Inheritance diagram for Sound::ASFStream:

Collaboration diagram for Sound::ASFStream:

[legend]

Classes
struct	Packet

Public Member Functions
	ASFStream (Common::SeekableReadStream *stream, bool dispose)

	~ASFStream ()

size_t	readBuffer (int16 *buffer, const size_t numSamples)
	Fill the given buffer with up to numSamples samples. More...

bool	endOfData () const
	End of data reached? If this returns true, it means that at this time there is no data available in the stream. More...

int	getChannels () const
	Return the number channels in this stream. More...

int	getRate () const
	Sample rate of the stream. More...

uint64	getLength () const
	Estimate the total number of samples per channel in this stream. More...

uint64	getDuration () const
	Estimate the total duration of the stream in milliseconds. More...

bool	rewind ()
	Rewinds the stream to its start. More...

Public Member Functions inherited from Sound::AudioStream
virtual	~AudioStream ()

virtual bool	endOfStream () const
	End of stream reached? If this returns true, it means that all data in this stream is used up and no additional data will appear in it in the future. More...

Private Member Functions
void	load ()

void	parseStreamHeader ()

void	parseFileHeader ()

Packet *	readPacket ()

PacketizedAudioStream *	createAudioStream ()

void	feedAudioData ()

bool	allDataLoaded () const

Additional Inherited Members
Static Public Attributes inherited from Sound::RewindableAudioStream
static const uint64	kInvalidLength = UINT64_C(0xFFFFFFFFFFFFFFFF)

Static Public Attributes inherited from Sound::AudioStream
static const size_t	kSizeInvalid = SIZE_MAX

Detailed Description

Definition at line 106 of file asf.cpp.

Constructor & Destructor Documentation

◆ ASFStream()

Sound::ASFStream::ASFStream	(	Common::SeekableReadStream *	stream,
		bool	dispose
	)

Definition at line 184 of file asf.cpp.

References _curPacket, _curSequenceNumber, and load().

Here is the call graph for this function:

◆ ~ASFStream()

Sound::ASFStream::~ASFStream ( )

Definition at line 191 of file asf.cpp.

Member Function Documentation

◆ allDataLoaded()

bool Sound::ASFStream::allDataLoaded ( ) const

private

Definition at line 473 of file asf.cpp.

References _curPacket, and _packetCount.

Referenced by endOfData(), and readBuffer().

Here is the caller graph for this function:

◆ createAudioStream()

PacketizedAudioStream * Sound::ASFStream::createAudioStream ( )

private

Definition at line 409 of file asf.cpp.

References _bitRate, _blockAlign, _channels, _compression, _extraData, _sampleRate, Sound::kWaveWMAv2, and Sound::makeWMAStream().

Referenced by parseStreamHeader(), and rewind().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ endOfData()

bool Sound::ASFStream::endOfData ( ) const

virtual

End of data reached? If this returns true, it means that at this time there is no data available in the stream.

However there may be more data in the future. This is used by e.g. a rate converter to decide whether to keep on converting data or stop.

Implements Sound::AudioStream.

Definition at line 477 of file asf.cpp.

References _curAudioStream, and allDataLoaded().

Here is the call graph for this function:

◆ feedAudioData()

void Sound::ASFStream::feedAudioData ( )

private

Definition at line 420 of file asf.cpp.

References _curAudioStream, _curSequenceNumber, _streamID, Sound::ASFStream::Packet::Segment::data, readPacket(), Sound::ASFStream::Packet::Segment::sequenceNumber, and Sound::ASFStream::Packet::Segment::streamID.

Referenced by readBuffer().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getChannels()

int Sound::ASFStream::getChannels ( ) const

inlinevirtual

Return the number channels in this stream.

Implements Sound::AudioStream.

Definition at line 114 of file asf.cpp.

References _channels.

◆ getDuration()

uint64 Sound::ASFStream::getDuration ( ) const

virtual

Estimate the total duration of the stream in milliseconds.

If this value is not calculable, return kInvalidLength.

Reimplemented from Sound::RewindableAudioStream.

Definition at line 301 of file asf.cpp.

