Class to hold resource data of an ERF archive file. More...

#include <erffile.h>

Inheritance diagram for Aurora::ERFFile:

Collaboration diagram for Aurora::ERFFile:

[legend]

Classes
struct	ERFHeader
	The header of an ERF file. More...

struct	IResource
	Internal resource information. More...

Public Member Functions
	ERFFile (Common::SeekableReadStream *erf, const std::vector< byte > &password=std::vector< byte >())
	Take over this stream and read an ERF file out of it. More...

	~ERFFile ()

const ResourceList &	getResources () const
	Return the list of resources. More...

uint32	getResourceSize (uint32 index) const
	Return the size of a resource. More...

Common::SeekableReadStream *	getResource (uint32 index, bool tryNoCopy=false) const
	Return a stream of the resource's contents. More...

uint32	getBuildYear () const
	Return the year the ERF was built. More...

uint32	getBuildDay () const
	Return the day of year the ERF was built. More...

const LocString &	getDescription () const
	Return the description. More...

Common::HashAlgo	getNameHashAlgo () const
	Return with which algorithm the name is hashed. More...

Public Member Functions inherited from Aurora::Archive
	Archive ()

virtual	~Archive ()

uint32	findResource (uint64 hash) const
	Return the index of the resource matching the hash, or 0xFFFFFFFF if not found. More...

uint32	findResource (const Common::UString &name, FileType type) const
	Return the index of the resource matching the name and type, or 0xFFFFFFFF if not found. More...

Public Member Functions inherited from Aurora::AuroraFile
	AuroraFile ()

void	clear ()

uint32	getID () const
	Return the file's ID. More...

uint32	getVersion () const
	Return the file's version. More...

bool	isUTF16LE () const
	Were the ID and version encoded in little-endian UTF-16 in the file? More...

Static Public Member Functions
static LocString	getDescription (Common::SeekableReadStream &erf)

static LocString	getDescription (const Common::UString &fileName)

Static Public Member Functions inherited from Aurora::AuroraFile
static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version, bool &utf16le)
	Read the header out of a stream. More...

static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version)
	Read the ID and version out of a stream. More...

static uint32	readHeaderID (Common::ReadStream &stream)
	Read the ID out of a stream. More...

Private Types
enum	Encryption { kEncryptionNone = 0, kEncryptionXOR = 1, kEncryptionBlowfishDAO = 2, kEncryptionBlowfishDA2 = 3, kEncryptionBlowfishNWN = 16 }

enum	Compression { kCompressionNone = 0, kCompressionBioWareZlib = 1, kCompressionHeaderlessZlib = 7, kCompressionStandardZlib = 8 }

typedef std::vector< IResource >	IResourceList

Private Member Functions
void	load ()

void	readResources (Common::SeekableReadStream &erf, const ERFHeader &header)

void	readV10ResList (Common::SeekableReadStream &erf, const ERFHeader &header)

void	readV10KeyList (Common::SeekableReadStream &erf, const ERFHeader &header)

void	readV11KeyList (Common::SeekableReadStream &erf, const ERFHeader &header)

void	readV20ResList (Common::SeekableReadStream &erf, const ERFHeader &header)

void	readV21ResList (Common::SeekableReadStream &erf, const ERFHeader &header)

void	readV22ResList (Common::SeekableReadStream &erf, const ERFHeader &header)

void	readV30ResList (Common::SeekableReadStream &erf, const ERFHeader &header)

void	verifyPasswordDigest ()

void	decryptNWNPremium ()

Common::SeekableReadStream *	decompress (Common::MemoryReadStream *packedStream, uint32 unpackedSize) const

Common::SeekableReadStream *	decompressBiowareZlib (Common::MemoryReadStream *packedStream, uint32 unpackedSize) const

Common::SeekableReadStream *	decompressHeaderlessZlib (Common::MemoryReadStream *packedStream, uint32 unpackedSize) const

Common::SeekableReadStream *	decompressStandardZlib (Common::MemoryReadStream *packedStream, uint32 unpackedSize) const

