A GFF (generic file format) V3.2/V3.3 file, found in all Aurora games except Sonic Chronicles: The Dark Brotherhood. More...

#include <gff3file.h>

Inheritance diagram for Aurora::GFF3File:

[legend]

Collaboration diagram for Aurora::GFF3File:

[legend]

Classes
struct	Header
	A GFF3 header. More...

Public Member Functions
	GFF3File (Common::SeekableReadStream *gff3, uint32 id=0xFFFFFFFF, bool repairNWNPremium=false)
	Take over this stream and read a GFF3 file out of it. More...

	GFF3File (const Common::UString &gff3, FileType type, uint32 id=0xFFFFFFFF, bool repairNWNPremium=false)
	Request this resource from the ResourceManager and read a GFF3 file out of it. More...

virtual	~GFF3File ()

uint32	getType () const
	Return the GFF3's specific type. More...

const GFF3Struct &	getTopLevel () const
	Returns the top-level struct. More...

Public Member Functions inherited from Aurora::AuroraFile
	AuroraFile ()

void	clear ()

uint32	getID () const
	Return the file's ID. More...

uint32	getVersion () const
	Return the file's version. More...

bool	isUTF16LE () const
	Were the ID and version encoded in little-endian UTF-16 in the file? More...

Private Types
typedef Common::PtrVector< GFF3Struct >	StructArray

typedef std::vector< GFF3List >	ListArray

Private Member Functions
void	load (uint32 id)

void	loadHeader (uint32 id)

void	loadStructs ()

void	loadLists ()

Common::SeekableReadStream &	getStream (uint32 offset) const
	Return the GFF3 stream. More...

Common::SeekableReadStream &	getFieldData () const
	Return the GFF3 stream seeked to the start of the field data. More...

const GFF3Struct &	getStruct (uint32 i) const
	Return a struct within the GFF3. More...

const GFF3List &	getList (uint32 i) const
	Return a list within the GFF3. More...

Private Attributes
Common::ScopedPtr< Common::SeekableReadStream >	_stream

Header	_header
	The GFF3's header. More...

bool	_repairNWNPremium
	Should we try to read GFF3 files found in Neverwinter Nights premium modules? More...

uint32	_offsetCorrection
	The correctional value for offsets to repair Neverwinter Nights premium modules. More...

StructArray	_structs
	Our structs. More...

ListArray	_lists
	Our lists. More...

std::vector< uint32 >	_listOffsetToIndex
	To convert list offsets found in GFF3 to real indices. More...

Friends
class	GFF3Struct

Additional Inherited Members
Static Public Member Functions inherited from Aurora::AuroraFile
static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version, bool &utf16le)
	Read the header out of a stream. More...

static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version)
	Read the ID and version out of a stream. More...

static uint32	readHeaderID (Common::ReadStream &stream)
	Read the ID out of a stream. More...

Protected Member Functions inherited from Aurora::AuroraFile
void	readHeader (Common::ReadStream &stream)

Static Protected Member Functions inherited from Aurora::AuroraFile
static uint32	convertUTF16LE (uint32 x1, uint32 x2)

Protected Attributes inherited from Aurora::AuroraFile
uint32	_id
	The file's ID. More...

uint32	_version
	The file's version. More...

bool	_utf16le
	The file's ID and version are in little-endian UTF-16. More...

Detailed Description

A GFF (generic file format) V3.2/V3.3 file, found in all Aurora games except Sonic Chronicles: The Dark Brotherhood.

Even games that have V4.0/V4.1 GFFs additionally use V3.2/V3.3 files as well.

GFF files store hierarchical data, similar in concept to XML. They are used whenever such data is useful: to, for example, hold area and object descriptions, module and campaign specifications or conversations. They consist of a top-level struct, with a collection of fields of various types, indexed by a human-readable string name. A field can then be another struct (which itself will be a collection of fields) or a list of structs, leading to a recursive, hierarchical structure.

GFF V3.2/V3.3 files come in a multitude of types (ARE, DLG, ...), each with its own 4-byte type ID ('ARE ', 'DLG ', ...). When specified in the GFF3File constructor, the loader will enforce that it matches, and throw an exception should it not. Conversely, an ID of 0xFFFFFFFF means that no such type ID enforcement should be done. In both cases, the type ID read from the file can get access through getType().

