An NCS, BioWare's NWN Compile Script. More...

#include <ncsfile.h>

Inheritance diagram for Aurora::NWScript::NCSFile:

Collaboration diagram for Aurora::NWScript::NCSFile:

[legend]

Classes
struct	Opcode

Public Member Functions
	NCSFile (Common::SeekableReadStream *ncs)

	NCSFile (const Common::UString &ncs)

	~NCSFile ()

const Common::UString &	getName () const

VariableContainer &	getEnvironment ()
	Return the script's environment variables. More...

void	setEnvironment (const VariableContainer &env)
	Overwrite the environment. More...

const Variable &	run (Object owner=0, Object triggerer=0)
	Run the current script, from start to finish. More...

const Variable &	run (const ObjectReference owner=ObjectReference(), const ObjectReference triggerer=ObjectReference())

const Variable &	run (const ScriptState &state, Object owner=0, Object triggerer=0)
	Run the current script, from this state to finish. More...

const Variable &	run (const ScriptState &state, const ObjectReference owner=ObjectReference(), const ObjectReference triggerer=ObjectReference())

Public Member Functions inherited from Aurora::AuroraFile
	AuroraFile ()

void	clear ()

uint32	getID () const
	Return the file's ID. More...

uint32	getVersion () const
	Return the file's version. More...

bool	isUTF16LE () const
	Were the ID and version encoded in little-endian UTF-16 in the file? More...

Static Public Member Functions
static ScriptState	getEmptyState ()

Static Public Member Functions inherited from Aurora::AuroraFile
static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version, bool &utf16le)
	Read the header out of a stream. More...

static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version)
	Read the ID and version out of a stream. More...

static uint32	readHeaderID (Common::ReadStream &stream)
	Read the ID out of a stream. More...

Private Types
enum	InstructionType { kInstTypeNone = 0, kInstTypeDirect = 1, kInstTypeInt = 3, kInstTypeFloat = 4, kInstTypeString = 5, kInstTypeObject = 6, kInstTypeResource = 96, kInstTypeEngineType0 = 16, kInstTypeEngineType1 = 17, kInstTypeEngineType2 = 18, kInstTypeEngineType3 = 19, kInstTypeEngineType4 = 20, kInstTypeEngineType5 = 21, kInstTypeIntArray = 64, kInstTypeFloatArray = 65, kInstTypeStringArray = 66, kInstTypeObjectArray = 67, kInstTypeResourceArray = 68, kInstTypeEngineType0Array = 80, kInstTypeEngineType1Array = 81, kInstTypeEngineType2Array = 82, kInstTypeEngineType3Array = 83, kInstTypeEngineType4Array = 84, kInstTypeEngineType5Array = 85, kInstTypeIntInt = 32, kInstTypeFloatFloat = 33, kInstTypeObjectObject = 34, kInstTypeStringString = 35, kInstTypeStructStruct = 36, kInstTypeIntFloat = 37, kInstTypeFloatInt = 38, kInstTypeEngineType0EngineType0 = 48, kInstTypeEngineType1EngineType1 = 49, kInstTypeEngineType2EngineType2 = 50, kInstTypeEngineType3EngineType3 = 51, kInstTypeEngineType4EngineType4 = 52, kInstTypeEngineType5EngineType5 = 53, kInstTypeVectorVector = 58, kInstTypeVectorFloat = 59, kInstTypeFloatVector = 60 }

typedef void(NCSFile::*	OpcodeProc) (InstructionType type)

Private Member Functions
void	setupOpcodes ()

void	load ()

void	reset ()
	Reset the script for another execution. More...

const Variable &	execute (const ObjectReference owner=ObjectReference(), const ObjectReference triggerer=ObjectReference())

bool	executeStep ()
	Execute one script step. More...

void	decompile ()

void	callEngine (Aurora::NWScript::FunctionContext &ctx, uint32 function, uint8 argCount)
	Helper function for o_action(), doing the actual engine function calling. More...

void	o_nop (InstructionType type)
	NOP: no operation. More...

void	o_cpdownsp (InstructionType type)
	CPDOWNSP: copy a value into an existing stack element. More...

void	o_rsadd (InstructionType type)
	RSADD: push an empty variable onto the stack. More...

void	o_cptopsp (InstructionType type)
	CPTOPSP: push a copy of a stack element on top of the stack. More...

void	o_const (InstructionType type)
	CONST: push a constant (predetermined value) variable onto the stack. More...

void	o_action (InstructionType type)
	ACTION: call a game-specific engine function. More...

void	o_logand (InstructionType type)
	LOGAND: perform a logical boolean AND (&&). More...

void	o_logor (InstructionType type)
	LOGOR: perform a logical boolean OR (\|\|). More...

void	o_incor (InstructionType type)
	INCOR: perform a bit-wise inclusive OR (\|). More...

void	o_excor (InstructionType type)
	EXCOR: perform a bit-wise exclusive OR (^). More...

void	o_booland (InstructionType type)
	BOOLAND: perform a bit-wise AND (&). More...

void	o_eq (InstructionType type)
	EQ: compare the top-most stack elements for equality (==). More...

void	o_neq (InstructionType type)
	NEQ: compare the top-most stack elements for inequality (!=). More...

void	o_geq (InstructionType type)
	GEQ: compare the top-most stack elements, greater-or-equal (>=). More...

void	o_gt (InstructionType type)
	GT: compare the top-most stack elements, greater (>). More...