Common::SeekableReadStream *	decompressZlib (const byte *compressedData, uint32 packedSize, uint32 unpackedSize, int windowBits) const

const IResource &	getIResource (uint32 index) const

Static Private Member Functions
static void	verifyVersion (uint32 id, uint32 version, bool utf16le)

static void	readERFHeader (Common::SeekableReadStream &erf, ERFHeader &header, uint32 version, std::vector< byte > &password)

static void	readDescription (LocString &description, Common::SeekableReadStream &erf, const ERFHeader &header)

static void	readV10Header (Common::SeekableReadStream &erf, ERFHeader &header)

static void	readV11Header (Common::SeekableReadStream &erf, ERFHeader &header)

static void	readV20Header (Common::SeekableReadStream &erf, ERFHeader &header)

static void	readV21Header (Common::SeekableReadStream &erf, ERFHeader &header)

static void	readV22Header (Common::SeekableReadStream &erf, ERFHeader &header, uint32 &flags)

static void	readV30Header (Common::SeekableReadStream &erf, ERFHeader &header, uint32 &flags)

static Common::MemoryReadStream *	decrypt (Common::SeekableReadStream &cryptStream, Encryption encryption, const std::vector< byte > &password)

static Common::MemoryReadStream *	decrypt (Common::SeekableReadStream *cryptStream, Encryption encryption, const std::vector< byte > &password)

static Common::SeekableReadStream *	decrypt (Common::SeekableReadStream &erf, size_t pos, size_t size, Encryption encryption, const std::vector< byte > &password)

static Common::SeekableReadStream *	decrypt (Common::SeekableReadStream &erf, size_t size, Encryption encryption, const std::vector< byte > &password)

static bool	decryptNWNPremiumHeader (Common::SeekableReadStream &erf, ERFHeader &header, const std::vector< byte > &password)

static bool	findNWNPremiumKey (Common::SeekableReadStream &erf, ERFHeader &header, const std::vector< byte > &md5, std::vector< byte > &password)

static void	readNWNPremiumHeader (Common::SeekableReadStream &erf, ERFHeader &header, std::vector< byte > &password)

Private Attributes
Common::ScopedPtr< Common::SeekableReadStream >	_erf

ERFHeader	_header

LocString	_description
	The ERF's description. More...

ResourceList	_resources
	External list of resource names and types. More...

IResourceList	_iResources
	Internal list of resource offsets and sizes. More...

std::vector< byte >	_password
	The password we were given, if any. More...

Additional Inherited Members
Public Types inherited from Aurora::Archive
typedef std::list< Resource >	ResourceList

Protected Member Functions inherited from Aurora::AuroraFile
void	readHeader (Common::ReadStream &stream)

Static Protected Member Functions inherited from Aurora::AuroraFile
static uint32	convertUTF16LE (uint32 x1, uint32 x2)

Protected Attributes inherited from Aurora::AuroraFile
uint32	_id
	The file's ID. More...

uint32	_version
	The file's version. More...

bool	_utf16le
	The file's ID and version are in little-endian UTF-16. More...

Detailed Description

Class to hold resource data of an ERF archive file.

The ERF file is, together with KEY and BIF files, the most basic and widespread archive archive format used in Aurora engine games. There are several versions with different features.

Supported versions:

1.0:
- Used in Neverwinter Nights, Knights of the Old Republic I and II, Jade Empire and The Witcher
- 16 ASCII characters per resource name
- Extension saved as a Type ID
- Includes a localized description text field
1.1 (variant a):
- Used in BioWare premium modules for Neverwinter Nights
- Blowfish encrypted
- Otherwise, identical to the 1.0 format
1.1 (variant b):
- Used in Neverwinter Nights 2
- 32 ASCII characters per resource name
- Extension saved as a Type ID
- Includes a localized description text field
2.0:
- Used in Dragon Age: Origins (PC)
- 32 UTF-16 characters per resource name
- Resource name includes extension and path
2.1:
- Used in Dragon Age: Origins (Xbox)
- 32 UTF-16 characters per resource name
- Resource name includes extension and path
- DEFLATE compressed
2.2:
- Used in Dragon Age: Origins
- Optionally Blowfish encrypted
- Optionally DEFLATE compressed
- Otherwise, identical to the 2.0 format
3.0:
- Dragon Age II
- Optionally Blowfish encrypted
- Optionally DEFLATE compressed
- Variable amount of ASCII characters per resource name
- Resource name includes extension and path
- Optionally, resource names are stripped in favour of a FNV64 hash of the resource name (including path and extension) and a FNV32 hash of only the extension

Known unsupported features:

XOR encryption as used in versions 2.2 and 3.0

ERF files can have several different file extensions:

.erf: Generic resource archive
.nwm: BioWare original campaign modules
.mod: Community adventure modules
.hak: Additional, shared module resources
.sav: Save games
.crf: Creature resources
.rim: Room resources in the Dragon Age games (Note: in earlier games, .rim are RIM files. See also class RIMFile in rimfile.h.)
.rimp: Patch resources

Definition at line 105 of file erffile.h.

