Common::Huffman Class Reference

Decode a Huffman'd bitstream. More...

#include <huffman.h>

Collaboration diagram for Common::Huffman:

Classes
struct	Symbol

Public Member Functions
	Huffman (uint8 maxLength, size_t codeCount, const uint32 *codes, const uint8 *lengths, const uint32 *symbols=0)
	Construct a Huffman decoder. More...
	Huffman (const HuffmanTable &table)
	~Huffman ()
void	setSymbols (const uint32 *symbols=0)
	Modify the codes' symbols. More...
uint32	getSymbol (BitStream &bits) const
	Return the next symbol in the bitstream. More...

Private Types
typedef std::list< Symbol >	CodeList
typedef std::vector< CodeList >	CodeLists
typedef std::vector< Symbol * >	SymbolList

Private Member Functions
void	init (uint8 maxLength, size_t codeCount, const uint32 *codes, const uint8 *lengths, const uint32 *symbols)

Private Attributes
CodeLists	_codes
	Lists of codes and their symbols, sorted by code length. More...
SymbolList	_symbols
	Sorted list of pointers to the symbols. More...

Detailed Description

Decode a Huffman'd bitstream.

Definition at line 47 of file huffman.h.

Member Typedef Documentation

CodeList

typedef std::list<Symbol> Common::Huffman::CodeList

private

Definition at line 76 of file huffman.h.

CodeLists

typedef std::vector<CodeList> Common::Huffman::CodeLists

private

Definition at line 77 of file huffman.h.

SymbolList

typedef std::vector<Symbol *> Common::Huffman::SymbolList

private

Definition at line 78 of file huffman.h.

Constructor & Destructor Documentation

Huffman() [1/2]

Common::Huffman::Huffman	(	uint8	maxLength,
		size_t	codeCount,
		const uint32 *	codes,
		const uint8 *	lengths,
		const uint32 *	symbols = 0
	)

Construct a Huffman decoder.

Parameters

maxLength	Maximal code length. If 0, it's searched for.
codeCount	Number of codes.
codes	The actual codes.
lengths	Lengths of the individual codes.
symbols	The symbols. If 0, assume they are identical to the code indices.

Definition at line 42 of file huffman.cpp.

References init().

Here is the call graph for this function:

Huffman() [2/2]

Common::Huffman::Huffman

(

const HuffmanTable &

table

)

Definition at line 38 of file huffman.cpp.

References Common::HuffmanTable::codeCount, Common::HuffmanTable::codes, init(), Common::HuffmanTable::lengths, Common::HuffmanTable::maxLength, and Common::HuffmanTable::symbols.

Here is the call graph for this function:

~Huffman()

Common::Huffman::~Huffman

(

)

Definition at line 77 of file huffman.cpp.

Member Function Documentation

getSymbol()

uint32 Common::Huffman::getSymbol

(

BitStream &

bits

)

const

Return the next symbol in the bitstream.

Definition at line 85 of file huffman.cpp.

References _codes, and Common::BitStream::addBit().

Referenced by Video::XMVWMV2Codec::decodeIBlock(), and Sound::WMACodec::decodeRunLevel().

Here is the call graph for this function:

Here is the caller graph for this function:

init()

void Common::Huffman::init ( uint8  maxLength, size_t  codeCount, const uint32 *  codes, const uint8 *  lengths, const uint32 *  symbols  )

private

Definition at line 48 of file huffman.cpp.

References _codes, _symbols, and MAX().

Referenced by Huffman().

Here is the call graph for this function:

Here is the caller graph for this function:

setSymbols()

void Common::Huffman::setSymbols

(

const uint32 *

symbols = 0

)

Modify the codes' symbols.

Definition at line 80 of file huffman.cpp.

References _symbols.

Member Data Documentation

_codes

CodeLists Common::Huffman::_codes

private

Lists of codes and their symbols, sorted by code length.

Definition at line 81 of file huffman.h.

Referenced by getSymbol(), and init().

_symbols

SymbolList Common::Huffman::_symbols

private

Sorted list of pointers to the symbols.

Definition at line 84 of file huffman.h.

Referenced by init(), and setSymbols().

---

The documentation for this class was generated from the following files:

• src/common/huffman.h
• src/common/huffman.cpp