References _duration.

◆ getLength()

uint64 Sound::ASFStream::getLength ( ) const

virtual

Estimate the total number of samples per channel in this stream.

If this value is not calculatable, return kInvalidLength.

Reimplemented from Sound::RewindableAudioStream.

Definition at line 297 of file asf.cpp.

References _duration, and getRate().

Here is the call graph for this function:

◆ getRate()

int Sound::ASFStream::getRate ( ) const

inlinevirtual

Sample rate of the stream.

Implements Sound::AudioStream.

Definition at line 115 of file asf.cpp.

References _sampleRate.

Referenced by getLength().

Here is the caller graph for this function:

◆ load()

void Sound::ASFStream::load ( )

private

Definition at line 194 of file asf.cpp.

References _rewindPos, _stream, Common::UString::c_str(), parseFileHeader(), parseStreamHeader(), Sound::s_asfCodecComment, Sound::s_asfComment, Sound::s_asfDataHeader, Sound::s_asfExtendedHeader, Sound::s_asfFileHeader, Sound::s_asfHead1, Sound::s_asfHeader, Sound::s_asfStreamBitRate, Sound::s_asfStreamHeader, Sound::ASFGUID::toString(), and warning().

Referenced by ASFStream().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ parseFileHeader()

void Sound::ASFStream::parseFileHeader ( )

private

Definition at line 241 of file asf.cpp.

References _duration, _maxPacketSize, _minPacketSize, _packetCount, and _stream.

Referenced by load().

Here is the caller graph for this function:

◆ parseStreamHeader()

void Sound::ASFStream::parseStreamHeader ( )

private

Definition at line 264 of file asf.cpp.

References _bitRate, _bitsPerCodedSample, _blockAlign, _channels, _compression, _curAudioStream, _extraData, _sampleRate, _stream, _streamID, createAudioStream(), Common::ScopedPtrBase< T, Deallocator >::reset(), and Sound::s_asfAudioStream.

Referenced by load().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readBuffer()

size_t Sound::ASFStream::readBuffer	(	int16 *	buffer,
		const size_t	numSamples
	)

virtual

Fill the given buffer with up to numSamples samples.

Returns the actual number of samples read, or kSizeInvalid if a critical error occurred (note: you must check if this value is less than what you requested, this can happen when the stream is fully used up).

Data has to be in native endianness, 16 bit per sample, signed. For stereo stream, buffer will be filled with interleaved left and right channel samples, starting with a left sample. Furthermore, the samples in the left and right are summed up. So if you request 4 samples from a stereo stream, you will get a total of two left channel and two right channel samples.

The same holds true for more channels. Channel configurations recognized:

5.1: front left, front right, front center, low frequency rear left, rear right

Implements Sound::AudioStream.

Definition at line 450 of file asf.cpp.

References _curAudioStream, allDataLoaded(), feedAudioData(), and Sound::AudioStream::kSizeInvalid.

Here is the call graph for this function:

◆ readPacket()

ASFStream::Packet * Sound::ASFStream::readPacket ( )

private

Definition at line 321 of file asf.cpp.

References _curPacket, _maxPacketSize, _packetCount, _stream, Sound::ASFStream::Packet::Segment::data, Sound::ASFStream::Packet::duration, Sound::ASFStream::Packet::flags, Sound::ASFStream::Packet::Segment::isKeyframe, Sound::ASFStream::Packet::packetSize, Sound::ASFStream::Packet::segments, Sound::ASFStream::Packet::segmentType, Sound::ASFStream::Packet::sendTime, Sound::ASFStream::Packet::Segment::sequenceNumber, and Sound::ASFStream::Packet::Segment::streamID.

Referenced by feedAudioData().

Here is the caller graph for this function:

◆ rewind()

bool Sound::ASFStream::rewind ( )

virtual

Rewinds the stream to its start.

Returns: true on success, false otherwise.

Implements Sound::RewindableAudioStream.

Definition at line 305 of file asf.cpp.

References _curAudioStream, _curPacket, _curSequenceNumber, _rewindPos, _stream, and createAudioStream().

