Graphics::Surface Class Reference

#include <surface.h>

Inheritance diagram for Graphics::Surface:

Collaboration diagram for Graphics::Surface:

Public Member Functions
	Surface (int width, int height)
	~Surface ()
int	getWidth () const
int	getHeight () const
int	getPitch () const
byte *	getData ()
const byte *	getData () const
void	fill (byte r, byte g, byte b, byte a)
const MipMap &	getMipMap (size_t mipMap) const
	Return a mip map. More...
const MipMap &	getMipMap () const
	Return a mip map. More...
MipMap &	getMipMap ()
	Return a mip map. More...
Public Member Functions inherited from Graphics::ImageDecoder
	ImageDecoder ()
	ImageDecoder (const ImageDecoder &image)
virtual	~ImageDecoder ()
ImageDecoder &	operator= (const ImageDecoder &image)
bool	isCompressed () const
	Is the image data compressed? More...
bool	hasAlpha () const
	Does the image data have alpha? . More...
PixelFormat	getFormat () const
	Return the image data's general format. More...
PixelFormatRaw	getFormatRaw () const
	Return the image data's raw format. More...
PixelDataType	getDataType () const
	Return the image data pixel's type. More...
size_t	getMipMapCount () const
	Return the number of mip maps contained in the image. More...
size_t	getLayerCount () const
	Return the number of layers contained in the image. More...
bool	isCubeMap () const
	Is this image a cube map? More...
const MipMap &	getMipMap (size_t mipMap, size_t layer=0) const
	Return a mip map. More...
void	decompress ()
	Manually decompress the texture image data. More...
const TXI &	getTXI () const
	Return the texture information TXI, which may be embedded in the image. More...
bool	dumpTGA (const Common::UString &fileName) const
	Dump the image into a TGA. More...

Additional Inherited Members
Protected Types inherited from Graphics::ImageDecoder
typedef Common::PtrVector< MipMap >	MipMaps
Static Protected Member Functions inherited from Graphics::ImageDecoder
static void	decompress (MipMap &out, const MipMap &in, PixelFormatRaw format)
Protected Attributes inherited from Graphics::ImageDecoder
bool	_compressed
bool	_hasAlpha
PixelFormat	_format
PixelFormatRaw	_formatRaw
PixelDataType	_dataType
size_t	_layerCount
	Number of layers in this image. More...
bool	_isCubeMap
	Is this image a cube map? A cube map always needs to have 6 layers! More...
MipMaps	_mipMaps
TXI	_txi

Detailed Description

Definition at line 32 of file surface.h.

Constructor & Destructor Documentation

Surface()

Graphics::Surface::Surface	(	int	width,
		int	height
	)

Definition at line 32 of file surface.cpp.

References Graphics::ImageDecoder::_compressed, Graphics::ImageDecoder::_dataType, Graphics::ImageDecoder::_format, Graphics::ImageDecoder::_formatRaw, Graphics::ImageDecoder::_hasAlpha, Graphics::ImageDecoder::_mipMaps, Graphics::kPixelDataType8, Graphics::kPixelFormatBGRA, and Graphics::kPixelFormatRGBA8.

~Surface()

Graphics::Surface::~Surface

(

)

Definition at line 50 of file surface.cpp.

Member Function Documentation

fill()

void Graphics::Surface::fill	(	byte	r,
		byte	g,
		byte	b,
		byte	a
	)

Definition at line 69 of file surface.cpp.

References Graphics::ImageDecoder::_mipMaps.

Referenced by Graphics::Aurora::PLTFile::load(), and Graphics::Aurora::TTFFont::Page::Page().

Here is the caller graph for this function:

getData() [1/2]

byte * Graphics::Surface::getData

(

)

Definition at line 61 of file surface.cpp.

References Graphics::ImageDecoder::_mipMaps.

Referenced by Graphics::Aurora::PLTFile::build(), Video::VPXDecoder::decodeFrame(), Video::XMVWMV2Codec::decodeFrame(), Video::Bink::BinkVideoTrack::decodePacket(), Graphics::TTFRenderer::drawCharacter(), Video::Fader::FaderVideoTrack::drawFrame(), and Graphics::Aurora::NFTRFont::drawGlyph().

Here is the caller graph for this function:

getData() [2/2]

const byte * Graphics::Surface::getData

(

)

const

Definition at line 65 of file surface.cpp.

References Graphics::ImageDecoder::_mipMaps.

getHeight()

int Graphics::Surface::getHeight

(

)

const

Definition at line 57 of file surface.cpp.

References Graphics::ImageDecoder::_mipMaps.

Referenced by Video::VPXDecoder::decodeFrame(), and Graphics::TTFRenderer::drawCharacter().

Here is the caller graph for this function:

getMipMap() [1/3]

const ImageDecoder::MipMap & Graphics::Surface::getMipMap

(

size_t

mipMap

)

const

Return a mip map.

Definition at line 85 of file surface.cpp.

References Graphics::ImageDecoder::getMipMap().

Referenced by Graphics::Aurora::ModelNode_NWN2::createTint().

Here is the call graph for this function:

Here is the caller graph for this function:

getMipMap() [2/3]

const ImageDecoder::MipMap & Graphics::Surface::getMipMap

(

)

const

Return a mip map.

Definition at line 89 of file surface.cpp.

References Graphics::ImageDecoder::_mipMaps.

getMipMap() [3/3]

ImageDecoder::MipMap & Graphics::Surface::getMipMap

(

)

Return a mip map.

Definition at line 93 of file surface.cpp.

References Graphics::ImageDecoder::_mipMaps.

getPitch()

int Graphics::Surface::getPitch ( ) const

inline

Definition at line 39 of file surface.h.

References getWidth().

Referenced by Video::VPXDecoder::decodeFrame().

Here is the call graph for this function:

Here is the caller graph for this function:

getWidth()

int Graphics::Surface::getWidth

(

)

const

Definition at line 53 of file surface.cpp.

References Graphics::ImageDecoder::_mipMaps.

Referenced by Video::XMVWMV2Codec::decodeFrame(), Video::Bink::BinkVideoTrack::decodePacket(), Graphics::TTFRenderer::drawCharacter(), Video::Fader::FaderVideoTrack::drawFrame(), Graphics::Aurora::NFTRFont::drawGlyph(), and getPitch().

Here is the caller graph for this function:

---

The documentation for this class was generated from the following files:

• src/graphics/images/surface.h
• src/graphics/images/surface.cpp
