Image decoder for Nintendo's tile-based graphics format. More...

#include <ncgr.h>

Inheritance diagram for Graphics::NCGR:

Collaboration diagram for Graphics::NCGR:

[legend]

Classes
struct	NCGRFile

struct	ReadContext

Public Member Functions
	NCGR (Common::SeekableReadStream &ncgr, Common::SeekableReadStream &nclr)

	NCGR (const std::vector< Common::SeekableReadStream *> &ncgrs, uint32 width, uint32 height, Common::SeekableReadStream &nclr)

	~NCGR ()

Public Member Functions inherited from Graphics::ImageDecoder
	ImageDecoder ()

	ImageDecoder (const ImageDecoder &image)

virtual	~ImageDecoder ()

ImageDecoder &	operator= (const ImageDecoder &image)

bool	isCompressed () const
	Is the image data compressed? More...

bool	hasAlpha () const
	Does the image data have alpha? . More...

PixelFormat	getFormat () const
	Return the image data's general format. More...

PixelFormatRaw	getFormatRaw () const
	Return the image data's raw format. More...

PixelDataType	getDataType () const
	Return the image data pixel's type. More...

size_t	getMipMapCount () const
	Return the number of mip maps contained in the image. More...

size_t	getLayerCount () const
	Return the number of layers contained in the image. More...

bool	isCubeMap () const
	Is this image a cube map? More...

const MipMap &	getMipMap (size_t mipMap, size_t layer=0) const
	Return a mip map. More...

void	decompress ()
	Manually decompress the texture image data. More...

const TXI &	getTXI () const
	Return the texture information TXI, which may be embedded in the image. More...

bool	dumpTGA (const Common::UString &fileName) const
	Dump the image into a TGA. More...

Private Member Functions
void	load (const std::vector< Common::SeekableReadStream *> &ncgrs, uint32 width, uint32 height, Common::SeekableReadStream &nclr)

void	load (NCGRFile &ctx)

void	readHeader (NCGRFile &ctx)

void	readChar (NCGRFile &ctx)

void	calculateGrid (ReadContext &ctx, uint32 &imageWidth, uint32 &imageHeight)

void	draw (ReadContext &ctx)

Additional Inherited Members
Protected Types inherited from Graphics::ImageDecoder
typedef Common::PtrVector< MipMap >	MipMaps

Static Protected Member Functions inherited from Graphics::ImageDecoder
static void	decompress (MipMap &out, const MipMap &in, PixelFormatRaw format)

Static Protected Member Functions inherited from Aurora::NitroFile
static Common::SeekableSubReadStreamEndian *	open (Common::SeekableReadStream &stream)
	Treat this stream as a Nitro file and return an endian'd stream according to its BOM. More...

static Common::SeekableSubReadStreamEndian *	open (Common::SeekableReadStream *stream)
	Treat this stream as a Nitro file, take it over and return an endian'd stream according to its BOM. More...

Protected Attributes inherited from Graphics::ImageDecoder
bool	_compressed

bool	_hasAlpha

PixelFormat	_format

PixelFormatRaw	_formatRaw

PixelDataType	_dataType

size_t	_layerCount
	Number of layers in this image. More...

bool	_isCubeMap
	Is this image a cube map? A cube map always needs to have 6 layers! More...

MipMaps	_mipMaps

TXI	_txi

Detailed Description

Image decoder for Nintendo's tile-based graphics format.

2D graphics on the Nintendo DS is fundamentally tile-based. Specifically, the graphics data in NCGR is ordered in tiles of 8x8 pixels. We unwrap them, so this is transparent to the user of the NCGR class.

Moreover, an NCGR file can itself be a tile of a larger image. By specifying a vector of NCGR streams and the dimensions of the grid they span (in NCGR files, not pixels), the NCGR class can automatically stitch them together into a single big image.

If a pointer in the NCGR stream vector is 0, the cell in the grid will stay empty, filled with entry 0 of the palette.

Please note that, in accordance with other image decoder classes, NCGR will never take over any of the streams. The caller has to manage stream deletion itself.

Definition at line 58 of file ncgr.h.
