shader.h File Reference

The global shader manager. More...

#include <vector>
#include <map>
#include "src/common/ustring.h"
#include "src/common/singleton.h"
#include "src/common/mutex.h"
#include "src/graphics/texture.h"
#include "src/graphics/aurora/texturehandle.h"
#include "src/graphics/shader/shaderbuilder.h"

Include dependency graph for shader.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	Graphics::Shader::ShaderUBO
struct	Graphics::Shader::ShaderSampler
	Shader sampler is used to bind a texture to a texture unit. More...
class	Graphics::Shader::ShaderObject
struct	Graphics::Shader::ShaderObject::ShaderObjectVariable
class	Graphics::Shader::ShaderProgram
class	Graphics::Shader::ShaderManager
	The shader manager. More...

Namespaces
	Graphics
	Graphics::Shader

Macros
#define	ShaderMan   Graphics::Shader::ShaderManager::instance()
	Shortcut for accessing the shader manager. More...

Enumerations
enum	Graphics::Shader::ShaderVariableType {   Graphics::Shader::SHADER_FLOAT = 0, Graphics::Shader::SHADER_VEC2, Graphics::Shader::SHADER_VEC3, Graphics::Shader::SHADER_VEC4,   Graphics::Shader::SHADER_INT, Graphics::Shader::SHADER_IVEC2, Graphics::Shader::SHADER_IVEC3, Graphics::Shader::SHADER_IVEC4,   Graphics::Shader::SHADER_UINT, Graphics::Shader::SHADER_UVEC2, Graphics::Shader::SHADER_UVEC3, Graphics::Shader::SHADER_UVEC4,   Graphics::Shader::SHADER_BOOL, Graphics::Shader::SHADER_BVEC2, Graphics::Shader::SHADER_BVEC3, Graphics::Shader::SHADER_BVEC4,   Graphics::Shader::SHADER_MAT2, Graphics::Shader::SHADER_MAT2X2, Graphics::Shader::SHADER_MAT2X3, Graphics::Shader::SHADER_MAT2X4,   Graphics::Shader::SHADER_MAT3, Graphics::Shader::SHADER_MAT3X2, Graphics::Shader::SHADER_MAT3X3, Graphics::Shader::SHADER_MAT3X4,   Graphics::Shader::SHADER_MAT4, Graphics::Shader::SHADER_MAT4X2, Graphics::Shader::SHADER_MAT4X3, Graphics::Shader::SHADER_MAT4X4,   Graphics::Shader::SHADER_SAMPLER1D, Graphics::Shader::SHADER_SAMPLER2D, Graphics::Shader::SHADER_SAMPLER3D, Graphics::Shader::SHADER_SAMPLERCUBE,   Graphics::Shader::SHADER_SAMPLER1DSHADOW, Graphics::Shader::SHADER_SAMPLER2DSHADOW, Graphics::Shader::SHADER_SAMPLER1DARRAY, Graphics::Shader::SHADER_SAMPLER2DARRAY,   Graphics::Shader::SHADER_SAMPLER1DARRAYSHADOW, Graphics::Shader::SHADER_SAMPLER2DARRAYSHADOW, Graphics::Shader::SHADER_SAMPLERBUFFER, Graphics::Shader::SHADER_ISAMPLER1D,   Graphics::Shader::SHADER_ISAMPLER2D, Graphics::Shader::SHADER_ISAMPLER3D, Graphics::Shader::SHADER_ISAMPLERCUBE, Graphics::Shader::SHADER_ISAMPLER1DARRAY,   Graphics::Shader::SHADER_ISAMPLER2DARRAY, Graphics::Shader::SHADER_USAMPLER1D, Graphics::Shader::SHADER_USAMPLER2D, Graphics::Shader::SHADER_USAMPLER3D,   Graphics::Shader::SHADER_USAMPLERCUBE, Graphics::Shader::SHADER_USAMPLER1DARRAY, Graphics::Shader::SHADER_USAMPLER2DARRAY, Graphics::Shader::SHADER_UNIFORM_BUFFER,   Graphics::Shader::SHADER_INVALID }
	Enum of all supported shader variable parsing and automatic binding. More...
enum	Graphics::Shader::ShaderType { Graphics::Shader::SHADER_VERTEX = 0, Graphics::Shader::SHADER_FRAGMENT }
enum	Graphics::Shader::ShaderVertexAttrib {   Graphics::Shader::VERTEX_LOCATION = 0, Graphics::Shader::VERTEX_NORMAL = 1, Graphics::Shader::VERTEX_COLOR = 2, Graphics::Shader::VERTEX_TEXCOORD0 = 3,   Graphics::Shader::VERTEX_TEXCOORD1 = 4 }
enum	Graphics::Shader::ShaderUBOIndex { Graphics::Shader::UBO_VIEW_MATRICES = 0, Graphics::Shader::UBO_BONE_MATRICES = 1, Graphics::Shader::UBO_SCREEN_INFO = 2 }

