Aurora::TalkTable_TLK Class Reference

Loading BioWare's TLK talk tables. More...

#include <talktable_tlk.h>

Inheritance diagram for Aurora::TalkTable_TLK:

Collaboration diagram for Aurora::TalkTable_TLK:

Classes
struct	Entry
	A talk resource entry. More...

Public Member Functions
	TalkTable_TLK (Common::SeekableReadStream *tlk, Common::Encoding encoding)
	Take over this stream and read a TLK out of it. More...
	~TalkTable_TLK ()
uint32	getLanguageID () const
	Return the language ID (ungendered) of the talk table. More...
bool	hasEntry (uint32 strRef) const
const Common::UString &	getString (uint32 strRef) const
const Common::UString &	getSoundResRef (uint32 strRef) const
uint32	getSoundID (uint32 strRef) const
Public Member Functions inherited from Aurora::AuroraFile
	AuroraFile ()
void	clear ()
uint32	getID () const
	Return the file's ID. More...
uint32	getVersion () const
	Return the file's version. More...
bool	isUTF16LE () const
	Were the ID and version encoded in little-endian UTF-16 in the file? More...
Public Member Functions inherited from Aurora::TalkTable
virtual	~TalkTable ()

Static Public Member Functions
static uint32	getLanguageID (Common::SeekableReadStream &tlk)
static uint32	getLanguageID (const Common::UString &file)
Static Public Member Functions inherited from Aurora::AuroraFile
static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version, bool &utf16le)
	Read the header out of a stream. More...
static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version)
	Read the ID and version out of a stream. More...
static uint32	readHeaderID (Common::ReadStream &stream)
	Read the ID out of a stream. More...
Static Public Member Functions inherited from Aurora::TalkTable
static TalkTable *	load (Common::SeekableReadStream *tlk, Common::Encoding encoding)
	Take over this stream and read a talk table (of either format) out of it. More...

Private Types
enum	EntryFlags { kFlagTextPresent = (1 << 0), kFlagSoundPresent = (1 << 1), kFlagSoundLengthPresent = (1 << 2) }
	The entries' flags. More...
typedef std::vector< Entry >	Entries

Private Member Functions
void	load ()
void	readEntryTableV3 (uint32 stringsOffset)
void	readEntryTableV4 ()
void	readString (Entry &entry) const

Private Attributes
Common::ScopedPtr< Common::SeekableReadStream >	_tlk
uint32	_languageID
Entries	_entries

Additional Inherited Members
Protected Member Functions inherited from Aurora::AuroraFile
void	readHeader (Common::ReadStream &stream)
Protected Member Functions inherited from Aurora::TalkTable
	TalkTable (Common::Encoding encoding)
Static Protected Member Functions inherited from Aurora::AuroraFile
static uint32	convertUTF16LE (uint32 x1, uint32 x2)
Protected Attributes inherited from Aurora::AuroraFile
uint32	_id
	The file's ID. More...
uint32	_version
	The file's version. More...
bool	_utf16le
	The file's ID and version are in little-endian UTF-16. More...
Protected Attributes inherited from Aurora::TalkTable
Common::Encoding	_encoding

Detailed Description

Loading BioWare's TLK talk tables.

See class TalkTable for a general overview how talk tables work.

Unlike TalkTable_GFF, a TLK talk table is its own simple binary format. It has a numerical, game-local ID of the language it contains, and stores a few more optional data points per string, like a reference to a voice-over file.

There are two versions of TLK files known and supported

• V3.0, used by Neverwinter Nights, Neverwinter Nights 2, Knight of the Old Republic, Knight of the Old Republic II and The Witcher
• V4.0, used by Jade Empire

Definition at line 53 of file talktable_tlk.h.

Member Typedef Documentation

Entries

typedef std::vector<Entry> Aurora::TalkTable_TLK::Entries

private

Definition at line 98 of file talktable_tlk.h.

Member Enumeration Documentation

EntryFlags

enum Aurora::TalkTable_TLK::EntryFlags

private

The entries' flags.

Enumerator
kFlagTextPresent
kFlagSoundPresent
kFlagSoundLengthPresent

Definition at line 75 of file talktable_tlk.h.

Constructor & Destructor Documentation

TalkTable_TLK()

Aurora::TalkTable_TLK::TalkTable_TLK	(	Common::SeekableReadStream *	tlk,
		Common::Encoding	encoding
	)

Take over this stream and read a TLK out of it.

Definition at line 46 of file talktable_tlk.cpp.

References _tlk, and load().

Here is the call graph for this function:

~TalkTable_TLK()

Aurora::TalkTable_TLK::~TalkTable_TLK

(

)

Definition at line 54 of file talktable_tlk.cpp.

Member Function Documentation

getLanguageID() [1/3]

uint32 Aurora::TalkTable_TLK::getLanguageID

(

)

const

Return the language ID (ungendered) of the talk table.