Member Typedef Documentation

◆ IResourceList

typedef std::vector<IResource> Aurora::ERFFile::IResourceList

private

Definition at line 207 of file erffile.h.

Member Enumeration Documentation

◆ Compression

enum Aurora::ERFFile::Compression

private

Enumerator
kCompressionNone	No compression as all.
kCompressionBioWareZlib	Compression using DEFLATE with an extra header byte.
kCompressionHeaderlessZlib	Compression using DEFLATE with default parameters.
kCompressionStandardZlib	Compression using DEFLATE, standard zlib chunk.

Definition at line 155 of file erffile.h.

◆ Encryption

enum Aurora::ERFFile::Encryption

private

Enumerator
kEncryptionNone	No encryption at all.
kEncryptionXOR	XOR encryption as used by V2.2 and V3.0 (UNSUPPORTED!)
kEncryptionBlowfishDAO	Blowfish encryption as used by Dragon Age: Origins (V2.2).
kEncryptionBlowfishDA2	Blowfish encryption as used by Dragon Age II (V3.0).
kEncryptionBlowfishNWN	Blowfish encryption as used by Neverwinter Nights (V1.1).

Definition at line 147 of file erffile.h.

Constructor & Destructor Documentation

◆ ERFFile()

Aurora::ERFFile::ERFFile	(	Common::SeekableReadStream *	erf,
		const std::vector< byte > &	password = `std::vector<byte>()`
	)

Take over this stream and read an ERF file out of it.

When the ERF is encrypted, use this password to decrypt it.

In Dragon Age: Origins and Dragon Age II, each DLC can have a unique password with which many of the DLC's ERF archive are encrypted. This password is used to directly decrypt the archive.

In Neverwinter Nights, each premium module consists of an unencrypted .nwm file and an encrypted .hak file, both of which are ERF archives. In this case, the password is the MD5 of the .nwm file. It is then used to calculate the key to decrypt the .hak file.

Definition at line 150 of file erffile.cpp.

References _erf, and load().

Here is the call graph for this function:

◆ ~ERFFile()

Aurora::ERFFile::~ERFFile ( )

Definition at line 158 of file erffile.cpp.

Member Function Documentation

◆ decompress()

Common::SeekableReadStream * Aurora::ERFFile::decompress	(	Common::MemoryReadStream *	packedStream,
		uint32	unpackedSize
	)		const

private

Definition at line 766 of file erffile.cpp.

References _header, Aurora::ERFFile::ERFHeader::compression, decompressBiowareZlib(), decompressHeaderlessZlib(), decompressStandardZlib(), kCompressionBioWareZlib, kCompressionHeaderlessZlib, kCompressionNone, kCompressionStandardZlib, Common::ScopedPtrBase< T, Deallocator >::release(), and Common::MemoryReadStream::size().

Referenced by getResource().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ decompressBiowareZlib()

Common::SeekableReadStream * Aurora::ERFFile::decompressBiowareZlib	(	Common::MemoryReadStream *	packedStream,
		uint32	unpackedSize
	)		const

private

Definition at line 794 of file erffile.cpp.

References decompressZlib(), Common::MemoryReadStream::getData(), and Common::MemoryReadStream::size().

Referenced by decompress().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ decompressHeaderlessZlib()

Common::SeekableReadStream * Aurora::ERFFile::decompressHeaderlessZlib	(	Common::MemoryReadStream *	packedStream,
		uint32	unpackedSize
	)		const

private

Definition at line 809 of file erffile.cpp.

References decompressZlib(), Common::MemoryReadStream::getData(), Common::kWindowBitsMax, and Common::MemoryReadStream::size().

Referenced by decompress().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ decompressStandardZlib()

Common::SeekableReadStream * Aurora::ERFFile::decompressStandardZlib	(	Common::MemoryReadStream *	packedStream,
		uint32	unpackedSize
	)		const

private

Definition at line 824 of file erffile.cpp.

