TarGa image. More...
#include <tga.h>
Public Member Functions | |
| TGA (Common::SeekableReadStream &tga, bool cubeMap=false) | |
| ~TGA () | |
 Public Member Functions inherited from Graphics::ImageDecoder | |
| ImageDecoder () | |
| ImageDecoder (const ImageDecoder &image) | |
| virtual | ~ImageDecoder () |
| ImageDecoder & | operator= (const ImageDecoder &image) |
| bool | isCompressed () const |
| Is the image data compressed? More... | |
| bool | hasAlpha () const |
| Does the image data have alpha? . More... | |
| PixelFormat | getFormat () const |
| Return the image data's general format. More... | |
| PixelFormatRaw | getFormatRaw () const |
| Return the image data's raw format. More... | |
| PixelDataType | getDataType () const |
| Return the image data pixel's type. More... | |
| size_t | getMipMapCount () const |
| Return the number of mip maps contained in the image. More... | |
| size_t | getLayerCount () const |
| Return the number of layers contained in the image. More... | |
| bool | isCubeMap () const |
| Is this image a cube map? More... | |
| const MipMap & | getMipMap (size_t mipMap, size_t layer=0) const |
| Return a mip map. More... | |
| void | decompress () |
| Manually decompress the texture image data. More... | |
| const TXI & | getTXI () const |
| Return the texture information TXI, which may be embedded in the image. More... | |
| bool | dumpTGA (const Common::UString &fileName) const |
| Dump the image into a TGA. More... | |
Private Types | |
| enum | ImageType { kImageTypeCMap = 1, kImageTypeTrueColor = 2, kImageTypeBW = 3, kImageTypeRLECMap = 9, kImageTypeRLETrueColor = 10, kImageTypeRLEBW = 11 } |
Private Member Functions | |
| void | load (Common::SeekableReadStream &tga) |
| void | readHeader (Common::SeekableReadStream &tga, ImageType &imageType, byte &pixelDepth, byte &imageDesc) |
| void | readData (Common::SeekableReadStream &tga, ImageType imageType, byte pixelDepth, byte imageDesc) |
| void | readRLE (Common::SeekableReadStream &tga, byte pixelDepth, size_t layer) |
| bool | isSupportedImageType (ImageType type) const |
Additional Inherited Members | |
| Protected Types inherited from Graphics::ImageDecoder | |
| typedef Common::PtrVector< MipMap > | MipMaps |
| Static Protected Member Functions inherited from Graphics::ImageDecoder | |
| static void | decompress (MipMap &out, const MipMap &in, PixelFormatRaw format) |
| Protected Attributes inherited from Graphics::ImageDecoder | |
| bool | _compressed |
| bool | _hasAlpha |
| PixelFormat | _format |
| PixelFormatRaw | _formatRaw |
| PixelDataType | _dataType |
| size_t | _layerCount |
| Number of layers in this image. More... | |
| bool | _isCubeMap |
| Is this image a cube map? A cube map always needs to have 6 layers! More... | |
| MipMaps | _mipMaps |
| TXI | _txi |
Detailed Description
TarGa image.
This format is used in the two Neverwinter Nights games, the two Knights of the Old Republic games, Jade Empire and Sonic.
Member Enumeration Documentation
◆ ImageType
|
private |
Constructor & Destructor Documentation
◆ TGA()
| Graphics::TGA::TGA | ( | Common::SeekableReadStream & | tga, |
| bool | cubeMap = false |
||
| ) |
Definition at line 61 of file tga.cpp.
References Graphics::ImageDecoder::_compressed, Graphics::ImageDecoder::_isCubeMap, Graphics::ImageDecoder::_layerCount, and load().
◆ ~TGA()
Member Function Documentation
◆ isSupportedImageType()
|
private |
Definition at line 287 of file tga.cpp.
References kImageTypeBW, kImageTypeRLETrueColor, and kImageTypeTrueColor.
Referenced by readHeader().
◆ load()
|
private |
Definition at line 75 of file tga.cpp.
References Common::StackException::add(), readData(), and readHeader().
Referenced by TGA().
◆ readData()
|
private |
Definition at line 179 of file tga.cpp.
References Graphics::ImageDecoder::_format, Graphics::ImageDecoder::_layerCount, Graphics::ImageDecoder::_mipMaps, Graphics::flipVertically(), kImageTypeBW, kImageTypeRLETrueColor, kImageTypeTrueColor, Graphics::kPixelFormatBGR, Graphics::kPixelFormatBGRA, Common::ReadStream::read(), Common::ReadStream::readByte(), readRLE(), and Common::ReadStream::readUint16LE().
Referenced by load().
◆ readHeader()
|
private |
Definition at line 89 of file tga.cpp.
References Graphics::ImageDecoder::_dataType, Graphics::ImageDecoder::_format, Graphics::ImageDecoder::_formatRaw, Graphics::ImageDecoder::_hasAlpha, Graphics::ImageDecoder::_layerCount, Graphics::ImageDecoder::_mipMaps, isSupportedImageType(), kImageTypeBW, kImageTypeRLEBW, kImageTypeRLECMap, kImageTypeRLETrueColor, kImageTypeTrueColor, Graphics::kPixelDataType8, Graphics::kPixelFormatBGR, Graphics::kPixelFormatBGRA, Graphics::kPixelFormatRGB8, Graphics::kPixelFormatRGBA8, Common::ReadStream::readByte(), Common::ReadStream::readUint16LE(), Common::PtrVector< T, Deallocator >::resize(), Common::SeekableReadStream::seek(), and Common::SeekableReadStream::skip().
Referenced by load().
◆ readRLE()
|
private |
Definition at line 238 of file tga.cpp.
References Graphics::ImageDecoder::_mipMaps, Common::ReadStream::readByte(), and Common::ReadStream::readUint32BE().
Referenced by readData().
The documentation for this class was generated from the following files:
