The debug manager, managing debug channels. More...

#include <debugman.h>

Inheritance diagram for Common::DebugManager:

Collaboration diagram for Common::DebugManager:

[legend]

Classes
struct	Channel
	A debug channel. More...

Public Member Functions
	DebugManager ()

	~DebugManager ()

void	getDebugChannels (std::vector< UString > &names, std::vector< UString > &descriptions) const
	Return the channel names alongside their descriptions. More...

void	setVerbosityLevel (DebugChannel channel, uint32 level)
	Set the verbosity level of this channel (by ID). More...

void	setVerbosityLevel (const UString &channel, uint32 level)
	Set the verbosity level of this channel (by name). More...

uint32	getVerbosityLevel (DebugChannel channel) const
	Return the verbosity level of this channel (by ID). More...

uint32	getVerbosityLevel (const UString &channel) const
	Return the verbosity level of this channel (by name). More...

bool	isEnabled (DebugChannel channel, uint32 level) const
	Is this channel ID enabled for this verbosity level? More...

bool	isEnabled (const UString &channel, uint32 level) const
	Is this channel name enabled for this verbosity level? More...

void	setVerbosityLevelsFromConfig ()
	Sync verbosity levels from the ConfigManager. More...

void	setConfigToVerbosityLevels ()
	Sync verbosity levels to the ConfigManager. More...

void	logDebugGL (DebugChannel channel, uint32 level, DebugGLType type, uint32 id, const char *msg)
	Log (and print) an OpenGL debug message. More...

bool	openLogFile (const UString &file)
	Open a log file where all debug output will be written to. More...

void	closeLogFile ()
	Close the current log file. More...

void	logString (const UString &str)
	Log that string to the current log file. More...

void	logCommandLine (const std::vector< UString > &argv)
	Write the whole command line to the current log file. More...

Static Public Member Functions
static UString	getDefaultLogFile ()
	Return the OS-specific default path of the log file. More...

Static Public Member Functions inherited from Common::Singleton< DebugManager >
static DebugManager &	instance ()

static void	destroy ()

Static Public Attributes
static const uint32	kMaxVerbosityLevel = 9

Private Types
typedef std::map< UString, DebugChannel, UString::iless >	ChannelMap

Private Attributes
Channel	_channels [kDebugChannelCount]
	All debug channels. More...

ChannelMap	_channelMap
	Debug channels indexed by name. More...

WriteFile	_logFile

bool	_logFileStartLine

bool	_changedConfig

Additional Inherited Members
Protected Types inherited from Common::Singleton< DebugManager >
typedef DebugManager	SingletonBaseType

Protected Member Functions inherited from Common::Singleton< DebugManager >
	Singleton ()

virtual	~Singleton ()

Detailed Description

The debug manager, managing debug channels.

A debug channel separates debug messages into groups, so debug output doesn't get swamped unnecessarily.

Each debug channel is associated with a verbosity "level" at which it is currently enabled, and each debug message is sent to a channel with a number specifying its verbosity level. The debug message is then only shown when the debug channel it belongs to is enabled at a verbosity level equal to or higher than the debug message's verbosity level.

The verbosity levels go from 0 (disabled) to 9 (most verbose).

For example:

There are two debug channels, C1 and C2. C1 is enabled at verbosity level 3 and C2 is enabled at verbosity level 0 (i.e. disabled). These three debug messages arrive: 1) Channel C1, level 3 2) Channel C1, level 4 3) Channel C2, level 1

In this scenario, only message 1, the one at channel C1 with a level of 3 is shown. Message 2 is not shown, because with a level of 4 it exceeds the current level of C1, which is 3. Likewise, the level of message 3, 1, exceeds the current level of C2. In fact, with a current level of 0, no messages will be shown for C2 at all, ever.

Definition at line 108 of file debugman.h.

Member Typedef Documentation

◆ ChannelMap

typedef std::map<UString, DebugChannel, UString::iless> Common::DebugManager::ChannelMap

private

Definition at line 181 of file debugman.h.