References decompressZlib(), Common::MemoryReadStream::getData(), Common::kWindowBitsMax, and Common::MemoryReadStream::size().

Referenced by decompress().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ decompressZlib()

Common::SeekableReadStream * Aurora::ERFFile::decompressZlib	(	const byte *	compressedData,
		uint32	packedSize,
		uint32	unpackedSize,
		int	windowBits
	)		const

private

Definition at line 839 of file erffile.cpp.

References Common::decompressDeflate().

Referenced by decompressBiowareZlib(), decompressHeaderlessZlib(), and decompressStandardZlib().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ decrypt() [1/4]

Common::MemoryReadStream * Aurora::ERFFile::decrypt	(	Common::SeekableReadStream &	cryptStream,
		Encryption	encryption,
		const std::vector< byte > &	password
	)

staticprivate

Definition at line 731 of file erffile.cpp.

References Common::decryptBlowfishEBC(), kEncryptionBlowfishDA2, kEncryptionBlowfishDAO, and kEncryptionBlowfishNWN.

Referenced by decrypt(), decryptNWNPremium(), decryptNWNPremiumHeader(), and getResource().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ decrypt() [2/4]

Common::MemoryReadStream * Aurora::ERFFile::decrypt	(	Common::SeekableReadStream *	cryptStream,
		Encryption	encryption,
		const std::vector< byte > &	password
	)

staticprivate

Definition at line 744 of file erffile.cpp.

References decrypt().

Here is the call graph for this function:

◆ decrypt() [3/4]

Common::SeekableReadStream * Aurora::ERFFile::decrypt	(	Common::SeekableReadStream &	erf,
		size_t	pos,
		size_t	size,
		Encryption	encryption,
		const std::vector< byte > &	password
	)

staticprivate

Definition at line 754 of file erffile.cpp.

References decrypt().

Here is the call graph for this function:

◆ decrypt() [4/4]

Common::SeekableReadStream * Aurora::ERFFile::decrypt	(	Common::SeekableReadStream &	erf,
		size_t	size,
		Encryption	encryption,
		const std::vector< byte > &	password
	)

staticprivate

Definition at line 760 of file erffile.cpp.

References decrypt(), and Common::SeekableReadStream::pos().

Here is the call graph for this function:

◆ decryptNWNPremium()

void Aurora::ERFFile::decryptNWNPremium ( )

private

Definition at line 302 of file erffile.cpp.

References _erf, _header, _password, decrypt(), Aurora::ERFFile::ERFHeader::encryption, kEncryptionBlowfishNWN, kEncryptionNone, and Common::ScopedPtrBase< T, Deallocator >::reset().

Referenced by load().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ decryptNWNPremiumHeader()

bool Aurora::ERFFile::decryptNWNPremiumHeader	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header,
		const std::vector< byte > &	password
	)

staticprivate

Definition at line 225 of file erffile.cpp.

References decrypt(), Aurora::ERFFile::ERFHeader::isSensible(), kEncryptionBlowfishNWN, Common::SeekableReadStream::pos(), readV11Header(), and Common::SeekableReadStream::size().

Referenced by findNWNPremiumKey().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ findNWNPremiumKey()

bool Aurora::ERFFile::findNWNPremiumKey	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header,
		const std::vector< byte > &	md5,
		std::vector< byte > &	password
	)

staticprivate

Definition at line 236 of file erffile.cpp.

References ARRAYSIZE, decryptNWNPremiumHeader(), Common::kMD5Length, Aurora::kNWNPremiumKeyLength, Aurora::kNWNPremiumKeys, Common::SeekableReadStream::pos(), and Common::SeekableReadStream::seek().

Referenced by readNWNPremiumHeader().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getBuildDay()

uint32 Aurora::ERFFile::getBuildDay ( ) const

Return the day of year the ERF was built.

Definition at line 689 of file erffile.cpp.

References _header, and Aurora::ERFFile::ERFHeader::buildDay.

◆ getBuildYear()

uint32 Aurora::ERFFile::getBuildYear ( ) const

Return the year the ERF was built.

Definition at line 685 of file erffile.cpp.

References _header, and Aurora::ERFFile::ERFHeader::buildYear.

◆ getDescription() [1/3]

const LocString & Aurora::ERFFile::getDescription ( ) const

Return the description.

Definition at line 693 of file erffile.cpp.