Detailed Description

The global shader manager.

Developer's Notes: This form of shader handling is absolute overkill for xoreos. It's based upon code developed for a different project, then plugged into xoreos to save some wheel reinvention. It is, however, rather flexible and should be able to cleanly handle any quirks from any of the particular engines.

The basic idea:

• Parse shader text, looking for uniform variables.
• Put all uniform names into an array.
• A compiled program will copy the lists of uniforms from vertex and fragment shaders.
• The compiled program then matches the full list of uniforms with shader program locations.
• A shader program instance (shaderInstance) adds its own pointer information to match the program uniform list.
• Binding a shader program instance (shaderInstance) takes the pointer, and can then bind it directly to a location. So this is a bit complicated, but easily allows switching the data pointers within a shader program instance. Textures can be swapped out, colors modified, etc, and it's all automatically bound correctly. Assigning data to a variable within a shader program instance is generally done by using the variable's name directly. This avoids having to know the location of the variable in the compiled shader, and avoids having to know the index of the variable within the collected shader uniform list.

Uniform Buffer Objects UBO's are parsed out and treated as a single variable, similar to a texture sampler. The user themselves must specify both the UBO id to attach, and the attachment location. Index binding within the shader is possible, but discouraged here. It's an OpenGL >=4.2 feature, and while it would cut down on a little bit of overhead, the target version for xoreos is OpenGL 3.2 (maybe 3.3).

To anyone thinking that program introspection would replace much of this, well yes and no. Again, the original idea behind this code involved knowing what uniforms would be available prior to the program linker stage. Uniforms stripped out during the linker phase are pretty much ignored when binding a shader here, so that's not a worry. The methods here also allow a common shader object instance (e.g fragment shader) to be bound across multiple programs (this is where unused uniforms being ignored comes in).

Definition in file shader.h.

Macro Definition Documentation

ShaderMan

#define ShaderMan   Graphics::Shader::ShaderManager::instance()

Shortcut for accessing the shader manager.

Definition at line 293 of file shader.h.

Referenced by Graphics::Aurora::ABCFont::ABCFont(), Graphics::Shader::ShaderInstance::bind(), Graphics::Shader::ShaderMaterial::bindFade(), Graphics::Shader::ShaderSurface::bindObjectModelview(), Graphics::Shader::ShaderSurface::bindProgram(), Graphics::Shader::ShaderMaterial::bindProgram(), Graphics::Shader::ShaderMaterial::bindProgramNoFade(), Graphics::Shader::ShaderSurface::bindTextureView(), Graphics::Aurora::ModelNode_Witcher::buildMaterial(), Graphics::Aurora::ModelNode::buildMaterial(), Graphics::GraphicsManager::deinit(), Graphics::Shader::ShaderProgram::doRebuild(), Graphics::Shader::MaterialManager::init(), Graphics::GraphicsManager::init(), Graphics::Shader::ShaderManager::init(), Engines::NWN::Portrait::Portrait(), Graphics::Shader::ShaderInstance::rebindFragmentVariable(), Graphics::Shader::ShaderInstance::rebindVertexVariable(), Graphics::Shader::ShaderInstance::ShaderInstance(), Graphics::Shader::SurfaceManager::SurfaceManager(), Graphics::Aurora::TextureFont::TextureFont(), and Graphics::Shader::ShaderRenderable::updateProgram().
