#include <model_witcher.h>

Inheritance diagram for Graphics::Aurora::ModelNode_Witcher:

Collaboration diagram for Graphics::Aurora::ModelNode_Witcher:

[legend]

Classes
struct	TexturePaintLayer

Public Member Functions
	ModelNode_Witcher (Model &model)

	~ModelNode_Witcher ()

void	load (Model_Witcher::ParserContext &ctx)

Public Member Functions inherited from Graphics::Aurora::ModelNode
	ModelNode (Model &model)

virtual	~ModelNode ()

const Common::UString &	getName () const
	Get the node's name. More...

float	getWidth () const
	Get the width of the node's bounding box. More...

float	getHeight () const
	Get the height of the node's bounding box. More...

float	getDepth () const
	Get the depth of the node's bounding box. More...

void	setInvisible (bool invisible)
	Should the node never be rendered at all? More...

void	setEnvironmentMap (const Common::UString &environmentMap="")
	Change the environment map on this model node. More...

void	getPosition (float &x, float &y, float &z) const
	Get the position of the node. More...

void	getRotation (float &x, float &y, float &z) const
	Get the rotation of the node. More...

void	getOrientation (float &x, float &y, float &z, float &a) const
	Get the orientation of the node. More...

void	getAbsolutePosition (float &x, float &y, float &z) const
	Get the position of the node after translate/rotate. More...

glm::mat4	getAbsolutePosition () const
	Get the position of the node after translate/rotate. More...

uint16	getNodeNumber () const

void	setPosition (float x, float y, float z)
	Set the position of the node. More...

void	setRotation (float x, float y, float z)
	Set the rotation of the node. More...

void	setOrientation (float x, float y, float z, float a)
	Set the orientation of the node. More...

void	move (float x, float y, float z)
	Move the node, relative to its current position. More...

void	rotate (float x, float y, float z)
	Rotate the node, relative to its current rotation. More...

void	setTextures (const std::vector< Common::UString > &textures)
	Set textures to the node. More...

void	computeInverseBindPose ()

void	computeAbsoluteTransform ()

float	getAlpha ()
	Get the alpha (transparency) of the node. More...

void	setAlpha (float alpha, bool isRecursive=true)
	Set the alpha (transparency) of the node. More...

float	getScaleX ()

float	getScaleY ()

float	getScaleZ ()

ModelNode *	getParent ()
	Get the node's parent. More...

const ModelNode *	getParent () const
	Get the node's parent. More...

void	setParent (ModelNode *parent)
	Set the node's parent. More...

std::list< ModelNode * > &	getChildren ()
	Get the node's children. More...

Mesh *	getMesh () const

bool	isInFrontOf (const ModelNode &node) const
	Is this node in front of that other node? More...

void	inheritPosition (ModelNode &node) const

void	inheritOrientation (ModelNode &node) const

Protected Member Functions
void	buildMaterial ()

Protected Member Functions inherited from Graphics::Aurora::ModelNode
void	loadTextures (const std::vector< Common::UString > &textures)

void	createBound ()

void	createCenter ()

void	createAbsoluteBound ()

void	createAbsoluteBound (Common::BoundingBox parentPosition)

void	render (RenderPass pass)

void	drawSkeleton (const glm::mat4 &parent, bool showInvisible)

void	calcRenderTransform (const glm::mat4 &parentTransform)
	Calculate the transform used for rendering. More...

void	renderImmediate (const glm::mat4 &parentTransform)

void	queueRender (const glm::mat4 &parentTransform)

void	lockFrame ()

void	unlockFrame ()

void	lockFrameIfVisible ()

void	unlockFrameIfVisible ()

void	setBufferedPosition (float x, float y, float z)

void	setBufferedOrientation (float x, float y, float z, float angle)

void	flushBuffers ()

TextureHandle *	getTextures (uint32 &count)

TextureHandle *	getEnvironmentMap (EnvironmentMapMode &mode)

void	setMaterial (Shader::ShaderMaterial *material)

Private Member Functions
void	readMesh (Model_Witcher::ParserContext &ctx)

void	readTexturePaint (Model_Witcher::ParserContext &ctx)

void	readTextures (Model_Witcher::ParserContext &ctx, std::vector< Common::UString > &textures)

void	readNodeControllers (Model_Witcher::ParserContext &ctx, uint32 offset, uint32 count, std::vector< float > &data)

void	evaluateTextures (int n, std::vector< Common::UString > &textures, const Common::UString staticTextures, const uint32 tVertsCount, bool lightMapDayNight, const Common::UString &lightMapName)

Additional Inherited Members
Public Types inherited from Graphics::Aurora::ModelNode
enum	EnvironmentMapMode { kModeEnvironmentBlendedUnder, kModeEnvironmentBlendedOver }
	The way the environment map is applied to a model node. More...

Protected Attributes inherited from Graphics::Aurora::ModelNode
Model *	_model
	The model this node belongs to. More...

ModelNode *	_parent
	The node's parent. More...

std::list< ModelNode * >	_children
	The node's children. More...