References _description.

Referenced by getDescription(), Engines::NWN::Module::getDescriptionCampaign(), and Engines::NWN::Module::getDescriptionExtra().

Here is the caller graph for this function:

◆ getDescription() [2/3]

LocString Aurora::ERFFile::getDescription ( Common::SeekableReadStream & erf )

static

Definition at line 853 of file erffile.cpp.

References readDescription(), readERFHeader(), Aurora::AuroraFile::readHeader(), and verifyVersion().

Here is the call graph for this function:

◆ getDescription() [3/3]

LocString Aurora::ERFFile::getDescription ( const Common::UString & fileName )

static

Definition at line 875 of file erffile.cpp.

References getDescription().

Here is the call graph for this function:

◆ getIResource()

const ERFFile::IResource & Aurora::ERFFile::getIResource ( uint32 index ) const

private

Definition at line 701 of file erffile.cpp.

References _iResources.

Referenced by getResource(), and getResourceSize().

Here is the caller graph for this function:

◆ getNameHashAlgo()

Common::HashAlgo Aurora::ERFFile::getNameHashAlgo ( ) const

virtual

Return with which algorithm the name is hashed.

Reimplemented from Aurora::Archive.

Definition at line 848 of file erffile.cpp.

References Aurora::AuroraFile::_version, Common::kHashFNV64, Common::kHashNone, and kVersion30.

◆ getResource()

Common::SeekableReadStream * Aurora::ERFFile::getResource	(	uint32	index,
		bool	tryNoCopy = `false`
	)		const

virtual

Return a stream of the resource's contents.

Implements Aurora::Archive.

Definition at line 712 of file erffile.cpp.

References _erf, _header, _password, Aurora::ERFFile::ERFHeader::compression, decompress(), decrypt(), Aurora::ERFFile::ERFHeader::encryption, Common::ScopedPtrBase< T, Deallocator >::get(), getIResource(), kCompressionNone, kEncryptionNone, Aurora::ERFFile::IResource::offset, Aurora::ERFFile::IResource::packedSize, and Aurora::ERFFile::IResource::unpackedSize.

Referenced by Engines::KotOR::SavedGame::fillFromModuleSAV(), Engines::KotOR::SavedGame::fillFromSAV(), Engines::Witcher::Module::getDescription(), and Engines::Witcher::Module::getName().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getResources()

const Archive::ResourceList & Aurora::ERFFile::getResources ( ) const

virtual

Return the list of resources.

Implements Aurora::Archive.

Definition at line 697 of file erffile.cpp.

References _resources.

Referenced by Engines::KotOR::SavedGame::fillFromModuleSAV(), and Engines::KotOR::SavedGame::fillFromSAV().

Here is the caller graph for this function:

◆ getResourceSize()

uint32 Aurora::ERFFile::getResourceSize ( uint32 index ) const

virtual

Return the size of a resource.

Reimplemented from Aurora::Archive.

Definition at line 708 of file erffile.cpp.

References getIResource(), and Aurora::ERFFile::IResource::unpackedSize.

Here is the call graph for this function:

◆ load()

void Aurora::ERFFile::load ( )

private

Definition at line 275 of file erffile.cpp.

References _description, _erf, _header, Aurora::AuroraFile::_id, _password, Aurora::AuroraFile::_utf16le, Aurora::AuroraFile::_version, Common::StackException::add(), Aurora::ERFFile::ERFHeader::clearStringTable(), decryptNWNPremium(), Aurora::ERFFile::ERFHeader::encryption, kEncryptionBlowfishNWN, readDescription(), readERFHeader(), Aurora::AuroraFile::readHeader(), readResources(), verifyPasswordDigest(), and verifyVersion().

Referenced by ERFFile().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readDescription()

void Aurora::ERFFile::readDescription	(	LocString &	description,
		Common::SeekableReadStream &	erf,
		const ERFHeader &	header
	)

staticprivate

Definition at line 499 of file erffile.cpp.

References Aurora::LocString::clear(), Aurora::ERFFile::ERFHeader::descriptionID, Aurora::ERFFile::ERFHeader::encryption, kEncryptionBlowfishNWN, Aurora::ERFFile::ERFHeader::langCount, Aurora::ERFFile::ERFHeader::offDescription, Aurora::LocString::readLocString(), and Common::SeekableReadStream::seek().