The GFF V3.2/V3.3 files found in the encrypted premium module archives of Neverwinter Nights are deliberately broken in various way. When the constructor parameter repairNWNPremium is set to true, GFF3File will detect such broken files and automatically repair them. When this parameter is set to false, no detection will take place, and these broken files will lead the loader to throw an exception.

There is no functional difference between GFF V3.2 and V3.3 files. GFF V3.3 files exclusively appear in The Witcher (and every GFF file there is of version V3.3), simply to denote that the language table used for LocStrings is different. Since xoreos has more flexible handling of language IDs anyway, this doesn't concern us.

See also: GFF4File in gff4file.h for the later V4.0/V4.1 versions of the GFF format.

Definition at line 85 of file gff3file.h.

Member Typedef Documentation

◆ ListArray

typedef std::vector<GFF3List> Aurora::GFF3File::ListArray

private

Definition at line 122 of file gff3file.h.

◆ StructArray

typedef Common::PtrVector<GFF3Struct> Aurora::GFF3File::StructArray

private

Definition at line 121 of file gff3file.h.

Constructor & Destructor Documentation

◆ GFF3File() [1/2]

Aurora::GFF3File::GFF3File	(	Common::SeekableReadStream *	gff3,
		uint32	id = `0xFFFFFFFF`,
		bool	repairNWNPremium = `false`
	)

Take over this stream and read a GFF3 file out of it.

Definition at line 66 of file gff3file.cpp.

References _stream, and load().

Here is the call graph for this function:

◆ GFF3File() [2/2]

Aurora::GFF3File::GFF3File	(	const Common::UString &	gff3,
		FileType	type,
		uint32	id = `0xFFFFFFFF`,
		bool	repairNWNPremium = `false`
	)

Request this resource from the ResourceManager and read a GFF3 file out of it.

Definition at line 74 of file gff3file.cpp.

References _stream, load(), Common::ScopedPtrBase< T, Deallocator >::reset(), ResMan, and TypeMan.

Here is the call graph for this function:

◆ ~GFF3File()

Aurora::GFF3File::~GFF3File ( )

virtual

Definition at line 84 of file gff3file.cpp.

Member Function Documentation

◆ getFieldData()

Common::SeekableReadStream & Aurora::GFF3File::getFieldData ( ) const

private

Return the GFF3 stream seeked to the start of the field data.

Definition at line 281 of file gff3file.cpp.

References _header, Aurora::GFF3File::Header::fieldDataOffset, and getStream().

Referenced by Aurora::GFF3Struct::getData().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getList()

const GFF3List & Aurora::GFF3File::getList ( uint32 i ) const

private

Return a list within the GFF3.

Definition at line 260 of file gff3file.cpp.

References _listOffsetToIndex, and _lists.

Referenced by Aurora::GFF3Struct::getList().

Here is the caller graph for this function:

◆ getStream()

Common::SeekableReadStream & Aurora::GFF3File::getStream ( uint32 offset ) const

private

Return the GFF3 stream.

Definition at line 275 of file gff3file.cpp.

References _stream.

Referenced by getFieldData(), and Aurora::GFF3Struct::load().

Here is the caller graph for this function:

◆ getStruct()

const GFF3Struct & Aurora::GFF3File::getStruct ( uint32 i ) const

private

Return a struct within the GFF3.

Definition at line 253 of file gff3file.cpp.

References _structs.

Referenced by Aurora::GFF3Struct::getStruct(), and getTopLevel().

Here is the caller graph for this function:

◆ getTopLevel()

const GFF3Struct & Aurora::GFF3File::getTopLevel ( ) const

Returns the top-level struct.

Definition at line 91 of file gff3file.cpp.

References getStruct().

Referenced by Engines::NWN::CharGenChoices::applyChoices(), Engines::Witcher::Area::Area(), Engines::NWN2::Area::Area(), Aurora::DLGFile::DLGFile(), Engines::KotOR::SavedGame::fillFromModuleIFO(), Engines::KotOR::SavedGame::fillFromNFO(), Engines::Witcher::Campaign::getDescription(), Engines::NWN2::Module::getDescription(), Engines::Witcher::Module::getDescription(), Engines::Witcher::Campaign::getName(), Engines::NWN2::Module::getName(), Engines::Witcher::Module::getName(), Engines::Witcher::Area::getName(), Engines::KotOR2::Module::getName(), Engines::NWN2::Area::getName(), Engines::NWN::Area::getName(), Engines::KotOR::Module::getName(), Engines::Witcher::Creature::load(), Engines::Jade::Area::load(), Engines::KotOR2::Area::load(), Engines::NWN::Area::load(), Engines::KotOR::Area::load(), Engines::Witcher::Campaign::loadCampaignFile(), and Aurora::NFOFile::NFOFile().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getType()

uint32 Aurora::GFF3File::getType ( ) const

Return the GFF3's specific type.