Constructor & Destructor Documentation

◆ DebugManager()

Common::DebugManager::DebugManager ( )

Definition at line 72 of file debugman.cpp.

References _channelMap, _channels, Common::DebugManager::Channel::description, Common::kDebugChannelAll, Common::kDebugChannelCount, Common::kDebugDescriptions, Common::kDebugGLTypeMAX, Common::kDebugNames, Common::DebugManager::Channel::level, and Common::DebugManager::Channel::name.

◆ ~DebugManager()

Common::DebugManager::~DebugManager ( )

Definition at line 87 of file debugman.cpp.

References closeLogFile().

Here is the call graph for this function:

Member Function Documentation

◆ closeLogFile()

void Common::DebugManager::closeLogFile ( )

Close the current log file.

Definition at line 243 of file debugman.cpp.

References _logFile, and Common::WriteFile::close().

Referenced by openLogFile(), and ~DebugManager().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getDebugChannels()

void Common::DebugManager::getDebugChannels	(	std::vector< UString > &	names,
		std::vector< UString > &	descriptions
	)		const

Return the channel names alongside their descriptions.

Definition at line 91 of file debugman.cpp.

References _channels, Common::DebugManager::Channel::description, Common::kDebugChannelCount, and Common::DebugManager::Channel::name.

◆ getDefaultLogFile()

UString Common::DebugManager::getDefaultLogFile ( )

static

Return the OS-specific default path of the log file.

Definition at line 287 of file debugman.cpp.

References Common::FilePath::getUserDataDirectory().

Here is the call graph for this function:

◆ getVerbosityLevel() [1/2]

uint32 Common::DebugManager::getVerbosityLevel ( DebugChannel channel ) const

Return the verbosity level of this channel (by ID).

Definition at line 128 of file debugman.cpp.

References _channels, Common::kDebugChannelCount, and Common::DebugManager::Channel::level.

Referenced by getVerbosityLevel(), and isEnabled().

Here is the caller graph for this function:

◆ getVerbosityLevel() [2/2]

uint32 Common::DebugManager::getVerbosityLevel ( const UString & channel ) const

Return the verbosity level of this channel (by name).

Definition at line 135 of file debugman.cpp.

References _channelMap, and getVerbosityLevel().

Here is the call graph for this function:

◆ isEnabled() [1/2]

bool Common::DebugManager::isEnabled	(	DebugChannel	channel,
		uint32	level
	)		const

Is this channel ID enabled for this verbosity level?

Definition at line 143 of file debugman.cpp.

References getVerbosityLevel(), and kMaxVerbosityLevel.

Referenced by logDebugGL().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ isEnabled() [2/2]

bool Common::DebugManager::isEnabled	(	const UString &	channel,
		uint32	level
	)		const

Is this channel name enabled for this verbosity level?

Definition at line 147 of file debugman.cpp.

References getVerbosityLevel(), and kMaxVerbosityLevel.

Here is the call graph for this function:

◆ logCommandLine()

void Common::DebugManager::logCommandLine ( const std::vector< UString > & argv )

Write the whole command line to the current log file.

Definition at line 278 of file debugman.cpp.

References logString().

Here is the call graph for this function:

◆ logDebugGL()

void Common::DebugManager::logDebugGL	(	DebugChannel	channel,
		uint32	level,
		DebugGLType	type,
		uint32	id,
		const char *	msg
	)

Log (and print) an OpenGL debug message.

Definition at line 202 of file debugman.cpp.

References _channels, Common::DebugManager::Channel::glTypeIDs, isEnabled(), Common::isOpenGLDebugChannel(), Common::kDebugGLTypeMAX, Common::kDebugGLTypeOther, Common::kDebugGLTypes, Common::kDebugNames, and status().

Here is the call graph for this function:

◆ logString()

void Common::DebugManager::logString ( const UString & str )

Log that string to the current log file.

Definition at line 247 of file debugman.cpp.

References _logFile, _logFileStartLine, Common::UString::empty(), Common::UString::end(), Common::WriteFile::flush(), Common::DateTime::formatDateTimeISO(), Common::WriteFile::isOpen(), Common::DateTime::kUTC, and Common::WriteStream::writeString().