Referenced by getDescription(), and load().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readERFHeader()

void Aurora::ERFFile::readERFHeader	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header,
		uint32	version,
		std::vector< byte > &	password
	)

staticprivate

Definition at line 434 of file erffile.cpp.

References Aurora::ERFFile::ERFHeader::clear(), Aurora::ERFFile::ERFHeader::encryption, kEncryptionBlowfishNWN, Aurora::kVersion10, kVersion11, kVersion20, kVersion21, kVersion22, kVersion30, Common::SeekableReadStream::pos(), readNWNPremiumHeader(), readV10Header(), readV11Header(), readV20Header(), readV21Header(), readV22Header(), readV30Header(), and Common::SeekableReadStream::seek().

Referenced by getDescription(), and load().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readNWNPremiumHeader()

void Aurora::ERFFile::readNWNPremiumHeader	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header,
		std::vector< byte > &	password
	)

staticprivate

Definition at line 257 of file erffile.cpp.

References Aurora::ERFFile::ERFHeader::encryption, findNWNPremiumKey(), Aurora::ERFFile::ERFHeader::isNWNPremium, kEncryptionBlowfishNWN, and Common::kMD5Length.

Referenced by readERFHeader().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readResources()

void Aurora::ERFFile::readResources	(	Common::SeekableReadStream &	erf,
		const ERFHeader &	header
	)

private

Definition at line 513 of file erffile.cpp.

References _iResources, _resources, Aurora::AuroraFile::_version, Aurora::ERFFile::ERFHeader::isNWNPremium, Aurora::kVersion10, kVersion11, kVersion20, kVersion21, kVersion22, kVersion30, readV10KeyList(), readV10ResList(), readV11KeyList(), readV20ResList(), readV21ResList(), readV22ResList(), readV30ResList(), and Aurora::ERFFile::ERFHeader::resCount.

Referenced by load().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV10Header()

void Aurora::ERFFile::readV10Header	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header
	)

staticprivate

Definition at line 312 of file erffile.cpp.

References Aurora::ERFFile::ERFHeader::buildDay, Aurora::ERFFile::ERFHeader::buildYear, Aurora::ERFFile::ERFHeader::descriptionID, Aurora::ERFFile::ERFHeader::descriptionSize, Aurora::ERFFile::ERFHeader::langCount, Aurora::ERFFile::ERFHeader::offDescription, Aurora::ERFFile::ERFHeader::offKeyList, Aurora::ERFFile::ERFHeader::offResList, Common::ReadStream::readUint32LE(), Aurora::ERFFile::ERFHeader::resCount, and Common::SeekableReadStream::skip().

Referenced by readERFHeader().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV10KeyList()

void Aurora::ERFFile::readV10KeyList	(	Common::SeekableReadStream &	erf,
		const ERFHeader &	header
	)

private

Definition at line 556 of file erffile.cpp.

References _resources, Common::kEncodingASCII, Aurora::ERFFile::ERFHeader::offKeyList, Common::readStringFixed(), Common::ReadStream::readUint16LE(), Common::SeekableReadStream::seek(), and Common::SeekableReadStream::skip().

Referenced by readResources().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV10ResList()

void Aurora::ERFFile::readV10ResList	(	Common::SeekableReadStream &	erf,
		const ERFHeader &	header
	)

private

Definition at line 582 of file erffile.cpp.

References _iResources, Aurora::ERFFile::ERFHeader::offResList, Common::ReadStream::readUint32LE(), and Common::SeekableReadStream::seek().

Referenced by readResources().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV11Header()

void Aurora::ERFFile::readV11Header	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header
	)

staticprivate

Definition at line 329 of file erffile.cpp.

Referenced by decryptNWNPremiumHeader(), and readERFHeader().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV11KeyList()

void Aurora::ERFFile::readV11KeyList	(	Common::SeekableReadStream &	erf,
		const ERFHeader &	header
	)

private

Definition at line 569 of file erffile.cpp.

References _resources, Common::kEncodingASCII, Aurora::ERFFile::ERFHeader::offKeyList, Common::readStringFixed(), Common::ReadStream::readUint16LE(), Common::SeekableReadStream::seek(), and Common::SeekableReadStream::skip().

Referenced by readResources().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV20Header()

void Aurora::ERFFile::readV20Header	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header
	)

staticprivate

Definition at line 359 of file erffile.cpp.