void	o_lt (InstructionType type)
	LT: compare the top-most stack elements, less (<). More...

void	o_leq (InstructionType type)
	LEQ: compare the top-most stack elements, less-or-equal (<=). More...

void	o_shleft (InstructionType type)
	SHLEFT: shift the top-most stack element to the left (<<). More...

void	o_shright (InstructionType type)
	SHRIGHT: signed-shift the top-most stack element to the right (>>>). More...

void	o_ushright (InstructionType type)
	USHRIGHT: shift the top-most stack element to the right (>>). More...

void	o_add (InstructionType type)
	ADD: add the top-most stack elements (+). More...

void	o_sub (InstructionType type)
	SUB: subtract the top-most stack elements (-). More...

void	o_mul (InstructionType type)
	MUL: multiply the top-most stack elements (*). More...

void	o_div (InstructionType type)
	DIV: divide the top-most stack elements (/). More...

void	o_mod (InstructionType type)
	MOD: calculate the remainder (modulo) of an integer division (%). More...

void	o_neg (InstructionType type)
	NEQ: negate the top-most stack element (unary -). More...

void	o_comp (InstructionType type)
	COMP: calculate the 1-complement of the top-most stack element (~). More...

void	o_movsp (InstructionType type)
	MOVSP: pop elements off the stack. More...

void	o_storestateall (InstructionType type)
	STORESTATEALL: unused, obsolete opcode. More...

void	o_jmp (InstructionType type)
	JMP: jump directly to a different script offset. More...

void	o_jsr (InstructionType type)
	JSR: call a subroutine. More...

void	o_jz (InstructionType type)
	JZ: jump conditionally if the top-most stack element is 0. More...

void	o_retn (InstructionType type)
	RETN: return from a subroutine call. More...

void	o_destruct (InstructionType type)
	DESTRUCT: remove elements from the stack. More...

void	o_not (InstructionType type)
	NOT: boolean-negate the top-most stack element (!). More...

void	o_decsp (InstructionType type)
	DECSP: decrement the value of a stack element (–). More...

void	o_incsp (InstructionType type)
	INCSP: increment the value of a stack element (++). More...

void	o_jnz (InstructionType type)
	JNZ: jump conditionally if the top-most stack element is not 0. More...

void	o_cpdownbp (InstructionType type)
	CPDOWNBP: copy a value into an existing base-pointer stack element. More...

void	o_cptopbp (InstructionType type)
	CPTOPBP: push a copy of a base-pointer stack element on top of the stack. More...

void	o_decbp (InstructionType type)
	DECBP: decrement the value of a base-pointer stack element (–). More...

void	o_incbp (InstructionType type)
	INCBP: increment the value of a base-pointer stack element (++). More...

void	o_savebp (InstructionType type)
	SAVEBP: set the value of the base-pointer. More...

void	o_restorebp (InstructionType type)
	RESTOREBP: restore the value of the base-pointer to a prior value. More...

void	o_storestate (InstructionType type)
	STORESTATE: create a functor of a subroutine with the current stack. More...

void	o_writearray (InstructionType type)
	WRITEARRAY: write the value of an array element on the stack. More...

void	o_readarray (InstructionType type)
	READARRAY: push the value of an array element onto of the stack. More...

void	o_getref (InstructionType type)
	GETREF: push the reference to a stack element onto the stack. More...

void	o_getrefarray (InstructionType type)
	GETREFARRAY: push the reference to an array element onto the stack. More...

Private Attributes
Common::UString	_name

NCSStack	_stack

Common::ScopedPtr< Common::SeekableReadStream >	_script

Variable	_return

ObjectReference	_owner

ObjectReference	_triggerer

VariableContainer	_env

std::stack< uint32 >	_returnOffsets

Variable	_storedState

const Opcode *	_opcodes

size_t	_opcodeListSize

Additional Inherited Members
Protected Member Functions inherited from Aurora::AuroraFile
void	readHeader (Common::ReadStream &stream)

Static Protected Member Functions inherited from Aurora::AuroraFile
static uint32	convertUTF16LE (uint32 x1, uint32 x2)

Protected Attributes inherited from Aurora::AuroraFile
uint32	_id
	The file's ID. More...

uint32	_version
	The file's version. More...

bool	_utf16le
	The file's ID and version are in little-endian UTF-16. More...

Detailed Description

An NCS, BioWare's NWN Compile Script.

Definition at line 86 of file ncsfile.h.

Member Typedef Documentation

◆ OpcodeProc

typedef void(NCSFile::* Aurora::NWScript::NCSFile::OpcodeProc) (InstructionType type)

private

Definition at line 183 of file ncsfile.h.

Member Enumeration Documentation

◆ InstructionType

enum Aurora::NWScript::NCSFile::InstructionType

private

Enumerator
kInstTypeNone
kInstTypeDirect
kInstTypeInt
kInstTypeFloat
kInstTypeString
kInstTypeObject
kInstTypeResource
kInstTypeEngineType0
kInstTypeEngineType1
kInstTypeEngineType2
kInstTypeEngineType3
kInstTypeEngineType4
kInstTypeEngineType5
kInstTypeIntArray
kInstTypeFloatArray
kInstTypeStringArray
kInstTypeObjectArray
kInstTypeResourceArray
kInstTypeEngineType0Array
kInstTypeEngineType1Array
kInstTypeEngineType2Array
kInstTypeEngineType3Array
kInstTypeEngineType4Array
kInstTypeEngineType5Array
kInstTypeIntInt
kInstTypeFloatFloat
kInstTypeObjectObject
kInstTypeStringString
kInstTypeStructStruct
kInstTypeIntFloat
kInstTypeFloatInt
kInstTypeEngineType0EngineType0
kInstTypeEngineType1EngineType1
kInstTypeEngineType2EngineType2
kInstTypeEngineType3EngineType3
kInstTypeEngineType4EngineType4
kInstTypeEngineType5EngineType5
kInstTypeVectorVector
kInstTypeVectorFloat
kInstTypeFloatVector

Definition at line 119 of file ncsfile.h.

