Graphics::Aurora::CursorManager Class Reference

The global Aurora cursor manager. More...

#include <cursorman.h>

Inheritance diagram for Graphics::Aurora::CursorManager:

Collaboration diagram for Graphics::Aurora::CursorManager:

Public Member Functions
	CursorManager ()
	~CursorManager ()
void	clear ()
	Remove all managed cursors. More...
bool	add (const Common::UString &name, const Common::UString &group, const Common::UString &state="", int hotspotX=-1, int hotspotY=-1)
	Add a cursor. More...
void	setDefault (const Common::UString &group, const Common::UString &state="")
	Register this cursor as the default cursor. More...
void	set (const Common::UString &group, const Common::UString &state="")
	Set the cursor to a specific group and state. More...
void	setGroup (const Common::UString &group)
	Set the cursor to another group, using the current state name. More...
void	setState (const Common::UString &state)
	Set the cursor to a different state within the current group. More...
void	set ()
	Set the cursor to the registered default. More...
void	reset ()
	Reset the cursor to the system's default. More...
void	hideCursor ()
	Hide the cursor completely. More...
void	showCursor ()
	Unhide the cursor. More...
uint8	getPosition (int &x, int &y) const
	Get the current cursor position. More...
void	setPosition (int x, int y)
	Move the cursor to a specific position. More...
void	toScreenCoordinates (int x, int y, float &sX, float &sY)
	Convert cursor position to screen position. More...
void	fromScreenCoordinates (float sX, float sY, int &x, int &y)
	Convert screen position to cursor position. More...
bool	isVisible () const
	Is a cursor current visible? More...
const Common::UString &	getCurrentGroup () const
	Return the current group. More...
const Common::UString &	getCurrentState () const
	Return the current state. More...

Private Types
typedef std::map< Common::UString, Cursor * >	StateMap
typedef std::map< Common::UString, StateMap >	CursorMap

Private Member Functions
Cursor *	find (Common::UString &group, Common::UString &state, bool def=false) const
void	update ()

Private Attributes
CursorMap	_cursors
Common::UString	_currentGroup
Common::UString	_currentState
Common::UString	_defaultGroup
Common::UString	_defaultState
bool	_hidden
Cursor *	_currentCursor
Common::Mutex	_mutex

Additional Inherited Members
Static Public Member Functions inherited from Common::Singleton< CursorManager >
static CursorManager &	instance ()
static void	destroy ()
Protected Types inherited from Common::Singleton< CursorManager >
typedef CursorManager	SingletonBaseType
Protected Member Functions inherited from Common::Singleton< CursorManager >
	Singleton ()
virtual	~Singleton ()

Detailed Description

The global Aurora cursor manager.

Definition at line 42 of file cursorman.h.

Member Typedef Documentation

CursorMap

typedef std::map<Common::UString, StateMap> Graphics::Aurora::CursorManager::CursorMap

private

Definition at line 102 of file cursorman.h.

StateMap

typedef std::map<Common::UString, Cursor *> Graphics::Aurora::CursorManager::StateMap

private

Definition at line 101 of file cursorman.h.

Constructor & Destructor Documentation

CursorManager()

Graphics::Aurora::CursorManager::CursorManager

(

)

Definition at line 41 of file cursorman.cpp.

~CursorManager()

Graphics::Aurora::CursorManager::~CursorManager

(

)

Definition at line 44 of file cursorman.cpp.

References clear(), and showCursor().

Here is the call graph for this function:

Member Function Documentation

add()

bool Graphics::Aurora::CursorManager::add	(	const Common::UString &	name,
		const Common::UString &	group,
		const Common::UString &	state = "",
		int	hotspotX = -1,
		int	hotspotY = -1
	)

Add a cursor.

Parameters

name	The name of the cursor image resource.
group	The tag to identify the cursor group.
state	The state this cursor has within the cursor group.
hotspotX	The X coordinate of the hotspot.
hotspotY	The Y coordinate of the hotspot.

Returns

true if the cursor could be added to the manager.

Definition at line 79 of file cursorman.cpp.

References _cursors, _mutex, Common::UString::c_str(), Common::exceptionDispatcherWarning(), Common::ScopedPtrBase< T, Deallocator >::get(), and Common::ScopedPtrBase< T, Deallocator >::release().

Here is the call graph for this function:

clear()

void Graphics::Aurora::CursorManager::clear

(

)

Remove all managed cursors.

Definition at line 61 of file cursorman.cpp.

References _currentGroup, _currentState, _cursors, _defaultGroup, _defaultState, _mutex, Common::UString::clear(), and reset().

Referenced by ~CursorManager().

Here is the call graph for this function:

Here is the caller graph for this function:

find()

Cursor * Graphics::Aurora::CursorManager::find ( Common::UString &  group, Common::UString &  state, bool  def = false  ) const

private

Definition at line 199 of file cursorman.cpp.

References _cursors, _defaultGroup, and _defaultState.

Referenced by set().

Here is the caller graph for this function:

fromScreenCoordinates()

void Graphics::Aurora::CursorManager::fromScreenCoordinates	(	float	sX,
		float	sY,
		int &	x,
		int &	y
	)

Convert screen position to cursor position.

Definition at line 175 of file cursorman.cpp.

References WindowMan.

getCurrentGroup()

const Common::UString & Graphics::Aurora::CursorManager::getCurrentGroup

(

)

const

Return the current group.