References Aurora::ERFFile::ERFHeader::buildDay, Aurora::ERFFile::ERFHeader::buildYear, Aurora::ERFFile::ERFHeader::offResList, Common::ReadStream::readUint32LE(), Aurora::ERFFile::ERFHeader::resCount, and Common::SeekableReadStream::skip().

Referenced by readERFHeader().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV20ResList()

void Aurora::ERFFile::readV20ResList	(	Common::SeekableReadStream &	erf,
		const ERFHeader &	header
	)

private

Definition at line 591 of file erffile.cpp.

References _iResources, _resources, Common::kEncodingUTF16LE, Aurora::kFileTypeNone, Aurora::ERFFile::ERFHeader::offResList, Common::readStringFixed(), Common::ReadStream::readUint32LE(), Common::SeekableReadStream::seek(), and TypeMan.

Referenced by readResources().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV21Header()

void Aurora::ERFFile::readV21Header	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header
	)

staticprivate

Definition at line 370 of file erffile.cpp.

References Aurora::ERFFile::ERFHeader::buildDay, Aurora::ERFFile::ERFHeader::buildYear, Aurora::ERFFile::ERFHeader::compression, kCompressionStandardZlib, Aurora::ERFFile::ERFHeader::offResList, Common::ReadStream::readUint16LE(), Common::ReadStream::readUint32LE(), Aurora::ERFFile::ERFHeader::resCount, and Common::SeekableReadStream::skip().

Referenced by readERFHeader().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV21ResList()

void Aurora::ERFFile::readV21ResList	(	Common::SeekableReadStream &	erf,
		const ERFHeader &	header
	)

private

Definition at line 610 of file erffile.cpp.

References _iResources, _resources, Common::kEncodingASCII, Aurora::kFileTypeNone, Aurora::ERFFile::ERFHeader::offResList, Common::readStringFixed(), Common::ReadStream::readUint32LE(), Common::SeekableReadStream::seek(), and TypeMan.

Referenced by readResources().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV22Header()

void Aurora::ERFFile::readV22Header	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header,
		uint32 &	flags
	)

staticprivate

Definition at line 387 of file erffile.cpp.

References Aurora::ERFFile::ERFHeader::buildDay, Aurora::ERFFile::ERFHeader::buildYear, Aurora::ERFFile::ERFHeader::compression, Aurora::ERFFile::ERFHeader::encryption, Common::kMD5Length, Common::kReadError, Aurora::ERFFile::ERFHeader::moduleID, Aurora::ERFFile::ERFHeader::offResList, Aurora::ERFFile::ERFHeader::passwordDigest, Common::ReadStream::read(), Common::ReadStream::readUint32LE(), Aurora::ERFFile::ERFHeader::resCount, and Common::SeekableReadStream::skip().

Referenced by readERFHeader().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV22ResList()

void Aurora::ERFFile::readV22ResList	(	Common::SeekableReadStream &	erf,
		const ERFHeader &	header
	)

private

Definition at line 630 of file erffile.cpp.

References _iResources, _resources, Common::kEncodingUTF16LE, Aurora::kFileTypeNone, Aurora::ERFFile::ERFHeader::offResList, Common::readStringFixed(), Common::ReadStream::readUint32LE(), Common::SeekableReadStream::seek(), and TypeMan.

Referenced by readResources().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV30Header()

void Aurora::ERFFile::readV30Header	(	Common::SeekableReadStream &	erf,
		ERFHeader &	header,
		uint32 &	flags
	)

staticprivate

Definition at line 409 of file erffile.cpp.

Referenced by readERFHeader().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readV30ResList()

void Aurora::ERFFile::readV30ResList	(	Common::SeekableReadStream &	erf,
		const ERFHeader &	header
	)

private

Definition at line 650 of file erffile.cpp.

References _iResources, _resources, Common::ScopedPtrBase< T, Deallocator >::get(), Aurora::kFileTypeNone, Common::kHashFNV32, Aurora::ERFFile::ERFHeader::offResList, Common::ReadStream::readSint32LE(), Common::ReadStream::readUint32LE(), Common::ReadStream::readUint64LE(), Common::SeekableReadStream::seek(), Aurora::ERFFile::ERFHeader::stringTable, Aurora::ERFFile::ERFHeader::stringTableSize, and TypeMan.