Constructor & Destructor Documentation

◆ NCSFile() [1/2]

Aurora::NWScript::NCSFile::NCSFile ( Common::SeekableReadStream * ncs )

Definition at line 277 of file ncsfile.cpp.

References _script, and load().

Here is the call graph for this function:

◆ NCSFile() [2/2]

Aurora::NWScript::NCSFile::NCSFile ( const Common::UString & ncs )

Definition at line 283 of file ncsfile.cpp.

References _script, Common::UString::c_str(), Aurora::kFileTypeNCS, load(), Common::ScopedPtrBase< T, Deallocator >::reset(), and ResMan.

Here is the call graph for this function:

◆ ~NCSFile()

Aurora::NWScript::NCSFile::~NCSFile ( )

Definition at line 291 of file ncsfile.cpp.

Member Function Documentation

◆ callEngine()

void Aurora::NWScript::NCSFile::callEngine	(	Aurora::NWScript::FunctionContext &	ctx,
		uint32	function,
		uint8	argCount
	)

private

Helper function for o_action(), doing the actual engine function calling.

Definition at line 529 of file ncsfile.cpp.

Referenced by o_action().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ decompile()

void Aurora::NWScript::NCSFile::decompile ( )

private

Definition at line 428 of file ncsfile.cpp.

References _script.

◆ execute()

const Variable & Aurora::NWScript::NCSFile::execute	(	const ObjectReference	owner = `ObjectReference()`,
		const ObjectReference	triggerer = `ObjectReference()`
	)

private

Definition at line 384 of file ncsfile.cpp.

References _name, _owner, _return, _stack, _triggerer, Common::UString::c_str(), debugC(), Aurora::NWScript::NCSStack::empty(), executeStep(), Aurora::NWScript::Variable::getInt(), Aurora::NWScript::Variable::getType(), Common::kDebugScripts, Aurora::NWScript::kTypeInt, and Aurora::NWScript::NCSStack::top().

Referenced by run().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ executeStep()

bool Aurora::NWScript::NCSFile::executeStep ( )

private

Execute one script step.

Definition at line 404 of file ncsfile.cpp.

References _opcodeListSize, _opcodes, _returnOffsets, _script, _stack, debugC(), Common::kDebugScripts, Aurora::NWScript::NCSStack::print(), and Aurora::NWScript::NCSFile::Opcode::proc.

Referenced by execute().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getEmptyState()

ScriptState Aurora::NWScript::NCSFile::getEmptyState ( )

static

Definition at line 306 of file ncsfile.cpp.

References Aurora::NWScript::ScriptState::offset.

Referenced by run(), Engines::Witcher::ScriptContainer::runScript(), Engines::Jade::ScriptContainer::runScript(), Engines::NWN::ScriptContainer::runScript(), Engines::NWN2::ScriptContainer::runScript(), Engines::KotOR::ScriptContainer::runScript(), Engines::KotOR2::ScriptContainer::runScript(), Engines::DragonAge::ScriptContainer::runScript(), and Engines::DragonAge2::ScriptContainer::runScript().

Here is the caller graph for this function:

◆ getEnvironment()

VariableContainer & Aurora::NWScript::NCSFile::getEnvironment ( )

Return the script's environment variables.

Environment variables can be set by script engine functions and will persist for the whole run of the script. Similar to an environment in a UNIX shell, if the script spawns off a second script, that child script will inherit the environment of its parent script.

Definition at line 298 of file ncsfile.cpp.

References _env.

Referenced by Aurora::NWScript::FunctionContext::getCurrentEnvironment(), Engines::DragonAge2::ScriptContainer::runScript(), and Engines::DragonAge::ScriptContainer::runScript().

Here is the caller graph for this function:

◆ getName()

const Common::UString & Aurora::NWScript::NCSFile::getName ( ) const

Definition at line 294 of file ncsfile.cpp.

References _name.

Referenced by Engines::DragonAge::Functions::getCurrentScriptName(), Engines::DragonAge2::Functions::getCurrentScriptName(), Engines::DragonAge2::Functions::getCurrentScriptResource(), Engines::DragonAge::Functions::getCurrentScriptResource(), and Aurora::NWScript::FunctionContext::getScriptName().

Here is the caller graph for this function:

◆ load()

void Aurora::NWScript::NCSFile::load ( )

private

Definition at line 314 of file ncsfile.cpp.

References Aurora::AuroraFile::_id, _script, Aurora::AuroraFile::_version, kNCSTag, Aurora::kVersion10, Aurora::AuroraFile::readHeader(), reset(), setupOpcodes(), and warning().

Referenced by NCSFile().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_action()

void Aurora::NWScript::NCSFile::o_action ( InstructionType type )

private

ACTION: call a game-specific engine function.

