Inheritance diagram for Sound::WwRIFFVorbisStream:

Collaboration diagram for Sound::WwRIFFVorbisStream:

[legend]

Public Member Functions
	WwRIFFVorbisStream (Common::SeekableReadStream inStream, bool disposeStream, Common::SeekableReadStream codebooks, bool disposeCodebooks, bool fullSetup)

size_t	readBuffer (int16 *buffer, const size_t numSamples)
	Fill the given buffer with up to numSamples samples. More...

int	getChannels () const
	Return the number channels in this stream. More...

int	getRate () const
	Sample rate of the stream. More...

bool	endOfData () const
	End of data reached? If this returns true, it means that at this time there is no data available in the stream. More...

bool	rewind ()
	Rewinds the stream to its start. More...

uint64	getLength () const
	Estimate the total number of samples per channel in this stream. More...

Public Member Functions inherited from Sound::RewindableAudioStream
virtual uint64	getDuration () const
	Estimate the total duration of the stream in milliseconds. More...

Public Member Functions inherited from Sound::AudioStream
virtual	~AudioStream ()

virtual bool	endOfStream () const
	End of stream reached? If this returns true, it means that all data in this stream is used up and no additional data will appear in it in the future. More...

Private Member Functions
void	init ()

Common::SeekableReadStream *	generateHeaderIdentification ()

Common::SeekableReadStream *	generateHeaderComment ()

Common::SeekableReadStream *	generateHeaderSetup ()

Common::SeekableReadStream *	createPacket ()

Private Attributes
Common::ScopedPtr< Sound::PacketizedAudioStream >	_vorbis

Common::DisposablePtr< Common::SeekableReadStream >	_inStream

Common::DisposablePtr< Common::SeekableReadStream >	_codebooks

bool	_fullSetup

bool	_headerTriadPresent

bool	_oldPacketHeaders

bool	_noGranule

bool	_modPackets

size_t	_dataOffset

size_t	_dataSize

size_t	_currentOffset

size_t	_setupPacketOffset

size_t	_firstAudioPacketOffset

uint16	_channels

uint32	_sampleRate

uint32	_averageBytesPerSecond

uint64	_sampleCount

uint32	_uid

uint8	_blocksize0Pow

uint8	_blocksize1Pow

uint32	_loopCount

uint32	_loopStart

uint32	_loopEnd

Common::ScopedArray< bool >	_modeBlockFlags

size_t	_modeBits

bool	_end

Additional Inherited Members
Static Public Attributes inherited from Sound::RewindableAudioStream
static const uint64	kInvalidLength = UINT64_C(0xFFFFFFFFFFFFFFFF)

Static Public Attributes inherited from Sound::AudioStream
static const size_t	kSizeInvalid = SIZE_MAX

Detailed Description

Definition at line 313 of file wwriffvorbis.cpp.

Constructor & Destructor Documentation

◆ WwRIFFVorbisStream()

Sound::WwRIFFVorbisStream::WwRIFFVorbisStream	(	Common::SeekableReadStream *	inStream,
		bool	disposeStream,
		Common::SeekableReadStream *	codebooks,
		bool	disposeCodebooks,
		bool	fullSetup
	)

Definition at line 407 of file wwriffvorbis.cpp.

References _headerTriadPresent, _modPackets, _oldPacketHeaders, init(), and rewind().

Here is the call graph for this function:

Member Function Documentation

◆ createPacket()

Common::SeekableReadStream * Sound::WwRIFFVorbisStream::createPacket ( )

private

Definition at line 1002 of file wwriffvorbis.cpp.

References _currentOffset, _dataOffset, _dataSize, _inStream, _noGranule, Sound::Packet::headerSize(), Sound::Packet::nextOffset(), Sound::Packet::offset(), and Sound::Packet::size().

Referenced by readBuffer().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ endOfData()

bool Sound::WwRIFFVorbisStream::endOfData ( ) const

virtual

End of data reached? If this returns true, it means that at this time there is no data available in the stream.

However there may be more data in the future. This is used by e.g. a rate converter to decide whether to keep on converting data or stop.

Implements Sound::AudioStream.

Definition at line 442 of file wwriffvorbis.cpp.

References _end.

◆ generateHeaderComment()

Common::SeekableReadStream * Sound::WwRIFFVorbisStream::generateHeaderComment ( )

private

Definition at line 705 of file wwriffvorbis.cpp.

References Common::BitStreamWriterImpl< valueBits, isLE, isMSB2LSB >::flush(), Common::MemoryWriteStreamDynamic::getData(), Common::BitStreamWriterImpl< valueBits, isLE, isMSB2LSB >::putBits(), Sound::putVorbisHeader(), Common::MemoryWriteStreamDynamic::setDisposable(), and Common::MemoryWriteStreamDynamic::size().