Definition at line 87 of file gff3file.cpp.

References Aurora::AuroraFile::_id.

Referenced by Aurora::SACFile::SACFile().

Here is the caller graph for this function:

◆ load()

void Aurora::GFF3File::load ( uint32 id )

private

Definition at line 97 of file gff3file.cpp.

References Common::StackException::add(), loadHeader(), loadLists(), and loadStructs().

Referenced by GFF3File().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ loadHeader()

void Aurora::GFF3File::loadHeader ( uint32 id )

private

Definition at line 110 of file gff3file.cpp.

References _header, Aurora::AuroraFile::_id, _offsetCorrection, _repairNWNPremium, _stream, Aurora::AuroraFile::_version, Common::debugTag(), Aurora::GFF3File::Header::fieldDataOffset, Aurora::GFF3File::Header::fieldIndicesOffset, Aurora::GFF3File::Header::fieldOffset, kVersion32, kVersion33, Aurora::GFF3File::Header::labelOffset, Aurora::GFF3File::Header::listIndicesOffset, Aurora::GFF3File::Header::read(), Aurora::AuroraFile::readHeader(), and Aurora::GFF3File::Header::structOffset.

Referenced by load().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ loadLists()

void Aurora::GFF3File::loadLists ( )

private

Definition at line 191 of file gff3file.cpp.

References _header, _listOffsetToIndex, _lists, _stream, _structs, Aurora::GFF3File::Header::listIndicesCount, and Aurora::GFF3File::Header::listIndicesOffset.

Referenced by load().

Here is the caller graph for this function:

◆ loadStructs()

void Aurora::GFF3File::loadStructs ( )

private

Definition at line 183 of file gff3file.cpp.

References _header, _structs, Aurora::GFF3File::Header::structCount, and Aurora::GFF3File::Header::structOffset.

Referenced by load().

Here is the caller graph for this function:

Friends And Related Function Documentation

◆ GFF3Struct

friend class GFF3Struct

friend

Definition at line 160 of file gff3file.h.

Member Data Documentation

◆ _header

Header Aurora::GFF3File::_header

private

The GFF3's header.

Definition at line 127 of file gff3file.h.

Referenced by getFieldData(), loadHeader(), loadLists(), loadStructs(), Aurora::GFF3Struct::readField(), Aurora::GFF3Struct::readFields(), and Aurora::GFF3Struct::readLabel().

◆ _listOffsetToIndex

std::vector<uint32> Aurora::GFF3File::_listOffsetToIndex

private

To convert list offsets found in GFF3 to real indices.

Definition at line 138 of file gff3file.h.

Referenced by getList(), and loadLists().

◆ _lists

ListArray Aurora::GFF3File::_lists

private

Our lists.

Definition at line 135 of file gff3file.h.

Referenced by getList(), and loadLists().

◆ _offsetCorrection

uint32 Aurora::GFF3File::_offsetCorrection

private

The correctional value for offsets to repair Neverwinter Nights premium modules.

Definition at line 132 of file gff3file.h.

Referenced by loadHeader().

◆ _repairNWNPremium

bool Aurora::GFF3File::_repairNWNPremium

private

Should we try to read GFF3 files found in Neverwinter Nights premium modules?

Definition at line 130 of file gff3file.h.

Referenced by loadHeader().

◆ _stream

Common::ScopedPtr<Common::SeekableReadStream> Aurora::GFF3File::_stream

private

Definition at line 125 of file gff3file.h.

Referenced by getStream(), GFF3File(), loadHeader(), and loadLists().

◆ _structs

StructArray Aurora::GFF3File::_structs

private

Our structs.

Definition at line 134 of file gff3file.h.

Referenced by getStruct(), loadLists(), and loadStructs().

The documentation for this class was generated from the following files:

src/aurora/gff3file.h
src/aurora/gff3file.cpp