Definition at line 625 of file ncsfile.cpp.

References _script, Common::StackException::add(), Common::UString::c_str(), callEngine(), FunctionMan, Aurora::NWScript::FunctionContext::getName(), and kInstTypeNone.

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_add()

void Aurora::NWScript::NCSFile::o_add ( InstructionType type )

private

ADD: add the top-most stack elements (+).

Definition at line 1088 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getFloat(), Aurora::NWScript::Variable::getInt(), Aurora::NWScript::Variable::getString(), kInstTypeFloatFloat, kInstTypeFloatInt, kInstTypeIntFloat, kInstTypeIntInt, kInstTypeStringString, kInstTypeVectorVector, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_booland()

void Aurora::NWScript::NCSFile::o_booland ( InstructionType type )

private

BOOLAND: perform a bit-wise AND (&).

Definition at line 684 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_comp()

void Aurora::NWScript::NCSFile::o_comp ( InstructionType type )

private

COMP: calculate the 1-complement of the top-most stack element (~).

Definition at line 926 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_const()

void Aurora::NWScript::NCSFile::o_const ( InstructionType type )

private

CONST: push a constant (predetermined value) variable onto the stack.

Definition at line 482 of file ncsfile.cpp.

References _owner, _script, _stack, Common::kEncodingASCII, kInstTypeFloat, kInstTypeInt, kInstTypeObject, kInstTypeResource, kInstTypeString, kScriptObjectInvalid, kScriptObjectInvalid2, kScriptObjectSelf, kScriptObjectTypeInvalid, Aurora::NWScript::NCSStack::push(), and Common::readStringFixed().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_cpdownbp()

void Aurora::NWScript::NCSFile::o_cpdownbp ( InstructionType type )

private

CPDOWNBP: copy a value into an existing base-pointer stack element.

Used to write into a global variable.

Definition at line 1423 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::NCSStack::getRelSP(), kInstTypeDirect, and Aurora::NWScript::NCSStack::setRelBP().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_cpdownsp()

void Aurora::NWScript::NCSFile::o_cpdownsp ( InstructionType type )

private

CPDOWNSP: copy a value into an existing stack element.

Definition at line 1049 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::NCSStack::getRelSP(), kInstTypeDirect, and Aurora::NWScript::NCSStack::setRelSP().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_cptopbp()

void Aurora::NWScript::NCSFile::o_cptopbp ( InstructionType type )

private

CPTOPBP: push a copy of a base-pointer stack element on top of the stack.

Used to read from a global variable.

Definition at line 1447 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::NCSStack::getRelBP(), kInstTypeDirect, and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_cptopsp()

void Aurora::NWScript::NCSFile::o_cptopsp ( InstructionType type )

private

CPTOPSP: push a copy of a stack element on top of the stack.

Definition at line 1070 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::NCSStack::getRelSP(), kInstTypeDirect, and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_decbp()

void Aurora::NWScript::NCSFile::o_decbp ( InstructionType type )

private

DECBP: decrement the value of a base-pointer stack element (–).

Definition at line 1001 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::Variable::getInt(), Aurora::NWScript::NCSStack::getRelBP(), kInstTypeInt, and Aurora::NWScript::NCSStack::setRelBP().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_decsp()

void Aurora::NWScript::NCSFile::o_decsp ( InstructionType type )

private

DECSP: decrement the value of a stack element (–).

Definition at line 970 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::Variable::getInt(), Aurora::NWScript::NCSStack::getRelSP(), kInstTypeInt, and Aurora::NWScript::NCSStack::setRelSP().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_destruct()

void Aurora::NWScript::NCSFile::o_destruct ( InstructionType type )

private

DESTRUCT: remove elements from the stack.

Used to isolate struct elements.

Definition at line 1389 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::NCSStack::pop(), Aurora::NWScript::NCSStack::push(), and Aurora::NWScript::NCSStack::top().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_div()

void Aurora::NWScript::NCSFile::o_div ( InstructionType type )

private

DIV: divide the top-most stack elements (/).

Definition at line 1268 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getFloat(), Aurora::NWScript::Variable::getInt(), INT32_MIN, kInstTypeFloatFloat, kInstTypeFloatInt, kInstTypeFloatVector, kInstTypeIntFloat, kInstTypeIntInt, kInstTypeVectorFloat, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_eq()

void Aurora::NWScript::NCSFile::o_eq ( InstructionType type )

private

EQ: compare the top-most stack elements for equality (==).

Definition at line 694 of file ncsfile.cpp.

References _script, _stack, kInstTypeStructStruct, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_excor()

void Aurora::NWScript::NCSFile::o_excor ( InstructionType type )

private

EXCOR: perform a bit-wise exclusive OR (^).

Definition at line 674 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_geq()

void Aurora::NWScript::NCSFile::o_geq ( InstructionType type )

private

GEQ: compare the top-most stack elements, greater-or-equal (>=).

Definition at line 752 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getFloat(), Aurora::NWScript::Variable::getInt(), kInstTypeFloatFloat, kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_getref()

void Aurora::NWScript::NCSFile::o_getref ( InstructionType type )

private

GETREF: push the reference to a stack element onto the stack.

Creates a reference to a variable, usually an engine type like Event or Effect, so that it can be modified by an engine function directly, without having to create a modified copy. Added with Dragon Age II.

The offset to the variable to create a reference to is passed as a direct argument to the instruction.