Definition at line 53 of file cursorman.cpp.

References _currentGroup.

getCurrentState()

const Common::UString & Graphics::Aurora::CursorManager::getCurrentState

(

)

const

Return the current state.

Definition at line 57 of file cursorman.cpp.

References _currentState.

getPosition()

uint8 Graphics::Aurora::CursorManager::getPosition	(	int &	x,
		int &	y
	)		const

Get the current cursor position.

Definition at line 159 of file cursorman.cpp.

hideCursor()

void Graphics::Aurora::CursorManager::hideCursor

(

)

Hide the cursor completely.

Definition at line 183 of file cursorman.cpp.

References _hidden, _mutex, and update().

Here is the call graph for this function:

isVisible()

bool Graphics::Aurora::CursorManager::isVisible

(

)

const

Is a cursor current visible?

Definition at line 49 of file cursorman.cpp.

References _hidden.

reset()

void Graphics::Aurora::CursorManager::reset

(

)

Reset the cursor to the system's default.

Definition at line 119 of file cursorman.cpp.

References _currentCursor, _currentGroup, _currentState, _mutex, Common::UString::clear(), and update().

Referenced by clear().

Here is the call graph for this function:

Here is the caller graph for this function:

set() [1/2]

void Graphics::Aurora::CursorManager::set	(	const Common::UString &	group,
		const Common::UString &	state = ""
	)

Set the cursor to a specific group and state.

Definition at line 148 of file cursorman.cpp.

References _currentCursor, _currentGroup, _currentState, _mutex, find(), and update().

Here is the call graph for this function:

set() [2/2]

void Graphics::Aurora::CursorManager::set

(

)

Set the cursor to the registered default.

Definition at line 130 of file cursorman.cpp.

References _defaultGroup, _defaultState, and _mutex.

setDefault()

void Graphics::Aurora::CursorManager::setDefault	(	const Common::UString &	group,
		const Common::UString &	state = ""
	)

Register this cursor as the default cursor.

Definition at line 112 of file cursorman.cpp.

References _defaultGroup, _defaultState, and _mutex.

setGroup()

void Graphics::Aurora::CursorManager::setGroup

(

const Common::UString &

group

)

Set the cursor to another group, using the current state name.

Definition at line 136 of file cursorman.cpp.

References _defaultState, and _mutex.

setPosition()

void Graphics::Aurora::CursorManager::setPosition	(	int	x,
		int	y
	)

Move the cursor to a specific position.

Definition at line 163 of file cursorman.cpp.

References WindowMan.

setState()

void Graphics::Aurora::CursorManager::setState

(

const Common::UString &

state

)

Set the cursor to a different state within the current group.

Definition at line 142 of file cursorman.cpp.

References _defaultGroup, and _mutex.

showCursor()

void Graphics::Aurora::CursorManager::showCursor

(

)

Unhide the cursor.

Definition at line 191 of file cursorman.cpp.

References _hidden, _mutex, and update().

Referenced by ~CursorManager().

Here is the call graph for this function:

Here is the caller graph for this function:

toScreenCoordinates()

void Graphics::Aurora::CursorManager::toScreenCoordinates	(	int	x,
		int	y,
		float &	sX,
		float &	sY
	)

Convert cursor position to screen position.

Definition at line 167 of file cursorman.cpp.

References WindowMan.

update()

void Graphics::Aurora::CursorManager::update ( )

private

Definition at line 220 of file cursorman.cpp.

References _currentCursor, _hidden, GfxMan, and WindowMan.

Referenced by hideCursor(), reset(), set(), and showCursor().

Here is the caller graph for this function:

Member Data Documentation

_currentCursor

Cursor* Graphics::Aurora::CursorManager::_currentCursor

private

Definition at line 114 of file cursorman.h.

Referenced by reset(), set(), and update().

_currentGroup

Common::UString Graphics::Aurora::CursorManager::_currentGroup

private

Definition at line 106 of file cursorman.h.

Referenced by clear(), getCurrentGroup(), reset(), and set().

_currentState

Common::UString Graphics::Aurora::CursorManager::_currentState

private

Definition at line 107 of file cursorman.h.

Referenced by clear(), getCurrentState(), reset(), and set().

_cursors

CursorMap Graphics::Aurora::CursorManager::_cursors

private

Definition at line 104 of file cursorman.h.

Referenced by add(), clear(), and find().

_defaultGroup

Common::UString Graphics::Aurora::CursorManager::_defaultGroup

private

Definition at line 109 of file cursorman.h.

Referenced by clear(), find(), set(), setDefault(), and setState().

_defaultState

Common::UString Graphics::Aurora::CursorManager::_defaultState

private

Definition at line 110 of file cursorman.h.

Referenced by clear(), find(), set(), setDefault(), and setGroup().

_hidden

bool Graphics::Aurora::CursorManager::_hidden

private

Definition at line 112 of file cursorman.h.

Referenced by hideCursor(), isVisible(), showCursor(), and update().

_mutex

Common::Mutex Graphics::Aurora::CursorManager::_mutex

private

Definition at line 116 of file cursorman.h.

Referenced by add(), clear(), hideCursor(), reset(), set(), setDefault(), setGroup(), setState(), and showCursor().

---

The documentation for this class was generated from the following files:

• src/graphics/aurora/cursorman.h
• src/graphics/aurora/cursorman.cpp
