageDecoder::decompress().

Here is the call graph for this function:

Here is the caller graph for this function:

decompressDXT3()

void Graphics::decompressDXT3	(	byte *	dest,
		Common::SeekableReadStream &	src,
		uint32	width,
		uint32	height,
		uint32	pitch
	)

Definition at line 114 of file s3tc.cpp.

References Graphics::DXT23Texel::alpha, Graphics::DXT1Texel::color_0, Graphics::DXT1Texel::color_1, convert565To8888(), interpolate32(), Graphics::DXT1Texel::pixels, and READ_DXT3_TEXEL.

Referenced by Graphics::ImageDecoder::decompress().

Here is the call graph for this function:

Here is the caller graph for this function:

decompressDXT5()

void Graphics::decompressDXT5	(	byte *	dest,
		Common::SeekableReadStream &	src,
		uint32	width,
		uint32	height,
		uint32	pitch
	)

Definition at line 165 of file s3tc.cpp.

References Graphics::DXT45Texel::alpha_0, Graphics::DXT45Texel::alpha_1, Graphics::DXT45Texel::alphabl, Graphics::DXT1Texel::color_0, Graphics::DXT1Texel::color_1, convert565To8888(), interpolate32(), Graphics::DXT1Texel::pixels, and READ_DXT5_TEXEL.

Referenced by Graphics::ImageDecoder::decompress().

Here is the call graph for this function:

Here is the caller graph for this function:

deSwizzleOffset()

static uint32 Graphics::deSwizzleOffset ( uint32  x, uint32  y, uint32  width, uint32  height  )

inlinestatic

De-"swizzle" a texture pixel offset.

Definition at line 179 of file util.h.

References Common::intLog2().

Referenced by Graphics::TXB::deSwizzle(), Graphics::TPC::deSwizzle(), and Graphics::SBM::readData().

Here is the call graph for this function:

Here is the caller graph for this function:

dumpTGA()

void Graphics::dumpTGA	(	const Common::UString &	fileName,
		const ImageDecoder *	image
	)

Dump image into a TGA file.

Definition at line 95 of file dumptga.cpp.

References Common::WriteStream::flush(), Graphics::ImageDecoder::getFormat(), Graphics::ImageDecoder::getLayerCount(), Graphics::ImageDecoder::getMipMap(), Graphics::ImageDecoder::getMipMapCount(), Graphics::ImageDecoder::MipMap::height, openTGA(), Graphics::ImageDecoder::MipMap::width, and writeMipMap().

Referenced by Graphics::ImageDecoder::dumpTGA().

Here is the call graph for this function:

Here is the caller graph for this function:

flipHorizontally()

static void Graphics::flipHorizontally ( byte *  data, int  width, int  height, int  bpp  )

inlinestatic

Flip an image horizontally.

Definition at line 95 of file util.h.

References Common::ScopedPtrBase< T, Deallocator >::get().

Here is the call graph for this function:

flipVertically()

static void Graphics::flipVertically ( byte *  data, int  width, int  height, int  bpp  )

inlinestatic

Flip an image vertically.

Definition at line 122 of file util.h.

Referenced by Graphics::TGA::readData().

Here is the caller graph for this function:

getDataSize()

static uint32 Graphics::getDataSize ( PixelFormatRaw  format, int32  width, int32  height  )

inlinestatic

Return the number of bytes necessary to hold an image of these dimensions and in this format.

Definition at line 43 of file util.h.

References kPixelFormatDXT1, kPixelFormatDXT3, kPixelFormatDXT5, kPixelFormatRGB5, kPixelFormatRGB5A1, kPixelFormatRGB8, and kPixelFormatRGBA8.

Referenced by getTXBDataSize(), Graphics::TPC::readHeader(), and Graphics::DDS::setSize().

Here is the caller graph for this function:

getTXBDataSize()

static uint32 Graphics::getTXBDataSize ( byte  encoding, PixelFormatRaw  format, int32  width, int32  height  )

static

Definition at line 66 of file txb.cpp.

References getDataSize(), kEncodingBGRA, kEncodingDXT1, kEncodingDXT5, and kEncodingGray.

Referenced by Graphics::TXB::readHeader().

Here is the call graph for this function:

Here is the caller graph for this function:

hasValidDimensions()

static bool Graphics::hasValidDimensions ( PixelFormatRaw  format, int32  width, int32  height  )

inlinestatic

Are these image dimensions valid for this format?

Definition at line 73 of file util.h.

References kPixelFormatDXT1, kPixelFormatDXT3, kPixelFormatDXT5, kPixelFormatRGB5, kPixelFormatRGB5A1, kPixelFormatRGB8, and kPixelFormatRGBA8.

Referenced by Graphics::ImageDecoder::decompress(), Graphics::DDS::readBioWareHeader(), Graphics::TPC::readHeader(), Graphics::TXB::readHeader(), and Graphics::DDS::readStandardHeader().

Here is the caller graph for this function:

interpolate32()

static uint32 Graphics::interpolate32 ( double  weight, uint32  color_0, uint32  color_1  )

inlinestatic

Definition at line 36 of file s3tc.cpp.

Referenced by decompressDXT1(), decompressDXT3(), and decompressDXT5().

Here is the caller graph for this function:

openTGA()

static Common::WriteStream* Graphics::openTGA ( const Common::UString &  fileName, int  width, int  height  )

static

Definition at line 66 of file dumptga.cpp.

References Common::WriteStream::writeByte(), Common::WriteStream::writeUint16LE(), and Common::WriteStream::writeUint32LE().

Referenced by dumpTGA().