Definition at line 1573 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::NCSStack::getRelSP(), kInstTypeDirect, Aurora::NWScript::kTypeReference, Aurora::NWScript::NCSStack::push(), Aurora::NWScript::Variable::setReference(), and Aurora::NWScript::NCSStack::top().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_getrefarray()

void Aurora::NWScript::NCSFile::o_getrefarray ( InstructionType type )

private

GETREFARRAY: push the reference to an array element onto the stack.

Like GETREF, this creates a reference to a variable, usually an engine type like Event or Effect, so that it can be modified by an engine function directly, without having to create a modified copy. GETREFARRAY, however, create a reference to a variable held inside a dynamic array variable. Added with Dragon Age II.

The index of the array is at the top-most stack position; the offset to the array variable is passed as a direct argument to the instruction.

The index is popped off the stack, and the reference to the variable inside the array is pushed on top.

Definition at line 1604 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::Variable::getArray(), Aurora::NWScript::Variable::getInt(), Aurora::NWScript::NCSStack::getRelSP(), kInstTypeDirect, Aurora::NWScript::kTypeReference, Aurora::NWScript::NCSStack::pop(), Aurora::NWScript::NCSStack::push(), Aurora::NWScript::Variable::setReference(), and Aurora::NWScript::NCSStack::top().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_gt()

void Aurora::NWScript::NCSFile::o_gt ( InstructionType type )

private

GT: compare the top-most stack elements, greater (>).

Definition at line 776 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getFloat(), Aurora::NWScript::Variable::getInt(), kInstTypeFloatFloat, kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_incbp()

void Aurora::NWScript::NCSFile::o_incbp ( InstructionType type )

private

INCBP: increment the value of a base-pointer stack element (++).

Definition at line 1011 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::Variable::getInt(), Aurora::NWScript::NCSStack::getRelBP(), kInstTypeInt, and Aurora::NWScript::NCSStack::setRelBP().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_incor()

void Aurora::NWScript::NCSFile::o_incor ( InstructionType type )

private

INCOR: perform a bit-wise inclusive OR (|).

Definition at line 664 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_incsp()

void Aurora::NWScript::NCSFile::o_incsp ( InstructionType type )

private

INCSP: increment the value of a stack element (++).

Definition at line 980 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::Variable::getInt(), Aurora::NWScript::NCSStack::getRelSP(), kInstTypeInt, and Aurora::NWScript::NCSStack::setRelSP().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_jmp()

void Aurora::NWScript::NCSFile::o_jmp ( InstructionType type )

private

JMP: jump directly to a different script offset.

Definition at line 942 of file ncsfile.cpp.

References _script, and kInstTypeNone.

Referenced by setupOpcodes().

Here is the caller graph for this function:

◆ o_jnz()

void Aurora::NWScript::NCSFile::o_jnz ( InstructionType type )

private

JNZ: jump conditionally if the top-most stack element is not 0.

Definition at line 990 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::Variable::getInt(), kInstTypeNone, and Aurora::NWScript::NCSStack::pop().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_jsr()

void Aurora::NWScript::NCSFile::o_jsr ( InstructionType type )

private

JSR: call a subroutine.

Definition at line 1362 of file ncsfile.cpp.

References _returnOffsets, _script, and kInstTypeNone.

Referenced by setupOpcodes().

Here is the caller graph for this function:

◆ o_jz()

void Aurora::NWScript::NCSFile::o_jz ( InstructionType type )

private

JZ: jump conditionally if the top-most stack element is 0.

Definition at line 951 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::Variable::getInt(), kInstTypeNone, and Aurora::NWScript::NCSStack::pop().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_leq()

void Aurora::NWScript::NCSFile::o_leq ( InstructionType type )

private

LEQ: compare the top-most stack elements, less-or-equal (<=).

Definition at line 824 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getFloat(), Aurora::NWScript::Variable::getInt(), kInstTypeFloatFloat, kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_logand()

void Aurora::NWScript::NCSFile::o_logand ( InstructionType type )

private

LOGAND: perform a logical boolean AND (&&).

Definition at line 644 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_logor()

void Aurora::NWScript::NCSFile::o_logor ( InstructionType type )

private

LOGOR: perform a logical boolean OR (||).

Definition at line 654 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_lt()

void Aurora::NWScript::NCSFile::o_lt ( InstructionType type )

private

LT: compare the top-most stack elements, less (<).

Definition at line 800 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getFloat(), Aurora::NWScript::Variable::getInt(), kInstTypeFloatFloat, kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_mod()

void Aurora::NWScript::NCSFile::o_mod ( InstructionType type )

private

MOD: calculate the remainder (modulo) of an integer division (%).

Definition at line 894 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_movsp()

void Aurora::NWScript::NCSFile::o_movsp ( InstructionType type )

private

MOVSP: pop elements off the stack.

Definition at line 934 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::NCSStack::getStackPtr(), kInstTypeNone, and Aurora::NWScript::NCSStack::setStackPtr().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_mul()

void Aurora::NWScript::NCSFile::o_mul ( InstructionType type )

private

MUL: multiply the top-most stack elements (*).

Definition at line 1204 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getFloat(), Aurora::NWScript::Variable::getInt(), kInstTypeFloatFloat, kInstTypeFloatInt, kInstTypeFloatVector, kInstTypeIntFloat, kInstTypeIntInt, kInstTypeVectorFloat, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_neg()

void Aurora::NWScript::NCSFile::o_neg ( InstructionType type )

private

NEQ: negate the top-most stack element (unary -).

