Graphics::Aurora::ABCFont Class Reference

An ABC/SBM font, as used by Jade Empire. More...

#include <abcfont.h>

Inheritance diagram for Graphics::Aurora::ABCFont:
Inheritance graph
[legend]
Collaboration diagram for Graphics::Aurora::ABCFont:
Collaboration graph
[legend]

Classes

struct  Char
 A font character. More...


Public Member Functions

 ABCFont (const Common::UString &name)

 ~ABCFont ()

float getWidth (uint32 c) const
 Return the width of a character. More...

float getHeight () const
 Return the height of a character. More...

void draw (uint32 c) const
 Draw this character. More...

virtual void renderBind (const glm::mat4 &transform) const
 Bind the font for rendering. More...

virtual void render (uint32 c, float &x, float &y, float *rgba) const

virtual void renderUnbind () const

- Public Member Functions inherited from Graphics::Font
 Font ()

virtual ~Font ()

virtual float getLineSpacing () const
 Return the size of space between lines. More...

size_t getLineCount (const Common::UString &text, float maxWidth=0.0f, float maxHeight=0.0f) const
 Return the number of lines this text spans. More...

float getWidth (const Common::UString &text, float maxWidth=0.0f) const
 Return the width this string would take. More...

float getHeight (const Common::UString &text, float maxWidth=0.0f, float maxHeight=0.0f) const
 Return the height this string would take. More...

float getLineWidth (const Common::UString &text) const
 Return the width of this string. More...

virtual void buildChars (const Common::UString &str)
 Build all necessary characters to display this string. More...

float split (const Common::UString &line, std::vector< Common::UString > &lines, float maxWidth=0.0f, float maxHeight=0.0f, bool trim=true) const

float split (Common::UString &line, float maxWidth, float maxHeight=0.0f, bool trim=true) const

float split (const Common::UString &line, Common::UString &lines, float maxWidth, float maxHeight=0.0f, bool trim=true) const


Private Member Functions

void load (const Common::UString &name)

void readCharDesc (Char &c, Common::SeekableReadStream &abc)

void calcCharVertices (Char &c)

const Char & findChar (uint32 c) const


Private Attributes

TextureHandle _texture

Mesh::MeshFont * _mesh

Shader::ShaderMaterial * _material

Shader::ShaderRenderable * _renderable

uint8 _base

Char _invalid

Char _ascii [128]

std::map< uint32, Char > _extended


Detailed Description

An ABC/SBM font, as used by Jade Empire.

Definition at line 50 of file abcfont.h.

Constructor & Destructor Documentation

◆ ABCFont()

Graphics::Aurora::ABCFont::ABCFont ( const Common::UString &  name)

Definition at line 43 of file abcfont.cpp.

References _material, _mesh, _renderable, _texture, Graphics::Shader::ShaderMaterial::getVariableData(), Graphics::Shader::ShaderSampler::handle, load(), MeshMan, Graphics::Shader::SHADER_FRAGMENT, ShaderMan, SurfaceMan, and TextureMan.

Here is the call graph for this function:

◆ ~ABCFont()

Graphics::Aurora::ABCFont::~ABCFont ( )

Definition at line 56 of file abcfont.cpp.

References _material, and _renderable.

Member Function Documentation

◆ calcCharVertices()

void Graphics::Aurora::ABCFont::calcCharVertices ( Char &  c)
private

Definition at line 210 of file abcfont.cpp.

References _texture, Graphics::Aurora::ABCFont::Char::dataX, Graphics::Aurora::ABCFont::Char::dataY, Graphics::Aurora::Texture::getHeight(), Graphics::Aurora::TextureHandle::getTexture(), Graphics::Aurora::Texture::getWidth(), Graphics::Aurora::ABCFont::Char::tX, Graphics::Aurora::ABCFont::Char::tY, Graphics::Aurora::ABCFont::Char::vX, Graphics::Aurora::ABCFont::Char::vY, and Graphics::Aurora::ABCFont::Char::width.

Referenced by load().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ draw()

void Graphics::Aurora::ABCFont::draw ( uint32  c) const
virtual

Draw this character.

Implements Graphics::Font.

Definition at line 71 of file abcfont.cpp.

References _texture, findChar(), Graphics::Aurora::ABCFont::Char::spaceL, Graphics::Aurora::ABCFont::Char::spaceR, TextureMan, Graphics::Aurora::ABCFont::Char::tX, Graphics::Aurora::ABCFont::Char::tY, Graphics::Aurora::ABCFont::Char::vX, Graphics::Aurora::ABCFont::Char::vY, and Graphics::Aurora::ABCFont::Char::width.

Here is the call graph for this function:

◆ findChar()

const ABCFont::Char & Graphics::Aurora::ABCFont::findChar ( uint32  c) const
private

Definition at line 233 of file abcfont.cpp.

References _ascii, _extended, _invalid, and Common::UString::isASCII().

Referenced by draw(), getWidth(), and render().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ getHeight()

float Graphics::Aurora::ABCFont::getHeight ( ) const
virtual

Return the height of a character.

Implements Graphics::Font.

Definition at line 61 of file abcfont.cpp.

◆ getWidth()

float Graphics::Aurora::ABCFont::getWidth ( uint32  c) const
virtual

Return the width of a character.

Implements Graphics::Font.

Definition at line 65 of file abcfont.cpp.

