A decoder for RAD Game Tools' Bink videos. More...

#include <bink.h>

Inheritance diagram for Video::Bink:

[legend]

Collaboration diagram for Video::Bink:

[legend]

Classes
struct	AudioInfo
	An audio track. More...

class	BinkAudioTrack

class	BinkVideoTrack

struct	VideoFrame
	A video frame. More...

Public Member Functions
	Bink (Common::SeekableReadStream *bink)

	~Bink ()

Public Member Functions inherited from Video::VideoDecoder
	VideoDecoder ()

	~VideoDecoder ()

void	setScale (Scale scale)

bool	isPlaying () const
	Is the video currently playing? More...

virtual uint32	getWidth () const
	Returns the width of the video's frames. More...

virtual uint32	getHeight () const
	Returns the height of the video's frames. More...

void	start ()
	Start playing the video. More...

void	abort ()
	Abort the playing of the video. More...

bool	needsUpdate () const
	Check whether a new frame should be decoded, i.e. More...

bool	endOfVideo () const
	Returns if the video has reached the end or not. More...

bool	endOfVideoTracks () const
	Have all video tracks finished? More...

uint32	getTime () const
	Returns the time position (in ms) of the current video. More...

uint32	getTimeToNextFrame () const
	Return the time, in milliseconds, to the next frame. More...

void	calculateDistance ()
	Calculate the object's distance. More...

void	render (Graphics::RenderPass pass)
	Render the object. More...

virtual Common::Timestamp	getDuration () const
	Get the duration of the video. More...

void	pauseVideo (bool pause)
	Pause or resume the video. More...

bool	isPaused () const
	Return whether the video is currently paused or not. More...

Public Member Functions inherited from Graphics::GLContainer
	GLContainer ()

	~GLContainer ()

void	rebuild ()

void	destroy ()

Public Member Functions inherited from Graphics::Queueable
	Queueable ()

virtual	~Queueable ()

Public Member Functions inherited from Graphics::Renderable
	Renderable (RenderableType type)

	~Renderable ()

bool	operator< (const Queueable &q) const

virtual void	advanceTime (float dt)
	Advance time (used by renderables with animations). More...

virtual void	renderImmediate (const glm::mat4 &parentTransform)
	For shader based systems, don't sort anything, render this right_now. More...

virtual void	queueRender (const glm::mat4 &parentTransform)
	Queue the object for later rendering. More...

double	getDistance () const
	Get the distance of the object from the viewer. More...

uint32	getID () const
	Get the object's unique ID. More...

bool	isClickable () const
	Is the object clickable? More...

void	setClickable (bool clickable)
	Set the object's clickable state. More...

const Common::UString &	getTag () const
	Get the object's tag. More...

void	setTag (const Common::UString &tag)
	Set the object's tag. More...

bool	isVisible () const
	Is the object visible? More...

virtual void	show ()
	Show the object. More...

virtual void	hide ()
	Hide the object. More...

virtual bool	isIn (float x, float y) const
	Is that point within the object? More...

virtual bool	isIn (float x, float y, float z) const
	Is that point within the object? More...

virtual bool	isIn (float x1, float y1, float z1, float x2, float y2, float z2) const
	Does the line from x1.y1.z1 to x2.y2.z2 intersect with the object? More...

Protected Member Functions
void	decodeNextTrackFrame (VideoTrack &track)
	Decode enough data for the next frame. More...

void	checkAudioBuffer (AudioTrack &track, const Common::Timestamp &endTime)
	Ensure that there is enough audio buffered in the given track to reach the given timestamp. More...

Protected Member Functions inherited from Video::VideoDecoder
void	initVideo ()
	Create a surface for video of these dimensions. More...

void	deinit ()

void	doRebuild ()

void	doDestroy ()

void	addTrack (Track *track, bool isExternal=false)
	Define a track to be used by this class. More...

TrackPtr	getTrack (uint track)
	Get the given internal track based on its index. More...

ConstTrackPtr	getTrack (uint track) const
	Get the given internal track based on its index. More...

VideoTrackPtr	findNextVideoTrack ()
	Set _nextVideoTrack to the video track with the lowest start time for the next frame. More...

TrackList	getInternalTracks ()
	Get a copy of the internal tracks. More...

ConstTrackList	getInternalTracks () const
	Get a copy of the internal tracks. More...

Protected Member Functions inherited from Graphics::Queueable
bool	isInQueue (QueueType queue) const

void	addToQueue (QueueType queue)

void	removeFromQueue (QueueType queue)

void	lockQueue (QueueType queue)

void	unlockQueue (QueueType queue)

void	sortQueue (QueueType queue)

Protected Member Functions inherited from Graphics::Renderable
void	resort ()

void	lockFrame ()

void	unlockFrame ()

void	lockFrameIfVisible ()

void	unlockFrameIfVisible ()

Private Types
enum	AudioCodec { kAudioCodecDCT, kAudioCodecRDFT }

Private Member Functions
void	load ()
	Load a Bink file. More...

void	initAudioTrack (AudioInfo &audio)

Private Attributes
Common::ScopedPtr< Common::SeekableReadStream >	_bink

std::vector< AudioInfo >	_audioTracks
	All audio tracks. More...

std::vector< VideoFrame >	_frames
	All video frames. More...

uint32	_audioTrack
	Audio track to use. More...