Referenced by rewind().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ generateHeaderIdentification()

Common::SeekableReadStream * Sound::WwRIFFVorbisStream::generateHeaderIdentification ( )

private

Definition at line 678 of file wwriffvorbis.cpp.

References _averageBytesPerSecond, _blocksize0Pow, _blocksize1Pow, _channels, _sampleRate, Common::BitStreamWriterImpl< valueBits, isLE, isMSB2LSB >::flush(), Common::MemoryWriteStreamDynamic::getData(), Common::BitStreamWriterImpl< valueBits, isLE, isMSB2LSB >::putBits(), Sound::putVorbisHeader(), Common::MemoryWriteStreamDynamic::setDisposable(), and Common::MemoryWriteStreamDynamic::size().

Referenced by rewind().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ generateHeaderSetup()

Common::SeekableReadStream * Sound::WwRIFFVorbisStream::generateHeaderSetup ( )

private

Definition at line 722 of file wwriffvorbis.cpp.

References _channels, _codebooks, _dataOffset, _firstAudioPacketOffset, _fullSetup, _inStream, _modeBits, _modeBlockFlags, _noGranule, _setupPacketOffset, Sound::CodebookLibrary::copy(), Common::BitStreamWriterImpl< valueBits, isLE, isMSB2LSB >::flush(), Common::BitStreamImpl< valueBits, isLE, isMSB2LSB >::getBit(), Common::BitStreamImpl< valueBits, isLE, isMSB2LSB >::getBits(), Common::MemoryWriteStreamDynamic::getData(), Sound::Packet::granule(), Common::intLog2(), MAX(), Sound::Packet::nextOffset(), Sound::Packet::offset(), Common::BitStreamImpl< valueBits, isLE, isMSB2LSB >::pos(), Common::BitStreamWriterImpl< valueBits, isLE, isMSB2LSB >::putBit(), Common::BitStreamWriterImpl< valueBits, isLE, isMSB2LSB >::putBits(), Sound::putVorbisHeader(), Sound::CodebookLibrary::rebuild(), Common::ScopedPtrBase< T, Deallocator >::reset(), Common::MemoryWriteStreamDynamic::setDisposable(), Common::MemoryWriteStreamDynamic::size(), and Sound::Packet::size().

Referenced by rewind().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getChannels()

int Sound::WwRIFFVorbisStream::getChannels ( ) const

virtual

Return the number channels in this stream.

Implements Sound::AudioStream.

Definition at line 434 of file wwriffvorbis.cpp.

References _vorbis.

◆ getLength()

uint64 Sound::WwRIFFVorbisStream::getLength ( ) const

virtual

Estimate the total number of samples per channel in this stream.

If this value is not calculatable, return kInvalidLength.

Reimplemented from Sound::RewindableAudioStream.

Definition at line 460 of file wwriffvorbis.cpp.

References _sampleCount.

◆ getRate()

int Sound::WwRIFFVorbisStream::getRate ( ) const

virtual

Sample rate of the stream.

Implements Sound::AudioStream.

Definition at line 438 of file wwriffvorbis.cpp.

References _vorbis.

◆ init()

void Sound::WwRIFFVorbisStream::init ( )

private

Definition at line 487 of file wwriffvorbis.cpp.

References _averageBytesPerSecond, _blocksize0Pow, _blocksize1Pow, _channels, _dataOffset, _dataSize, _firstAudioPacketOffset, _headerTriadPresent, _inStream, _loopCount, _loopEnd, _loopStart, _modPackets, _noGranule, _oldPacketHeaders, _sampleCount, _sampleRate, _setupPacketOffset, _uid, Common::kEncodingASCII, MKTAG, Common::readStringFixed(), and SIZE_MAX.

Referenced by WwRIFFVorbisStream().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readBuffer()

size_t Sound::WwRIFFVorbisStream::readBuffer	(	int16 *	buffer,
		const size_t	numSamples
	)

virtual

Fill the given buffer with up to numSamples samples.

Returns the actual number of samples read, or kSizeInvalid if a critical error occurred (note: you must check if this value is less than what you requested, this can happen when the stream is fully used up).

Data has to be in native endianness, 16 bit per sample, signed. For stereo stream, buffer will be filled with interleaved left and right channel samples, starting with a left sample. Furthermore, the samples in the left and right are summed up. So if you request 4 samples from a stereo stream, you will get a total of two left channel and two right channel samples.

The same holds true for more channels. Channel configurations recognized:
