Class to hold resource data of a RIM archive file. More...

#include <rimfile.h>

Inheritance diagram for Aurora::RIMFile:

Collaboration diagram for Aurora::RIMFile:

[legend]

Classes
struct	IResource
	Internal resource information. More...

Public Member Functions
	RIMFile (Common::SeekableReadStream *rim)
	Take over this stream and read a RIM file out of it. More...

	~RIMFile ()

const ResourceList &	getResources () const
	Return the list of resources. More...

uint32	getResourceSize (uint32 index) const
	Return the size of a resource. More...

Common::SeekableReadStream *	getResource (uint32 index, bool tryNoCopy=false) const
	Return a stream of the resource's contents. More...

Public Member Functions inherited from Aurora::Archive
	Archive ()

virtual	~Archive ()

virtual Common::HashAlgo	getNameHashAlgo () const
	Return with which algorithm the name is hashed. More...

uint32	findResource (uint64 hash) const
	Return the index of the resource matching the hash, or 0xFFFFFFFF if not found. More...

uint32	findResource (const Common::UString &name, FileType type) const
	Return the index of the resource matching the name and type, or 0xFFFFFFFF if not found. More...

Public Member Functions inherited from Aurora::AuroraFile
	AuroraFile ()

void	clear ()

uint32	getID () const
	Return the file's ID. More...

uint32	getVersion () const
	Return the file's version. More...

bool	isUTF16LE () const
	Were the ID and version encoded in little-endian UTF-16 in the file? More...

Private Types
typedef std::vector< IResource >	IResourceList

Private Member Functions
void	load (Common::SeekableReadStream &rim)

void	readResList (Common::SeekableReadStream &rim, uint32 offset)

const IResource &	getIResource (uint32 index) const

Private Attributes
Common::ScopedPtr< Common::SeekableReadStream >	_rim

ResourceList	_resources
	External list of resource names and types. More...

IResourceList	_iResources
	Internal list of resource offsets and sizes. More...

Additional Inherited Members
Public Types inherited from Aurora::Archive
typedef std::list< Resource >	ResourceList

Static Public Member Functions inherited from Aurora::AuroraFile
static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version, bool &utf16le)
	Read the header out of a stream. More...

static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version)
	Read the ID and version out of a stream. More...

static uint32	readHeaderID (Common::ReadStream &stream)
	Read the ID out of a stream. More...

Protected Member Functions inherited from Aurora::AuroraFile
void	readHeader (Common::ReadStream &stream)

Static Protected Member Functions inherited from Aurora::AuroraFile
static uint32	convertUTF16LE (uint32 x1, uint32 x2)

Protected Attributes inherited from Aurora::AuroraFile
uint32	_id
	The file's ID. More...

uint32	_version
	The file's version. More...

bool	_utf16le
	The file's ID and version are in little-endian UTF-16. More...

Detailed Description

Class to hold resource data of a RIM archive file.

A RIM file is a resource archive, used in several Aurora games. It is a simplified version of the more complex ERF format, lacking the support for a localized description text as found in early ERF formats, as well as compression and encryption as found in later ERF formats.

There is only one single version, V1.0, of the RIM format known and supported. For each resource file, it stores a path- and extension-less name (with a maximum of 16 ASCII characters) and a Type ID.

RIM files are found in Knights of the Old Republic, Knights of the Old Republic II and Jade Empire. They always have the .rim extension.

Note: .rim files in the Dragon Age games are not real RIM files. Instead, they are ERF files. See class ERFFile in erffile.h.

Definition at line 61 of file rimfile.h.