Referenced by logCommandLine(), and openLogFile().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ openLogFile()

bool Common::DebugManager::openLogFile ( const UString & file )

Open a log file where all debug output will be written to.

For ease of debugging and build identification, the xoreos version string will be the first line written to the file.

Definition at line 220 of file debugman.cpp.

References _logFile, _logFileStartLine, Common::FilePath::canonicalize(), closeLogFile(), Common::FilePath::createDirectories(), Common::FilePath::getDirectory(), Version::getProjectNameVersionFull(), logString(), and Common::WriteFile::open().

Here is the call graph for this function:

◆ setConfigToVerbosityLevels()

void Common::DebugManager::setConfigToVerbosityLevels ( )

Sync verbosity levels to the ConfigManager.

This writes the current verbosity levels of all debug channels into the "debug" config option of the ConfigManager.

Definition at line 179 of file debugman.cpp.

References _changedConfig, _channels, Common::composeString(), ConfigMan, Common::UString::empty(), Common::kDebugChannelCount, and Common::DebugManager::Channel::name.

Here is the call graph for this function:

◆ setVerbosityLevel() [1/2]

void Common::DebugManager::setVerbosityLevel	(	DebugChannel	channel,
		uint32	level
	)

Set the verbosity level of this channel (by ID).

Definition at line 101 of file debugman.cpp.

References _changedConfig, _channels, Common::kDebugChannelAll, Common::kDebugChannelCount, Common::kDebugGLTypeMAX, kMaxVerbosityLevel, and Common::DebugManager::Channel::level.

Referenced by setVerbosityLevel(), and setVerbosityLevelsFromConfig().

Here is the caller graph for this function:

◆ setVerbosityLevel() [2/2]

void Common::DebugManager::setVerbosityLevel	(	const UString &	channel,
		uint32	level
	)

Set the verbosity level of this channel (by name).

Definition at line 120 of file debugman.cpp.

References _channelMap, and setVerbosityLevel().

Here is the call graph for this function:

◆ setVerbosityLevelsFromConfig()

void Common::DebugManager::setVerbosityLevelsFromConfig ( )

Sync verbosity levels from the ConfigManager.

This reads the current value of the "debug" config option from the ConfigManager, parses it, and sets the verbosity levels of all debug channels according to this value.

Definition at line 151 of file debugman.cpp.

References _changedConfig, ConfigMan, Common::kDebugChannelAll, Common::parseString(), setVerbosityLevel(), and Common::UString::split().

Here is the call graph for this function:

Member Data Documentation

◆ _changedConfig

bool Common::DebugManager::_changedConfig

private

Definition at line 189 of file debugman.h.

Referenced by setConfigToVerbosityLevels(), setVerbosityLevel(), and setVerbosityLevelsFromConfig().

◆ _channelMap

ChannelMap Common::DebugManager::_channelMap

private

Debug channels indexed by name.

Definition at line 184 of file debugman.h.

Referenced by DebugManager(), getVerbosityLevel(), and setVerbosityLevel().

◆ _channels

Channel Common::DebugManager::_channels[kDebugChannelCount]

private

All debug channels.

Definition at line 183 of file debugman.h.

Referenced by DebugManager(), getDebugChannels(), getVerbosityLevel(), logDebugGL(), setConfigToVerbosityLevels(), and setVerbosityLevel().

◆ _logFile

WriteFile Common::DebugManager::_logFile

private

Definition at line 186 of file debugman.h.

Referenced by closeLogFile(), logString(), and openLogFile().

◆ _logFileStartLine

bool Common::DebugManager::_logFileStartLine

private

Definition at line 187 of file debugman.h.

Referenced by logString(), and openLogFile().

◆ kMaxVerbosityLevel

const uint32 Common::DebugManager::kMaxVerbosityLevel = 9

static

Definition at line 110 of file debugman.h.

Referenced by isEnabled(), and setVerbosityLevel().

The documentation for this class was generated from the following files:

src/common/debugman.h
src/common/debugman.cpp