Definition at line 910 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getFloat(), Aurora::NWScript::Variable::getInt(), kInstTypeFloat, kInstTypeInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_neq()

void Aurora::NWScript::NCSFile::o_neq ( InstructionType type )

private

NEQ: compare the top-most stack elements for inequality (!=).

Definition at line 723 of file ncsfile.cpp.

References _script, _stack, kInstTypeStructStruct, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_nop()

void Aurora::NWScript::NCSFile::o_nop ( InstructionType type )

private

NOP: no operation.

Definition at line 1044 of file ncsfile.cpp.

Referenced by setupOpcodes().

Here is the caller graph for this function:

◆ o_not()

void Aurora::NWScript::NCSFile::o_not ( InstructionType type )

private

NOT: boolean-negate the top-most stack element (!).

Definition at line 962 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_readarray()

void Aurora::NWScript::NCSFile::o_readarray ( InstructionType type )

private

READARRAY: push the value of an array element onto of the stack.

Reads out of the dynamic array variables types added with Dragon Age: Origins.

The index of the array to read is at the top-most stack position; the offset to the array variable is passed as a direct argument to the instruction.

The index is popped off the stack, and the value read out of the array is pushed on top.

Definition at line 1541 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::Variable::getArray(), Aurora::NWScript::Variable::getInt(), Aurora::NWScript::NCSStack::getRelSP(), kInstTypeDirect, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_restorebp()

void Aurora::NWScript::NCSFile::o_restorebp ( InstructionType type )

private

RESTOREBP: restore the value of the base-pointer to a prior value.

Destroy the global variables anchor point after use.

Definition at line 1036 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeNone, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::setBasePtr().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_retn()

void Aurora::NWScript::NCSFile::o_retn ( InstructionType type )

private

RETN: return from a subroutine call.

Definition at line 1375 of file ncsfile.cpp.

References _returnOffsets, and _script.

Referenced by setupOpcodes().

Here is the caller graph for this function:

◆ o_rsadd()

void Aurora::NWScript::NCSFile::o_rsadd ( InstructionType type )

private

RSADD: push an empty variable onto the stack.

Definition at line 440 of file ncsfile.cpp.

References _stack, kInstTypeEngineType0, kInstTypeEngineType0Array, kInstTypeEngineType1, kInstTypeEngineType1Array, kInstTypeEngineType2, kInstTypeEngineType2Array, kInstTypeEngineType3, kInstTypeEngineType3Array, kInstTypeEngineType4, kInstTypeEngineType4Array, kInstTypeEngineType5, kInstTypeEngineType5Array, kInstTypeFloat, kInstTypeFloatArray, kInstTypeInt, kInstTypeIntArray, kInstTypeObject, kInstTypeObjectArray, kInstTypeResource, kInstTypeResourceArray, kInstTypeString, kInstTypeStringArray, Aurora::NWScript::kTypeArray, Aurora::NWScript::kTypeEngineType, Aurora::NWScript::kTypeFloat, Aurora::NWScript::kTypeInt, Aurora::NWScript::kTypeObject, Aurora::NWScript::kTypeString, and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_savebp()

void Aurora::NWScript::NCSFile::o_savebp ( InstructionType type )

private

SAVEBP: set the value of the base-pointer.

Used to create an anchor point to access global variables.

Definition at line 1024 of file ncsfile.cpp.

References _stack, Aurora::NWScript::NCSStack::getBasePtr(), Aurora::NWScript::NCSStack::getStackPtr(), kInstTypeNone, Aurora::NWScript::NCSStack::push(), and Aurora::NWScript::NCSStack::setBasePtr().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_shleft()

void Aurora::NWScript::NCSFile::o_shleft ( InstructionType type )

private

SHLEFT: shift the top-most stack element to the left (<<).

Definition at line 848 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_shright()

void Aurora::NWScript::NCSFile::o_shright ( InstructionType type )

private

SHRIGHT: signed-shift the top-most stack element to the right (>>>).

Definition at line 858 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_storestate()

void Aurora::NWScript::NCSFile::o_storestate ( InstructionType type )

private

STORESTATE: create a functor of a subroutine with the current stack.

Used to create the "action" variables when calling an engine function that assigns a function to an object, or delays a function, or similar.

Definition at line 1470 of file ncsfile.cpp.

References _script, _stack, _storedState, Aurora::NWScript::NCSStack::getRelBP(), Aurora::NWScript::NCSStack::getRelSP(), Aurora::NWScript::Variable::getScriptState(), Aurora::NWScript::ScriptState::globals, Aurora::NWScript::kTypeScriptState, Aurora::NWScript::ScriptState::locals, Aurora::NWScript::ScriptState::offset, and Aurora::NWScript::Variable::setType().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_storestateall()

void Aurora::NWScript::NCSFile::o_storestateall ( InstructionType type )

private

STORESTATEALL: unused, obsolete opcode.

Hopefully.

Definition at line 1353 of file ncsfile.cpp.

References warning().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_sub()

void Aurora::NWScript::NCSFile::o_sub ( InstructionType type )

private

SUB: subtract the top-most stack elements (-).