Definition at line 138 of file talktable_tlk.cpp.

References _languageID.

Referenced by Engines::KotOR2::KotOR2Engine::detectLanguages(), Engines::KotOR::KotOREngine::detectLanguages(), Engines::NWN2::NWN2Engine::detectLanguages(), Engines::NWN::NWNEngine::detectLanguages(), getLanguageID(), and Engines::Jade::getTLKLanguage().

Here is the caller graph for this function:

getLanguageID() [2/3]

uint32 Aurora::TalkTable_TLK::getLanguageID ( Common::SeekableReadStream &  tlk )

static

Definition at line 170 of file talktable_tlk.cpp.

References Aurora::kLanguageInvalid, kTLKID, kVersion3, kVersion4, Aurora::AuroraFile::readHeader(), and Common::ReadStream::readUint32LE().

Here is the call graph for this function:

getLanguageID() [3/3]

uint32 Aurora::TalkTable_TLK::getLanguageID ( const Common::UString &  file )

static

Definition at line 182 of file talktable_tlk.cpp.

References getLanguageID(), Aurora::kLanguageInvalid, and Common::ReadFile::open().

Here is the call graph for this function:

getSoundID()

uint32 Aurora::TalkTable_TLK::getSoundID ( uint32  strRef ) const

virtual

Implements Aurora::TalkTable.

Definition at line 163 of file talktable_tlk.cpp.

References _entries, and Aurora::kFieldIDInvalid.

getSoundResRef()

const Common::UString & Aurora::TalkTable_TLK::getSoundResRef ( uint32  strRef ) const

virtual

Implements Aurora::TalkTable.

Definition at line 156 of file talktable_tlk.cpp.

References _entries, and Aurora::kEmptyString.

getString()

const Common::UString & Aurora::TalkTable_TLK::getString ( uint32  strRef ) const

virtual

Implements Aurora::TalkTable.

Definition at line 147 of file talktable_tlk.cpp.

References _entries, Aurora::kEmptyString, and readString().

Here is the call graph for this function:

hasEntry()

bool Aurora::TalkTable_TLK::hasEntry ( uint32  strRef ) const

virtual

Implements Aurora::TalkTable.

Definition at line 142 of file talktable_tlk.cpp.

References _entries.

load()

void Aurora::TalkTable_TLK::load ( )

private

Definition at line 57 of file talktable_tlk.cpp.

References _entries, Aurora::AuroraFile::_id, _languageID, _tlk, Aurora::AuroraFile::_version, Common::StackException::add(), Common::debugTag(), kTLKID, kVersion3, kVersion4, readEntryTableV3(), readEntryTableV4(), and Aurora::AuroraFile::readHeader().

Referenced by TalkTable_TLK().

Here is the call graph for this function:

Here is the caller graph for this function:

readEntryTableV3()

void Aurora::TalkTable_TLK::readEntryTableV3 ( uint32  stringsOffset )

private

Definition at line 94 of file talktable_tlk.cpp.

References _entries, _tlk, Common::kEncodingASCII, Aurora::kFieldIDInvalid, and Common::readStringFixed().

Referenced by load().

Here is the call graph for this function:

Here is the caller graph for this function:

readEntryTableV4()

void Aurora::TalkTable_TLK::readEntryTableV4 ( )

private

Definition at line 107 of file talktable_tlk.cpp.

References _entries, _tlk, and kFlagTextPresent.

Referenced by load().

Here is the caller graph for this function:

readString()

void Aurora::TalkTable_TLK::readString ( Entry &  entry ) const

private

Definition at line 116 of file talktable_tlk.cpp.

References Aurora::TalkTable::_encoding, _tlk, Common::UString::empty(), Aurora::TalkTable_TLK::Entry::flags, Common::kEncodingInvalid, kFlagTextPresent, LangMan, Aurora::TalkTable_TLK::Entry::length, Aurora::TalkTable_TLK::Entry::offset, Common::readString(), and Aurora::TalkTable_TLK::Entry::text.

Referenced by getString().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

_entries

Entries Aurora::TalkTable_TLK::_entries

mutableprivate

Definition at line 105 of file talktable_tlk.h.

Referenced by getSoundID(), getSoundResRef(), getString(), hasEntry(), load(), readEntryTableV3(), and readEntryTableV4().

_languageID

uint32 Aurora::TalkTable_TLK::_languageID

private

Definition at line 103 of file talktable_tlk.h.

Referenced by getLanguageID(), and load().

_tlk

Common::ScopedPtr<Common::SeekableReadStream> Aurora::TalkTable_TLK::_tlk

private

Definition at line 101 of file talktable_tlk.h.

Referenced by load(), readEntryTableV3(), readEntryTableV4(), readString(), and TalkTable_TLK().

---

The documentation for this class was generated from the following files:

• src/aurora/talktable_tlk.h
• src/aurora/talktable_tlk.cpp