Model *	_attachedModel
	The model that is attached to this node. More...

uint32	_level

Common::UString	_name
	The node's name. More...

std::vector< Shader::ShaderRenderable >	_renderableArray
	Damn you bioware. More...

float	_center [3]
	The node's center. More...

float	_position [3]
	Position of the node. More...

float	_rotation [3]
	Node rotation. More...

float	_orientation [4]
	Orientation of the node. More...

float	_scale [3]
	Scale of the node. More...

float	_alpha
	Alpha of the node, used if no _mesh is present in this node. More...

std::vector< PositionKeyFrame >	_positionFrames
	Keyframes for position animation. More...

std::vector< QuaternionKeyFrame >	_orientationFrames
	Keyframes for orientation animation. More...

glm::mat4	_absolutePosition
	Position of the node after translate/rotate. More...

glm::mat4	_renderTransform

bool	_render
	Render the node? More...

bool	_dirtyRender
	Rendering information needs updating. More...

bool	_dirtyMesh
	Mesh data needs updating. More...

Mesh *	_mesh

ModelNode *	_rootStateNode

Common::BoundingBox	_boundBox

Common::BoundingBox	_absoluteBoundBox

uint16	_nodeNumber

glm::mat4	_invBindPose
	Inverse bind pose matrix used for animations. More...

glm::mat4	_absoluteTransform
	Absolute transformation matrix used for animations. More...

float	_positionBuffer [3]

bool	_positionBuffered

float	_orientationBuffer [4]

bool	_orientationBuffered

std::vector< float >	_vertexCoordsBuffer

bool	_vertexCoordsBuffered

Shader::ShaderMaterial *	_material

Shader::ShaderRenderable *	_shaderRenderable

Detailed Description

Definition at line 85 of file model_witcher.h.

Constructor & Destructor Documentation

◆ ModelNode_Witcher()

Graphics::Aurora::ModelNode_Witcher::ModelNode_Witcher ( Model & model )

Definition at line 242 of file model_witcher.cpp.

Referenced by load().

Here is the caller graph for this function:

◆ ~ModelNode_Witcher()

Graphics::Aurora::ModelNode_Witcher::~ModelNode_Witcher ( )

Definition at line 245 of file model_witcher.cpp.

Member Function Documentation

◆ buildMaterial()

void Graphics::Aurora::ModelNode_Witcher::buildMaterial ( )

protectedvirtual

If there's no override of mesh, textures, or environment mapping, then don't bother to create any new renderables. Just make sure rootStateNode has some, and have the render queuing use the renderables from there instead. This isn't really a problem, as the per-modelnode data (modelview matrix in this case) is still supplied from _this object.

To get here, _mesh must exist and have some data. This is required to consider making a new renderable - otherwise, the renderable of the parent can be used directly. This may change depending what information the renderable is dependent on during creation. Important information in this case means texture or environment maps are overidden from any potential parent.

Seems that, regardless of _isTransparent, anything with shperical env mapping is opaque. This mostly comes from NWN, where it's seen that things marked as transparent actually shouldn't be. It's assumed this carries over to other game titles as well.

Sometimes the _textures handler array isn't matched up against what is properly loaded (missing files from disk). So do some brief sanity checks on this.

The Witcher will place diffuse texture as the second if there's more than one. In these cases, the first texture will be a lightmap. Because that makes sense.

Actually this looks like a case where someone has declared multiple textures, but only filled in one. So the second, which should be a lightmap, is actually the diffuse. Just to screw with everyone's head a bit. Just set the colour, which will default to white - a diffuse texture treated as a lightmap, multiplying white, will end up with the same RGB values.

Reimplemented from Graphics::Aurora::ModelNode.

Definition at line 980 of file model_witcher.cpp.

Referenced by readTexturePaint().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ evaluateTextures()

void Graphics::Aurora::ModelNode_Witcher::evaluateTextures	(	int	n,
		std::vector< Common::UString > &	textures,
		const Common::UString *	staticTextures,
		const uint32 *	tVertsCount,
		bool	lightMapDayNight,
		const Common::UString &	lightMapName
	)

private

Definition at line 897 of file model_witcher.cpp.

References Aurora::kResourceImage, and ResMan.

Referenced by readMesh(), and readTexturePaint().

Here is the caller graph for this function:

◆ load()

void Graphics::Aurora::ModelNode_Witcher::load ( Model_Witcher::ParserContext & ctx )

Dirty hack around an issue where sometimes a tile can have multiple meshes of exactly the same name. This dirty hack will double up on static objects without state, but hopefully they're relatively few and it won't impact performance too much. A future improvement will be to see if an entire model has already been loaded and to use that directly: that should prevent models with an empty state from being affected by this dirty hack. Screw you bioware.

Definition at line 248 of file model_witcher.cpp.

Referenced by Graphics::Aurora::Model_Witcher::load(), and load().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readMesh()

void Graphics::Aurora::ModelNode_Witcher::readMesh ( Model_Witcher::ParserContext & ctx )

private

Definition at line 360 of file model_witcher.cpp.

Referenced by load().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readNodeControllers()

void Graphics::Aurora::ModelNode_Witcher::readNodeControllers	(	Model_Witcher::ParserContext &	ctx,
		uint32	offset,
		uint32	count,
		std::vector< float > &	data
	)