Definition at line 1150 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getFloat(), Aurora::NWScript::Variable::getInt(), kInstTypeFloatFloat, kInstTypeFloatInt, kInstTypeIntFloat, kInstTypeIntInt, kInstTypeVectorVector, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_ushright()

void Aurora::NWScript::NCSFile::o_ushright ( InstructionType type )

private

USHRIGHT: shift the top-most stack element to the right (>>).

Definition at line 879 of file ncsfile.cpp.

References _stack, Aurora::NWScript::Variable::getInt(), kInstTypeIntInt, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::push().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ o_writearray()

void Aurora::NWScript::NCSFile::o_writearray ( InstructionType type )

private

WRITEARRAY: write the value of an array element on the stack.

Writes into the dynamic array variables types added with Dragon Age: Origins.

The index of the array to write and the value to write are at the top-most stack position; the offset to the array variable is passed as a direct argument to the instruction.

The index is popped off the stack, but the value written remains.

Definition at line 1506 of file ncsfile.cpp.

References _script, _stack, Aurora::NWScript::Variable::getArray(), Aurora::NWScript::Variable::getInt(), Aurora::NWScript::NCSStack::getRelSP(), Aurora::NWScript::Variable::getType(), Aurora::NWScript::Variable::growArray(), kInstTypeDirect, Aurora::NWScript::NCSStack::pop(), and Aurora::NWScript::NCSStack::top().

Referenced by setupOpcodes().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ reset()

void Aurora::NWScript::NCSFile::reset ( )

private

Reset the script for another execution.

Definition at line 338 of file ncsfile.cpp.

References _return, _returnOffsets, _script, _stack, _storedState, Aurora::NWScript::kTypeVoid, Aurora::NWScript::NCSStack::reset(), and Aurora::NWScript::Variable::setType().

Referenced by load(), and run().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ run() [1/4]

const Variable & Aurora::NWScript::NCSFile::run	(	Object *	owner = `0`,
		Object *	triggerer = `0`
	)

Run the current script, from start to finish.

Definition at line 350 of file ncsfile.cpp.

References getEmptyState().

Referenced by Engines::Witcher::Functions::executeScript(), Engines::Jade::Functions::executeScript(), Engines::NWN::Functions::executeScript(), Engines::NWN2::Functions::executeScript(), run(), Engines::Witcher::ScriptContainer::runScript(), Engines::NWN::ScriptContainer::runScript(), Engines::NWN2::ScriptContainer::runScript(), Engines::KotOR2::ScriptContainer::runScript(), Engines::Jade::ScriptContainer::runScript(), Engines::KotOR::ScriptContainer::runScript(), Engines::DragonAge2::ScriptContainer::runScript(), Engines::DragonAge::ScriptContainer::runScript(), and Aurora::DLGFile::runScript().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ run() [2/4]

const Variable & Aurora::NWScript::NCSFile::run	(	const ObjectReference	owner = `ObjectReference()`,
		const ObjectReference	triggerer = `ObjectReference()`
	)

Definition at line 354 of file ncsfile.cpp.

References getEmptyState(), and run().

Here is the call graph for this function:

◆ run() [3/4]

const Variable & Aurora::NWScript::NCSFile::run	(	const ScriptState &	state,
		Object *	owner = `0`,
		Object *	triggerer = `0`
	)

Run the current script, from this state to finish.

Definition at line 358 of file ncsfile.cpp.

References run().

Here is the call graph for this function:

◆ run() [4/4]

const Variable & Aurora::NWScript::NCSFile::run	(	const ScriptState &	state,
		const ObjectReference	owner = `ObjectReference()`,
		const ObjectReference	triggerer = `ObjectReference()`
	)

Definition at line 362 of file ncsfile.cpp.

References _name, _script, _stack, Common::UString::c_str(), debugC(), execute(), Aurora::NWScript::NCSStack::getStackPtr(), Aurora::NWScript::ScriptState::globals, Common::kDebugScripts, Aurora::NWScript::ScriptState::locals, Aurora::NWScript::ScriptState::offset, Aurora::NWScript::NCSStack::push(), reset(), and Aurora::NWScript::NCSStack::setBasePtr().

Here is the call graph for this function:

◆ setEnvironment()

void Aurora::NWScript::NCSFile::setEnvironment ( const VariableContainer & env )

Overwrite the environment.

Definition at line 302 of file ncsfile.cpp.

References _env.

Referenced by Engines::Witcher::Functions::executeScript(), Engines::NWN::Functions::executeScript(), and Engines::NWN2::Functions::executeScript().

Here is the caller graph for this function:

◆ setupOpcodes()

void Aurora::NWScript::NCSFile::setupOpcodes ( )

private

Definition at line 194 of file ncsfile.cpp.

References _opcodeListSize, _opcodes, ARRAYSIZE, o_action(), o_add(), o_booland(), o_comp(), o_const(), o_cpdownbp(), o_cpdownsp(), o_cptopbp(), o_cptopsp(), o_decbp(), o_decsp(), o_destruct(), o_div(), o_eq(), o_excor(), o_geq(), o_getref(), o_getrefarray(), o_gt(), o_incbp(), o_incor(), o_incsp(), o_jmp(), o_jnz(), o_jsr(), o_jz(), o_leq(), o_logand(), o_logor(), o_lt(), o_mod(), o_movsp(), o_mul(), o_neg(), o_neq(), o_nop(), o_not(), o_readarray(), o_restorebp(), o_retn(), o_rsadd(), o_savebp(), o_shleft(), o_shright(), o_storestate(), o_storestateall(), o_sub(), o_ushright(), o_writearray(), OPCODE, and OPCODE0.

