Another one of BioWare's own texture formats, TXB. More...
#include <txb.h>
Public Member Functions | |
| TXB (Common::SeekableReadStream &txb) | |
| ~TXB () | |
 Public Member Functions inherited from Graphics::ImageDecoder | |
| ImageDecoder () | |
| ImageDecoder (const ImageDecoder &image) | |
| virtual | ~ImageDecoder () |
| ImageDecoder & | operator= (const ImageDecoder &image) |
| bool | isCompressed () const |
| Is the image data compressed? More... | |
| bool | hasAlpha () const |
| Does the image data have alpha? . More... | |
| PixelFormat | getFormat () const |
| Return the image data's general format. More... | |
| PixelFormatRaw | getFormatRaw () const |
| Return the image data's raw format. More... | |
| PixelDataType | getDataType () const |
| Return the image data pixel's type. More... | |
| size_t | getMipMapCount () const |
| Return the number of mip maps contained in the image. More... | |
| size_t | getLayerCount () const |
| Return the number of layers contained in the image. More... | |
| bool | isCubeMap () const |
| Is this image a cube map? More... | |
| const MipMap & | getMipMap (size_t mipMap, size_t layer=0) const |
| Return a mip map. More... | |
| void | decompress () |
| Manually decompress the texture image data. More... | |
| const TXI & | getTXI () const |
| Return the texture information TXI, which may be embedded in the image. More... | |
| bool | dumpTGA (const Common::UString &fileName) const |
| Dump the image into a TGA. More... | |
Private Member Functions | |
| void | load (Common::SeekableReadStream &txb) |
| void | readHeader (Common::SeekableReadStream &txb, byte &encoding, uint32 &dataSize) |
| void | readData (Common::SeekableReadStream &txb, byte encoding) |
| void | readTXI (Common::SeekableReadStream &txb) |
Static Private Member Functions | |
| static void | deSwizzle (byte *dst, const byte *src, uint32 width, uint32 height, uint8 bpp) |
Additional Inherited Members | |
| Protected Types inherited from Graphics::ImageDecoder | |
| typedef Common::PtrVector< MipMap > | MipMaps |
| Static Protected Member Functions inherited from Graphics::ImageDecoder | |
| static void | decompress (MipMap &out, const MipMap &in, PixelFormatRaw format) |
| Protected Attributes inherited from Graphics::ImageDecoder | |
| bool | _compressed |
| bool | _hasAlpha |
| PixelFormat | _format |
| PixelFormatRaw | _formatRaw |
| PixelDataType | _dataType |
| size_t | _layerCount |
| Number of layers in this image. More... | |
| bool | _isCubeMap |
| Is this image a cube map? A cube map always needs to have 6 layers! More... | |
| MipMaps | _mipMaps |
| TXI | _txi |
Detailed Description
Another one of BioWare's own texture formats, TXB.
This format is used by Jade Empire.
Even though the Xbox versions of the Knights of the Old Republic games features textures with a .txb extension, these are actually in the TPC format, not this TXB format.
Constructor & Destructor Documentation
◆ TXB()
| Graphics::TXB::TXB | ( | Common::SeekableReadStream & | txb | ) |
◆ ~TXB()
Member Function Documentation
◆ deSwizzle()
|
staticprivate |
Definition at line 166 of file txb.cpp.
References Graphics::deSwizzleOffset().
Referenced by readData().
◆ load()
|
private |
Definition at line 47 of file txb.cpp.
References Common::StackException::add(), readData(), readHeader(), readTXI(), and Common::SeekableReadStream::seek().
Referenced by TXB().
◆ readData()
|
private |
Definition at line 177 of file txb.cpp.
References Graphics::ImageDecoder::_mipMaps, deSwizzle(), Common::ScopedPtrBase< T, Deallocator >::get(), kEncodingBGRA, kEncodingGray, Common::kReadError, Common::ReadStream::read(), and Common::ScopedPtrBase< T, Deallocator >::swap().
Referenced by load().
◆ readHeader()
|
private |
Definition at line 80 of file txb.cpp.
References Graphics::ImageDecoder::_compressed, Graphics::ImageDecoder::_dataType, Graphics::ImageDecoder::_format, Graphics::ImageDecoder::_formatRaw, Graphics::ImageDecoder::_hasAlpha, Graphics::ImageDecoder::_mipMaps, Graphics::getTXBDataSize(), Graphics::hasValidDimensions(), kEncodingBGRA, kEncodingDXT1, kEncodingDXT5, kEncodingGray, Graphics::kPixelDataType8, Graphics::kPixelFormatBGR, Graphics::kPixelFormatBGRA, Graphics::kPixelFormatDXT1, Graphics::kPixelFormatDXT5, Graphics::kPixelFormatRGB8, Graphics::kPixelFormatRGBA8, Common::ReadStream::readByte(), Common::ReadStream::readUint16LE(), Common::ReadStream::readUint32LE(), Common::ScopedPtrBase< T, Deallocator >::release(), and Common::SeekableReadStream::skip().
Referenced by load().
◆ readTXI()
|
private |
Definition at line 220 of file txb.cpp.
References Graphics::ImageDecoder::_txi, Graphics::TXI::load(), Common::SeekableReadStream::pos(), Common::ReadStream::readStream(), and Common::SeekableReadStream::size().
Referenced by load().
The documentation for this class was generated from the following files:
