fft.cpp File Reference

(Inverse) Fast Fourier Transform. More...

#include <cassert>
#include <cstring>
#include "src/common/maths.h"
#include "src/common/cosinetables.h"
#include "src/common/util.h"
#include "src/common/fft.h"

Include dependency graph for fft.cpp:

Go to the source code of this file.

Namespaces
	Common

Macros
#define	sqrthalf   (float)M_SQRT1_2
#define	BF(x, y, a, b)
#define	BUTTERFLIES(a0, a1, a2, a3)
#define	BUTTERFLIES_BIG(a0, a1, a2, a3)
#define	TRANSFORM(a0, a1, a2, a3, wre, wim)
#define	TRANSFORM_ZERO(a0, a1, a2, a3)
#define	PASS(name)
#define	BUTTERFLIES   BUTTERFLIES_BIG
#define	DECL_FFT(t, n, n2, n4)
#define	pass   pass_big

Functions
static void	Common::pass (Complex *z, const float *wre, unsigned int n)
static void	Common::pass_big (Complex *z, const float *wre, unsigned int n)
static void	Common::fft4 (Complex *z)
static void	Common::fft8 (Complex *z)
static void	Common::fft16 (Complex *z)
static void	Common::fft32 (Complex *z)
static void	Common::fft64 (Complex *z)
static void	Common::fft128 (Complex *z)
static void	Common::fft256 (Complex *z)
static void	Common::fft512 (Complex *z)
static void	Common::fft1024 (Complex *z)
static void	Common::fft2048 (Complex *z)
static void	Common::fft4096 (Complex *z)
static void	Common::fft8192 (Complex *z)
static void	Common::fft16384 (Complex *z)
static void	Common::fft32768 (Complex *z)
static void	Common::fft65536 (Complex *z)

Variables
static void(*const	Common::fft_dispatch [])(Complex *)

Detailed Description

(Inverse) Fast Fourier Transform.

Definition in file fft.cpp.

Macro Definition Documentation

BF

#define BF	(		x,
			y,
			a,
			b
	)

Value:

{\
    x = a - b;\
    y = a + b;\
}

Definition at line 123 of file fft.cpp.

Referenced by Common::fft4(), and Common::fft8().

BUTTERFLIES [1/2]

#define BUTTERFLIES	(		a0,
			a1,
			a2,
			a3
	)

Value:

{\
    BF(t3, t5, t5, t1);\
    BF(a2.re, a0.re, a0.re, t5);\
    BF(a3.im, a1.im, a1.im, t3);\
    BF(t4, t6, t2, t6);\
    BF(a3.re, a1.re, a1.re, t4);\
    BF(a2.im, a0.im, a0.im, t6);\
}

Definition at line 190 of file fft.cpp.

BUTTERFLIES [2/2]

#define BUTTERFLIES   BUTTERFLIES_BIG

Definition at line 190 of file fft.cpp.

BUTTERFLIES_BIG

#define BUTTERFLIES_BIG	(		a0,
			a1,
			a2,
			a3
	)

Value:

{\
    float r0=a0.re, i0=a0.im, r1=a1.re, i1=a1.im;\
    BF(t3, t5, t5, t1);\
    BF(a2.re, a0.re, r0, t5);\
    BF(a3.im, a1.im, i1, t3);\
    BF(t4, t6, t2, t6);\
    BF(a3.re, a1.re, r1, t4);\
    BF(a2.im, a0.im, i0, t6);\
}

Definition at line 140 of file fft.cpp.

DECL_FFT

#define DECL_FFT	(		t,
			n,
			n2,
			n4
	)

Value:

static void fft##n(Complex *z)\
{\
    fft##n2(z);\
    fft##n4(z+n4*2);\
    fft##n4(z+n4*3);\
    pass(z,getCosineTable(t),n4/2);\
}

Definition at line 193 of file fft.cpp.

PASS

#define PASS

(

name

)

Value:

static void name(Complex *z, const float *wre, unsigned int n)\
{\
    float t1, t2, t3, t4, t5, t6;\
    int o1 = 2*n;\
    int o2 = 4*n;\
    int o3 = 6*n;\
    const float *wim = wre+o1;\
    n--;\
\
	TRANSFORM_ZERO(z[0],z[o1],z[o2],z[o3]);\
    TRANSFORM(z[1],z[o1+1],z[o2+1],z[o3+1],wre[1],wim[-1]);\
    do {\
        z += 2;\
        wre += 2;\
        wim -= 2;\
        TRANSFORM(z[0],z[o1],z[o2],z[o3],wre[0],wim[0]);\
        TRANSFORM(z[1],z[o1+1],z[o2+1],z[o3+1],wre[1],wim[-1]);\
    } while (--n);\
}

Definition at line 167 of file fft.cpp.

pass

#define pass   pass_big

Definition at line 257 of file fft.cpp.

Referenced by Graphics::Shader::ShaderDescriptor::addPass(), Graphics::Aurora::HighlightableText::render(), Graphics::Aurora::HighlightableGUIQuad::render(), Graphics::Aurora::SubSceneQuad::render(), Graphics::Aurora::FPS::render(), Graphics::Aurora::KotORDialogFrame::render(), Engines::Trigger::render(), Engines::Sonic::AreaBackground::render(), Graphics::Aurora::BorderQuad::render(), Graphics::Aurora::CubeSide::render(), Engines::Jade::GUIBackground::render(), Engines::KotOR::GUIBackground::render(), Graphics::Aurora::FadeQuad::render(), Graphics::Aurora::GeometryObject::render(), Graphics::Aurora::Walkmesh::render(), Engines::NWN::Scrollbar::render(), Engines::NWN::NewGameFog::render(), Engines::NWN::Portrait::render(), Graphics::Aurora::Text::render(), Graphics::Aurora::GUIQuad::render(), Engines::NWN::FadeModel::render(), Graphics::Aurora::Model_Sonic::render(), Engines::ConsoleWindow::render(), Video::VideoDecoder::render(), Engines::NWN::DialogBox::render(), Graphics::Aurora::Model::render(), and Graphics::Aurora::ModelNode::render().

sqrthalf

#define sqrthalf   (float)M_SQRT1_2

Definition at line 121 of file fft.cpp.

Referenced by Common::fft16(), and Common::fft8().

TRANSFORM

#define TRANSFORM	(		a0,
			a1,
			a2,
			a3,
			wre,
			wim
	)

Value:

{\
    t1 = a2.re * wre + a2.im * wim;\
    t2 = a2.im * wre - a2.re * wim;\
    t5 = a3.re * wre - a3.im * wim;\
    t6 = a3.im * wre + a3.re * wim;\
    BUTTERFLIES(a0,a1,a2,a3)\
}

Definition at line 150 of file fft.cpp.

Referenced by Common::fft16(), and Common::fft8().

TRANSFORM_ZERO

#define TRANSFORM_ZERO	(		a0,
			a1,
			a2,
			a3
	)

Value:

{\
    t1 = a2.re;\
    t2 = a2.im;\
    t5 = a3.re;\
    t6 = a3.im;\
    BUTTERFLIES(a0,a1,a2,a3)\
}

Definition at line 158 of file fft.cpp.

Referenced by Common::fft16().