Referenced by load().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ _env

VariableContainer Aurora::NWScript::NCSFile::_env

private

Definition at line 177 of file ncsfile.h.

Referenced by getEnvironment(), and setEnvironment().

◆ _name

Common::UString Aurora::NWScript::NCSFile::_name

private

Definition at line 167 of file ncsfile.h.

Referenced by execute(), getName(), and run().

◆ _opcodeListSize

size_t Aurora::NWScript::NCSFile::_opcodeListSize

private

Definition at line 189 of file ncsfile.h.

Referenced by executeStep(), and setupOpcodes().

◆ _opcodes

const Opcode* Aurora::NWScript::NCSFile::_opcodes

private

Definition at line 188 of file ncsfile.h.

Referenced by executeStep(), and setupOpcodes().

◆ _owner

ObjectReference Aurora::NWScript::NCSFile::_owner

private

Definition at line 174 of file ncsfile.h.

Referenced by callEngine(), execute(), and o_const().

◆ _return

Variable Aurora::NWScript::NCSFile::_return

private

Definition at line 172 of file ncsfile.h.

Referenced by execute(), and reset().

◆ _returnOffsets

std::stack<uint32> Aurora::NWScript::NCSFile::_returnOffsets

private

Definition at line 179 of file ncsfile.h.

Referenced by executeStep(), o_jsr(), o_retn(), and reset().

◆ _script

Common::ScopedPtr<Common::SeekableReadStream> Aurora::NWScript::NCSFile::_script

private

Definition at line 170 of file ncsfile.h.

Referenced by decompile(), executeStep(), load(), NCSFile(), o_action(), o_const(), o_cpdownbp(), o_cpdownsp(), o_cptopbp(), o_cptopsp(), o_decbp(), o_decsp(), o_destruct(), o_eq(), o_getref(), o_getrefarray(), o_incbp(), o_incsp(), o_jmp(), o_jnz(), o_jsr(), o_jz(), o_movsp(), o_neq(), o_readarray(), o_retn(), o_storestate(), o_writearray(), reset(), and run().

◆ _stack

NCSStack Aurora::NWScript::NCSFile::_stack

private

Definition at line 169 of file ncsfile.h.

Referenced by callEngine(), execute(), executeStep(), o_add(), o_booland(), o_comp(), o_const(), o_cpdownbp(), o_cpdownsp(), o_cptopbp(), o_cptopsp(), o_decbp(), o_decsp(), o_destruct(), o_div(), o_eq(), o_excor(), o_geq(), o_getref(), o_getrefarray(), o_gt(), o_incbp(), o_incor(), o_incsp(), o_jnz(), o_jz(), o_leq(), o_logand(), o_logor(), o_lt(), o_mod(), o_movsp(), o_mul(), o_neg(), o_neq(), o_not(), o_readarray(), o_restorebp(), o_rsadd(), o_savebp(), o_shleft(), o_shright(), o_storestate(), o_sub(), o_ushright(), o_writearray(), reset(), and run().

◆ _storedState

Variable Aurora::NWScript::NCSFile::_storedState

private

Definition at line 181 of file ncsfile.h.

Referenced by callEngine(), o_storestate(), and reset().

◆ _triggerer

ObjectReference Aurora::NWScript::NCSFile::_triggerer

private

Definition at line 175 of file ncsfile.h.

Referenced by callEngine(), and execute().

The documentation for this class was generated from the following files:

src/aurora/nwscript/ncsfile.h
src/aurora/nwscript/ncsfile.cpp

Classes

Public Member Functions

Static Public Member Functions

Private Types

Private Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Member Typedef Documentation

◆ OpcodeProc

Member Enumeration Documentation

◆ InstructionType

Constructor & Destructor Documentation

◆ NCSFile() [1/2]

◆ NCSFile() [2/2]

◆ ~NCSFile()

Member Function Documentation

◆ callEngine()

◆ decompile()

◆ execute()

◆ executeStep()

◆ getEmptyState()

◆ getEnvironment()

◆ getName()

◆ load()

◆ o_action()

◆ o_add()

◆ o_booland()

◆ o_comp()

◆ o_const()

◆ o_cpdownbp()

◆ o_cpdownsp()

◆ o_cptopbp()

◆ o_cptopsp()

◆ o_decbp()

◆ o_decsp()

◆ o_destruct()

◆ o_div()

◆ o_eq()

◆ o_excor()

◆ o_geq()

◆ o_getref()

◆ o_getrefarray()

◆ o_gt()

◆ o_incbp()

◆ o_incor()

◆ o_incsp()

◆ o_jmp()

◆ o_jnz()

◆ o_jsr()

◆ o_jz()

◆ o_leq()

◆ o_logand()

◆ o_logor()

◆ o_lt()

◆ o_mod()

◆ o_movsp()

◆ o_mul()

◆ o_neg()

◆ o_neq()

◆ o_nop()

◆ o_not()

◆ o_readarray()

◆ o_restorebp()

◆ o_retn()

◆ o_rsadd()

◆ o_savebp()

◆ o_shleft()

◆ o_shright()

◆ o_storestate()

◆ o_storestateall()

◆ o_sub()

◆ o_ushright()

◆ o_writearray()

◆ reset()

◆ run() [1/4]

◆ run() [2/4]

◆ run() [3/4]

◆ run() [4/4]

◆ setEnvironment()