Here is the call graph for this function:

Member Data Documentation

◆ _bitRate

uint32 Sound::ASFStream::_bitRate

private

Definition at line 169 of file asf.cpp.

Referenced by createAudioStream(), and parseStreamHeader().

◆ _bitsPerCodedSample

uint16 Sound::ASFStream::_bitsPerCodedSample

private

Definition at line 171 of file asf.cpp.

Referenced by parseStreamHeader().

◆ _blockAlign

uint16 Sound::ASFStream::_blockAlign

private

Definition at line 170 of file asf.cpp.

Referenced by createAudioStream(), and parseStreamHeader().

◆ _channels

uint16 Sound::ASFStream::_channels

private

Definition at line 167 of file asf.cpp.

Referenced by createAudioStream(), getChannels(), and parseStreamHeader().

◆ _compression

uint16 Sound::ASFStream::_compression

private

Definition at line 166 of file asf.cpp.

Referenced by createAudioStream(), and parseStreamHeader().

◆ _curAudioStream

Common::ScopedPtr<PacketizedAudioStream> Sound::ASFStream::_curAudioStream

private

Definition at line 156 of file asf.cpp.

Referenced by endOfData(), feedAudioData(), parseStreamHeader(), readBuffer(), and rewind().

◆ _curPacket

uint64 Sound::ASFStream::_curPacket

private

Definition at line 155 of file asf.cpp.

Referenced by allDataLoaded(), ASFStream(), readPacket(), and rewind().

◆ _curSequenceNumber

byte Sound::ASFStream::_curSequenceNumber

private

Definition at line 157 of file asf.cpp.

Referenced by ASFStream(), feedAudioData(), and rewind().

◆ _duration

uint64 Sound::ASFStream::_duration

private

Definition at line 161 of file asf.cpp.

Referenced by getDuration(), getLength(), and parseFileHeader().

◆ _extraData

Common::ScopedPtr<Common::SeekableReadStream> Sound::ASFStream::_extraData

private

Definition at line 172 of file asf.cpp.

Referenced by createAudioStream(), and parseStreamHeader().

◆ _maxPacketSize

uint32 Sound::ASFStream::_maxPacketSize

private

Definition at line 162 of file asf.cpp.

Referenced by parseFileHeader(), and readPacket().

◆ _minPacketSize

uint32 Sound::ASFStream::_minPacketSize

private

Definition at line 162 of file asf.cpp.

Referenced by parseFileHeader().

◆ _packetCount

uint64 Sound::ASFStream::_packetCount

private

Definition at line 160 of file asf.cpp.

Referenced by allDataLoaded(), parseFileHeader(), and readPacket().

◆ _rewindPos

size_t Sound::ASFStream::_rewindPos

private

Definition at line 154 of file asf.cpp.

Referenced by load(), and rewind().

◆ _sampleRate

int Sound::ASFStream::_sampleRate

private

Definition at line 168 of file asf.cpp.

Referenced by createAudioStream(), getRate(), and parseStreamHeader().

◆ _stream

Common::DisposablePtr<Common::SeekableReadStream> Sound::ASFStream::_stream

private

Definition at line 143 of file asf.cpp.

Referenced by load(), parseFileHeader(), parseStreamHeader(), readPacket(), and rewind().

◆ _streamID

uint16 Sound::ASFStream::_streamID

private

Definition at line 165 of file asf.cpp.

Referenced by feedAudioData(), and parseStreamHeader().

The documentation for this class was generated from the following file:

src/sound/decoders/asf.cpp

Private Attributes
Common::DisposablePtr< Common::SeekableReadStream >	_stream

size_t	_rewindPos

uint64	_curPacket

Common::ScopedPtr< PacketizedAudioStream >	_curAudioStream

byte	_curSequenceNumber

uint64	_packetCount

uint64	_duration

uint32	_minPacketSize

uint32	_maxPacketSize

uint16	_streamID

uint16	_compression

uint16	_channels

int	_sampleRate

uint32	_bitRate

uint16	_blockAlign

uint16	_bitsPerCodedSample

Common::ScopedPtr< Common::SeekableReadStream >	_extraData