Static Private Attributes
static const int	kAudioChannelsMax = 2

static const int	kAudioBlockSizeMax = (kAudioChannelsMax << 11)

Additional Inherited Members
Public Types inherited from Video::VideoDecoder
enum	Scale { kScaleNone, kScaleUp, kScaleDown, kScaleUpDown }

Protected Types inherited from Video::VideoDecoder
typedef boost::shared_ptr< Track >	TrackPtr
	A Track pointer. More...

typedef boost::shared_ptr< const Track >	ConstTrackPtr
	A const Track pointer. More...

typedef boost::shared_ptr< AudioTrack >	AudioTrackPtr
	An AudioTrack pointer. More...

typedef boost::shared_ptr< VideoTrack >	VideoTrackPtr
	A VideoTrack pointer. More...

typedef std::vector< TrackPtr >	TrackList
	A list of tracks. More...

typedef std::vector< ConstTrackPtr >	ConstTrackList
	A list of const tracks. More...

Protected Attributes inherited from Video::VideoDecoder
bool	_needCopy
	Is new frame content available that needs to by copied? More...

Common::ScopedPtr< Graphics::Surface >	_surface
	The video's surface. More...

Protected Attributes inherited from Graphics::Renderable
QueueType	_queueExists

QueueType	_queueVisible

uint32	_id

bool	_clickable

Common::UString	_tag

double	_distance
	The distance of the object from the viewer. More...

Detailed Description

A decoder for RAD Game Tools' Bink videos.

Definition at line 98 of file bink.h.

Member Enumeration Documentation

◆ AudioCodec

enum Video::Bink::AudioCodec

private

Enumerator
kAudioCodecDCT
kAudioCodecRDFT

Definition at line 111 of file bink.h.

Constructor & Destructor Documentation

◆ Bink()

Video::Bink::Bink ( Common::SeekableReadStream * bink )

Definition at line 154 of file bink.cpp.

References _bink, and load().

Here is the call graph for this function:

◆ ~Bink()

Video::Bink::~Bink ( )

Definition at line 160 of file bink.cpp.

Member Function Documentation

◆ checkAudioBuffer()

void Video::Bink::checkAudioBuffer	(	AudioTrack &	track,
		const Common::Timestamp &	endTime
	)

protectedvirtual

Ensure that there is enough audio buffered in the given track to reach the given timestamp.

Reimplemented from Video::VideoDecoder.

Definition at line 199 of file bink.cpp.

References _audioTracks, _bink, and _frames.

◆ decodeNextTrackFrame()

void Video::Bink::decodeNextTrackFrame ( VideoTrack & track )

protectedvirtual

Decode enough data for the next frame.

Currently, audio may be buffered here at the same time. This is deprecated in favor of using checkAudioBuffer().

Implements Video::VideoDecoder.

Definition at line 163 of file bink.cpp.

References _audioTracks, _bink, _frames, Video::VideoDecoder::_needCopy, Video::VideoDecoder::_surface, Video::Bink::VideoFrame::bits, Video::Bink::BinkVideoTrack::decodePacket(), Common::ScopedPtrBase< T, Deallocator >::get(), Video::Bink::BinkVideoTrack::getCurFrame(), Video::Bink::VideoFrame::offset, and Video::Bink::VideoFrame::size.

Here is the call graph for this function:

◆ initAudioTrack()

void Video::Bink::initAudioTrack ( AudioInfo & audio )

private

Definition at line 519 of file bink.cpp.

Referenced by load().

Here is the caller graph for this function:

◆ load()

void Video::Bink::load ( )

private

Load a Bink file.

Definition at line 439 of file bink.cpp.

References _audioTrack, _audioTracks, _bink, _frames, Video::VideoDecoder::addTrack(), Common::debugTag(), Video::Bink::AudioInfo::flags, initAudioTrack(), Video::VideoDecoder::initVideo(), kBIKbID, kBIKfID, kBIKgID, kBIKhID, kBIKiID, kBIKkID, kKB2aID, kKB2dID, kKB2fID, kKB2gID, kKB2hID, kKB2iID, kKB2jID, kKB2kID, kVideoFlagAlpha, Video::Bink::AudioInfo::sampleRate, and warning().

Referenced by Bink().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ _audioTrack

uint32 Video::Bink::_audioTrack

private

Audio track to use.

Definition at line 170 of file bink.h.

Referenced by load().

◆ _audioTracks

std::vector<AudioInfo> Video::Bink::_audioTracks

private

All audio tracks.

Definition at line 167 of file bink.h.

Referenced by checkAudioBuffer(), decodeNextTrackFrame(), and load().

◆ _bink

Common::ScopedPtr<Common::SeekableReadStream> Video::Bink::_bink

private

Definition at line 165 of file bink.h.

Referenced by Bink(), checkAudioBuffer(), decodeNextTrackFrame(), and load().

◆ _frames

std::vector<VideoFrame> Video::Bink::_frames

private

All video frames.

Definition at line 168 of file bink.h.

Referenced by checkAudioBuffer(), decodeNextTrackFrame(), and load().

◆ kAudioBlockSizeMax

const int Video::Bink::kAudioBlockSizeMax = (kAudioChannelsMax << 11)

staticprivate

Definition at line 109 of file bink.h.

◆ kAudioChannelsMax

const int Video::Bink::kAudioChannelsMax = 2

staticprivate

Definition at line 108 of file bink.h.

Referenced by initAudioTrack().

The documentation for this class was generated from the following files:

src/video/bink.h
src/video/bink.cpp