Here is the call graph for this function:

Here is the caller graph for this function:

outputGLDebug()

static void Graphics::outputGLDebug ( GLenum  source, GLenum  type, GLuint  id, GLenum  severity, GLsizei  length, const GLchar *  message, const void *  userParam  )

static

Definition at line 267 of file graphics.cpp.

References ARRAYSIZE, DebugMan, Common::kDebugGL3rd, Common::kDebugGLAPI, Common::kDebugGLApp, Common::kDebugGLOther, Common::kDebugGLShader, Common::kDebugGLTypeDeprecated, Common::kDebugGLTypeError, Common::kDebugGLTypeOther, Common::kDebugGLTypePerformance, Common::kDebugGLTypePortability, Common::kDebugGLTypeUndefined, and Common::kDebugGLWindow.

Referenced by Graphics::GraphicsManager::checkGLExtensions().

Here is the caller graph for this function:

parseTXICommand()

TXICommand Graphics::parseTXICommand	(	const Common::UString &	str,
		Common::UString &	args
	)

Parse a TXI command from a string.

Definition at line 99 of file txitypes.cpp.

References Common::UString::c_str(), Common::StringListMap::find(), kTXICommandMap, and TXICommandMAX.

Referenced by Graphics::TXI::load().

Here is the call graph for this function:

Here is the caller graph for this function:

queueComp()

static bool Graphics::queueComp ( Queueable *  a, Queueable *  b  )

static

Definition at line 32 of file queueman.cpp.

Referenced by Graphics::QueueManager::sortQueue().

Here is the caller graph for this function:

readUint48LE()

static uint64 Graphics::readUint48LE ( Common::SeekableReadStream &  src )

static

Definition at line 154 of file s3tc.cpp.

References Common::ReadStream::readUint16LE(), and Common::ReadStream::readUint32LE().

Here is the call graph for this function:

rotate90()

static void Graphics::rotate90 ( byte *  data, int  width, int  height, int  bpp, int  steps  )

inlinestatic

Rotate a square image in 90° steps, clock-wise.

Definition at line 145 of file util.h.

Referenced by Graphics::TPC::fixupCubeMap().

Here is the caller graph for this function:

setStaticIcon()

static void Graphics::setStaticIcon ( SDL_Window &  window )

static

Definition at line 322 of file icon.cpp.

References createStaticIconSurface().

Referenced by setWindowIcon().

Here is the call graph for this function:

Here is the caller graph for this function:

setWindowIcon()

void Graphics::setWindowIcon

(

SDL_Window &

window

)

Definition at line 350 of file icon.cpp.

References setStaticIcon().

Referenced by Graphics::WindowManager::initWindow().

Here is the call graph for this function:

Here is the caller graph for this function:

takeScreenshot()

bool Graphics::takeScreenshot

(

)

Saves a screenshot to a file.

Warning: Unsafe outside the main thread.

Definition at line 110 of file screenshot.cpp.

References Common::UString::c_str(), constructFilename(), Common::enforceMainThread(), Common::ScopedPtrBase< T, Deallocator >::get(), status(), warning(), and writeBMP().

Referenced by Graphics::GraphicsManager::endScene().

Here is the call graph for this function:

Here is the caller graph for this function:

writeBMP()

static bool Graphics::writeBMP ( const Common::UString &  filename, const byte *  data, int  width, int  height  )

static

Definition at line 53 of file screenshot.cpp.

References Common::WriteFile::close(), Common::WriteFile::flush(), Common::WriteFile::open(), Common::WriteFile::write(), Common::WriteStream::writeByte(), Common::WriteStream::writeUint16LE(), and Common::WriteStream::writeUint32LE().

Referenced by takeScreenshot().

Here is the call graph for this function:

Here is the caller graph for this function:

writeMipMap()

static void Graphics::writeMipMap ( Common::WriteStream &  stream, const ImageDecoder::MipMap &  mipMap, PixelFormat  format  )

static

Definition at line 87 of file dumptga.cpp.

References Graphics::ImageDecoder::MipMap::data, Common::ScopedPtrBase< T, Deallocator >::get(), Graphics::ImageDecoder::MipMap::height, Graphics::ImageDecoder::MipMap::width, and writePixel().

Referenced by dumpTGA().

Here is the call graph for this function:

Here is the caller graph for this function:

writePixel()

static void Graphics::writePixel ( Common::WriteStream &  file, const byte *&  data, PixelFormat  format  )

static

Definition at line 36 of file dumptga.cpp.

References kPixelFormatBGR, kPixelFormatBGRA, kPixelFormatRGB, kPixelFormatRGBA, and Common::WriteStream::writeByte().

Referenced by writeMipMap().

Here is the call graph for this function:

Here is the caller graph for this function:

Variable Documentation

glCompressedTexImage2D

PFNGLCOMPRESSEDTEXIMAGE2DPROC Graphics::glCompressedTexImage2D

Definition at line 71 of file graphics.cpp.

Referenced by Graphics::GraphicsManager::checkGLExtensions(), Graphics::GraphicsManager::GraphicsManager(), and Graphics::Aurora::Texture::setMipMapData().

kResolutions

const Resolution Graphics::kResolutions[]

static

Definition at line 35 of file resolution.h.

Referenced by Engines::NWN::OptionsResolutionMenu::initResolutionsBox(), Engines::Jade::GUIBackground::update(), and Engines::KotOR::GUIBackground::update().

kStaticIcon

const byte Graphics::kStaticIcon[32 *32 *4]

static

Static version of the xoreos icon.

Definition at line 42 of file icon.cpp.

Referenced by createStaticIconSurface().