References findChar(), Graphics::Aurora::ABCFont::Char::spaceL, Graphics::Aurora::ABCFont::Char::spaceR, and Graphics::Aurora::ABCFont::Char::width.

Here is the call graph for this function:

◆ load()

void Graphics::Aurora::ABCFont::load ( const Common::UString &  name)
private

Definition at line 129 of file abcfont.cpp.

References _ascii, _base, _extended, _invalid, Common::UString::c_str(), calcCharVertices(), Graphics::Aurora::ABCFont::Char::dataX, Graphics::Aurora::ABCFont::Char::dataY, Common::UString::fromUTF16(), Aurora::kFileTypeABC, readCharDesc(), ResMan, Graphics::Aurora::ABCFont::Char::spaceL, Graphics::Aurora::ABCFont::Char::spaceR, Graphics::Aurora::ABCFont::Char::tX, Graphics::Aurora::ABCFont::Char::tY, Graphics::Aurora::ABCFont::Char::vX, Graphics::Aurora::ABCFont::Char::vY, and Graphics::Aurora::ABCFont::Char::width.

Referenced by ABCFont().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ readCharDesc()

void Graphics::Aurora::ABCFont::readCharDesc ( Char &  c,
Common::SeekableReadStream &  abc
)
private

Definition at line 195 of file abcfont.cpp.

References Graphics::Aurora::ABCFont::Char::dataX, Graphics::Aurora::ABCFont::Char::dataY, Common::ReadStream::readByte(), Common::ReadStream::readUint32LE(), Graphics::Aurora::ABCFont::Char::spaceL, Graphics::Aurora::ABCFont::Char::spaceR, and Graphics::Aurora::ABCFont::Char::width.

Referenced by load().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ render()

void Graphics::Aurora::ABCFont::render ( uint32  c,
float &  x,
float &  y,
float *  rgba
) const
virtual

Reimplemented from Graphics::Font.

Definition at line 97 of file abcfont.cpp.

References _mesh, findChar(), Graphics::Mesh::MeshFont::render(), Graphics::Aurora::ABCFont::Char::spaceL, Graphics::Aurora::ABCFont::Char::spaceR, Graphics::Aurora::ABCFont::Char::tX, Graphics::Aurora::ABCFont::Char::tY, Graphics::Aurora::ABCFont::Char::vX, Graphics::Aurora::ABCFont::Char::vY, and Graphics::Aurora::ABCFont::Char::width.

Here is the call graph for this function:

◆ renderBind()

void Graphics::Aurora::ABCFont::renderBind ( const glm::mat4 &  transform) const
virtual

Bind the font for rendering.

Must be performed before render is called.

Parameters
transformBase modelview transform. Under most circumstances this is expected to be the identity matrix.

Reimplemented from Graphics::Font.

Definition at line 88 of file abcfont.cpp.

References _material, _mesh, _renderable, Graphics::Shader::ShaderSurface::bindGLState(), Graphics::Shader::ShaderMaterial::bindGLState(), Graphics::Shader::ShaderSurface::bindProgram(), Graphics::Shader::ShaderMaterial::bindProgram(), Graphics::Shader::ShaderRenderable::getProgram(), Graphics::Shader::ShaderRenderable::getSurface(), Graphics::Shader::ShaderProgram::glid, and Graphics::Mesh::Mesh::renderBind().

Here is the call graph for this function:

◆ renderUnbind()

void Graphics::Aurora::ABCFont::renderUnbind ( ) const
virtual

Reimplemented from Graphics::Font.

Definition at line 121 of file abcfont.cpp.

References _material, _mesh, _renderable, Graphics::Shader::ShaderRenderable::getSurface(), Graphics::Mesh::Mesh::renderUnbind(), Graphics::Shader::ShaderMaterial::unbindGLState(), and Graphics::Shader::ShaderSurface::unbindGLState().

Here is the call graph for this function:

Member Data Documentation

◆ _ascii

Char Graphics::Aurora::ABCFont::_ascii[128]
private

Definition at line 90 of file abcfont.h.

Referenced by findChar(), and load().

◆ _base

uint8 Graphics::Aurora::ABCFont::_base
private

Definition at line 87 of file abcfont.h.

Referenced by load().

◆ _extended

std::map<uint32, Char> Graphics::Aurora::ABCFont::_extended
private

Definition at line 91 of file abcfont.h.

Referenced by findChar(), and load().

◆ _invalid

Char Graphics::Aurora::ABCFont::_invalid
private

Definition at line 89 of file abcfont.h.

Referenced by findChar(), and load().

◆ _material

Shader::ShaderMaterial* Graphics::Aurora::ABCFont::_material
private

Definition at line 84 of file abcfont.h.

Referenced by ABCFont(), renderBind(), renderUnbind(), and ~ABCFont().

◆ _mesh

Mesh::MeshFont* Graphics::Aurora::ABCFont::_mesh
private

Definition at line 83 of file abcfont.h.

Referenced by ABCFont(), render(), renderBind(), and renderUnbind().

◆ _renderable

Shader::ShaderRenderable* Graphics::Aurora::ABCFont::_renderable
private

Definition at line 85 of file abcfont.h.

Referenced by ABCFont(), renderBind(), renderUnbind(), and ~ABCFont().

◆ _texture

TextureHandle Graphics::Aurora::ABCFont::_texture
private

Definition at line 82 of file abcfont.h.

Referenced by ABCFont(), calcCharVertices(), and draw().

The documentation for this class was generated from the following files:
