#include <highlightableguiquad.h>

Inheritance diagram for Graphics::Aurora::HighlightableGUIQuad:

[legend]

Collaboration diagram for Graphics::Aurora::HighlightableGUIQuad:

[legend]

Public Member Functions
	HighlightableGUIQuad (const Common::UString &texture, float x1, float y1, float x2, float y2, float tX1=0.0f, float tY1=0.0f, float tX2=1.0f, float tY2=1.0f)

	~HighlightableGUIQuad ()

void	render (RenderPass pass)
	Render the object. More...

Public Member Functions inherited from Graphics::Aurora::GUIQuad
	GUIQuad (const Common::UString &texture, float x1, float y1, float x2, float y2, float tX1=0.0f, float tY1=0.0f, float tX2=1.0f, float tY2=1.0f)

	GUIQuad (Graphics::GUIElement::GUIElementType type, const Common::UString &texture, float x1, float y1, float x2, float y2, float tX1=0.0f, float tY1=0.0f, float tX2=1.0f, float tY2=1.0f)

	GUIQuad (TextureHandle texture, float x1, float y1, float x2, float y2, float tX1=0.0f, float tY1=0.0f, float tX2=1.0f, float tY2=1.0f)

	~GUIQuad ()

void	getPosition (float &x, float &y, float &z) const
	Get the current position of the quad. More...

void	setPosition (float x, float y, float z=-FLT_MAX)
	Set the current position of the quad. More...

void	setRotation (float angle)
	Set the current rotation of the quad in degrees. More...

void	getColor (float &r, float &g, float &b, float &a) const
	Get the current color of the quad. More...

void	setColor (float r, float g, float b, float a)
	Set the current color of the quad. More...

void	setTexture (const Common::UString &texture)
	Set the current texture of the quad. More...

void	setTexture (TextureHandle texture)
	Set the current texture of the quad. More...

void	setScissor (int x, int y, int width, int height)
	Set the scissor test parameters. More...

float	getWidth () const
	Return the quad's width. More...

float	getHeight () const
	Return the quad's height. More...

void	setWidth (float w)
	Set the quad's width. More...

void	setHeight (float h)
	Set the quad's height. More...

void	setXOR (bool enabled)
	Enable/Disable XOR mode. More...

void	setScissor (bool enabled)
	Enable/Disable Scissor Test. More...

bool	isIn (float x, float y) const
	Is the point within the quad? More...

void	calculateDistance ()
	Calculate the object's distance. More...

Public Member Functions inherited from Graphics::GUIElement
	GUIElement (GUIElementType type)

	~GUIElement ()

Public Member Functions inherited from Graphics::Renderable
	Renderable (RenderableType type)

	~Renderable ()

bool	operator< (const Queueable &q) const

virtual void	advanceTime (float dt)
	Advance time (used by renderables with animations). More...

virtual void	renderImmediate (const glm::mat4 &parentTransform)
	For shader based systems, don't sort anything, render this right_now. More...

virtual void	queueRender (const glm::mat4 &parentTransform)
	Queue the object for later rendering. More...

double	getDistance () const
	Get the distance of the object from the viewer. More...

uint32	getID () const
	Get the object's unique ID. More...

bool	isClickable () const
	Is the object clickable? More...

void	setClickable (bool clickable)
	Set the object's clickable state. More...

const Common::UString &	getTag () const
	Get the object's tag. More...

void	setTag (const Common::UString &tag)
	Set the object's tag. More...

bool	isVisible () const
	Is the object visible? More...

virtual void	show ()
	Show the object. More...

virtual void	hide ()
	Hide the object. More...

virtual bool	isIn (float x, float y, float z) const
	Is that point within the object? More...

virtual bool	isIn (float x1, float y1, float z1, float x2, float y2, float z2) const
	Does the line from x1.y1.z1 to x2.y2.z2 intersect with the object? More...

Public Member Functions inherited from Graphics::Queueable
	Queueable ()

virtual	~Queueable ()

Public Member Functions inherited from Graphics::Aurora::Highlightable
	Highlightable ()

virtual	~Highlightable ()

bool	isHighlightable () const

void	setHighlightable (bool highlightable)

bool	isHightlighted () const

void	setHighlighted (bool hightlighted)

void	setHighlightDelta (float r, float g, float b, float a)
	Set how much the quad changes per render. More...

void	setHighlightUpperBound (float r, float g, float b, float a)
	When any of the quad properties are greater than this bound, the signs of the delta floats will flip. More...

void	setHighlightLowerBound (float r, float g, float b, float a)
	When any of the quad properties are less than this bound, the signs of the delta floats will flip. More...

void	getHighlightedLowerBound (float &r, float &g, float &b, float &a) const

Additional Inherited Members
Public Types inherited from Graphics::GUIElement
enum	GUIElementType { kGUIElementFront = kRenderableTypeGUIFront, kGUIElementBack = kRenderableTypeGUIBack, kGUIElementConsole = kRenderableTypeConsole }

Protected Member Functions inherited from Graphics::Renderable
void	resort ()

void	lockFrame ()

void	unlockFrame ()

void	lockFrameIfVisible ()

void	unlockFrameIfVisible ()

Protected Member Functions inherited from Graphics::Queueable
bool	isInQueue (QueueType queue) const

void	addToQueue (QueueType queue)

void	removeFromQueue (QueueType queue)

void	lockQueue (QueueType queue)

void	unlockQueue (QueueType queue)

void	sortQueue (QueueType queue)

Protected Member Functions inherited from Graphics::Aurora::Highlightable
void	flipHighlightDelta ()

void	incrementColor (float initialR, float initialG, float initialB, float initialA, float &r, float &g, float &b, float &a)

Protected Attributes inherited from Graphics::Renderable
QueueType	_queueExists

QueueType	_queueVisible

uint32	_id

bool	_clickable

Common::UString	_tag

double	_distance
	The distance of the object from the viewer. More...

Detailed Description

Definition at line 31 of file highlightableguiquad.h.

Constructor & Destructor Documentation

◆ HighlightableGUIQuad()

Graphics::Aurora::HighlightableGUIQuad::HighlightableGUIQuad	(	const Common::UString &	texture,
		float	x1,
		float	y1,
		float	x2,
		float	y2,
		float	tX1 = `0.0f`,
		float	tY1 = `0.0f`,
		float	tX2 = `1.0f`,
		float	tY2 = `1.0f`
	)