Referenced by readResources().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ verifyPasswordDigest()

void Aurora::ERFFile::verifyPasswordDigest ( )

private

Definition at line 174 of file erffile.cpp.

References _header, _password, Common::compareMD5Digest(), Common::encryptBlowfishEBC(), Aurora::ERFFile::ERFHeader::encryption, kEncryptionBlowfishDA2, kEncryptionBlowfishDAO, kEncryptionBlowfishNWN, kEncryptionNone, kEncryptionXOR, Common::parseString(), and Aurora::ERFFile::ERFHeader::passwordDigest.

Referenced by load().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ verifyVersion()

void Aurora::ERFFile::verifyVersion	(	uint32	id,
		uint32	version,
		bool	utf16le
	)

staticprivate

Definition at line 161 of file erffile.cpp.

References Common::debugTag(), kERFID, kHAKID, kMODID, kSAVID, Aurora::kVersion10, kVersion11, kVersion20, kVersion21, kVersion22, and kVersion30.

Referenced by getDescription(), and load().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ _description

LocString Aurora::ERFFile::_description

private

The ERF's description.

Definition at line 214 of file erffile.h.

Referenced by getDescription(), and load().

◆ _erf

Common::ScopedPtr<Common::SeekableReadStream> Aurora::ERFFile::_erf

private

Definition at line 209 of file erffile.h.

Referenced by decryptNWNPremium(), ERFFile(), getResource(), and load().

◆ _header

ERFHeader Aurora::ERFFile::_header

private

Definition at line 211 of file erffile.h.

Referenced by decompress(), decryptNWNPremium(), getBuildDay(), getBuildYear(), getResource(), load(), and verifyPasswordDigest().

◆ _iResources

IResourceList Aurora::ERFFile::_iResources

private

Internal list of resource offsets and sizes.

Definition at line 220 of file erffile.h.

Referenced by getIResource(), readResources(), readV10ResList(), readV20ResList(), readV21ResList(), readV22ResList(), and readV30ResList().

◆ _password

std::vector<byte> Aurora::ERFFile::_password

private

The password we were given, if any.

Definition at line 223 of file erffile.h.

Referenced by decryptNWNPremium(), getResource(), load(), and verifyPasswordDigest().

◆ _resources

ResourceList Aurora::ERFFile::_resources

private

External list of resource names and types.

Definition at line 217 of file erffile.h.

Referenced by getResources(), readResources(), readV10KeyList(), readV11KeyList(), readV20ResList(), readV21ResList(), readV22ResList(), and readV30ResList().

The documentation for this class was generated from the following files:

src/aurora/erffile.h
src/aurora/erffile.cpp

Classes

Public Member Functions

Static Public Member Functions

Private Types

Private Member Functions

Static Private Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Member Typedef Documentation

◆ IResourceList

Member Enumeration Documentation

◆ Compression

◆ Encryption

Constructor & Destructor Documentation

◆ ERFFile()

◆ ~ERFFile()

Member Function Documentation

◆ decompress()

◆ decompressBiowareZlib()

◆ decompressHeaderlessZlib()

◆ decompressStandardZlib()

◆ decompressZlib()

◆ decrypt() [1/4]

◆ decrypt() [2/4]

◆ decrypt() [3/4]

◆ decrypt() [4/4]

◆ decryptNWNPremium()

◆ decryptNWNPremiumHeader()

◆ findNWNPremiumKey()

◆ getBuildDay()

◆ getBuildYear()

◆ getDescription() [1/3]

◆ getDescription() [2/3]

◆ getDescription() [3/3]

◆ getIResource()

◆ getNameHashAlgo()

◆ getResource()

◆ getResources()

◆ getResourceSize()

◆ load()

◆ readDescription()

◆ readERFHeader()

◆ readNWNPremiumHeader()

◆ readResources()

◆ readV10Header()

◆ readV10KeyList()

◆ readV10ResList()

◆ readV11Header()

◆ readV11KeyList()

◆ readV20Header()

◆ readV20ResList()

◆ readV21Header()

◆ readV21ResList()

◆ readV22Header()

◆ readV22ResList()

◆ readV30Header()

◆ readV30ResList()

◆ verifyPasswordDigest()

◆ verifyVersion()

Member Data Documentation

◆ _description

◆ _erf

◆ _header

◆ _iResources

◆ _password

◆ _resources
