Aurora::BZFFile Class Reference

Class to hold resource data information of a BZF file. More...

#include <bzffile.h>

Inheritance diagram for Aurora::BZFFile:

Collaboration diagram for Aurora::BZFFile:

Classes
struct	IResource
	Internal resource information. More...

Public Member Functions
	BZFFile (Common::SeekableReadStream *bzf)
	Take over this stream and read a BZF file out of it. More...
	~BZFFile ()
const ResourceList &	getResources () const
	Return the list of resources. More...
uint32	getResourceSize (uint32 index) const
	Return the size of a resource. More...
Common::SeekableReadStream *	getResource (uint32 index, bool tryNoCopy=false) const
	Return a stream of the resource's contents. More...
void	mergeKEY (const KEYFile &key, uint32 dataFileIndex)
	Merge information from the KEY into the data file. More...
Public Member Functions inherited from Aurora::KEYDataFile
virtual	~KEYDataFile ()
Public Member Functions inherited from Aurora::Archive
	Archive ()
virtual	~Archive ()
virtual Common::HashAlgo	getNameHashAlgo () const
	Return with which algorithm the name is hashed. More...
uint32	findResource (uint64 hash) const
	Return the index of the resource matching the hash, or 0xFFFFFFFF if not found. More...
uint32	findResource (const Common::UString &name, FileType type) const
	Return the index of the resource matching the name and type, or 0xFFFFFFFF if not found. More...
Public Member Functions inherited from Aurora::AuroraFile
	AuroraFile ()
void	clear ()
uint32	getID () const
	Return the file's ID. More...
uint32	getVersion () const
	Return the file's version. More...
bool	isUTF16LE () const
	Were the ID and version encoded in little-endian UTF-16 in the file? More...

Private Types
typedef std::vector< IResource >	IResourceList

Private Member Functions
void	load (Common::SeekableReadStream &bzf)
void	readVarResTable (Common::SeekableReadStream &bzf, uint32 offset)
const IResource &	getIResource (uint32 index) const

Private Attributes
Common::ScopedPtr< Common::SeekableReadStream >	_bzf
ResourceList	_resources
	External list of resource names and types. More...
IResourceList	_iResources
	Internal list of resource offsets and sizes. More...

Additional Inherited Members
Public Types inherited from Aurora::Archive
typedef std::list< Resource >	ResourceList
Static Public Member Functions inherited from Aurora::AuroraFile
static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version, bool &utf16le)
	Read the header out of a stream. More...
static void	readHeader (Common::ReadStream &stream, uint32 &id, uint32 &version)
	Read the ID and version out of a stream. More...
static uint32	readHeaderID (Common::ReadStream &stream)
	Read the ID out of a stream. More...
Protected Member Functions inherited from Aurora::AuroraFile
void	readHeader (Common::ReadStream &stream)
Static Protected Member Functions inherited from Aurora::AuroraFile
static uint32	convertUTF16LE (uint32 x1, uint32 x2)
Protected Attributes inherited from Aurora::AuroraFile
uint32	_id
	The file's ID. More...
uint32	_version
	The file's version. More...
bool	_utf16le
	The file's ID and version are in little-endian UTF-16. More...

Detailed Description

Class to hold resource data information of a BZF file.

A BZF is a compressed variation of a BIF file, found exclusively in the Android and iOS version of Knights of the Old Republic.

See also classes KEYFile in keyfile.h and BIFFile in biffile.h.

Definition at line 55 of file bzffile.h.

Member Typedef Documentation

IResourceList

typedef std::vector<IResource> Aurora::BZFFile::IResourceList

private

Definition at line 91 of file bzffile.h.

Constructor & Destructor Documentation

BZFFile()

Aurora::BZFFile::BZFFile

(

Common::SeekableReadStream *

bzf

)

Take over this stream and read a BZF file out of it.

Definition at line 44 of file bzffile.cpp.

References _bzf, and load().

Here is the call graph for this function:

~BZFFile()

Aurora::BZFFile::~BZFFile

(

)

Definition at line 50 of file bzffile.cpp.

Member Function Documentation

getIResource()

const BZFFile::IResource & Aurora::BZFFile::getIResource ( uint32  index ) const

private

Definition at line 132 of file bzffile.cpp.

References _iResources.

Referenced by getResource(), and getResourceSize().

Here is the caller graph for this function:

getResource()

Common::SeekableReadStream * Aurora::BZFFile::getResource ( uint32  index, bool  tryNoCopy = false  ) const

virtual

Return a stream of the resource's contents.

Implements Aurora::Archive.

Definition at line 143 of file bzffile.cpp.

References _bzf, Common::decompressLZMA1(), getIResource(), Aurora::BZFFile::IResource::offset, Aurora::BZFFile::IResource::packedSize, and Aurora::BZFFile::IResource::size.

Here is the call graph for this function:

getResources()

const Archive::ResourceList & Aurora::BZFFile::getResources ( ) const

virtual

Return the list of resources.

Implements Aurora::Archive.

Definition at line 128 of file bzffile.cpp.

References _resources.

getResourceSize()

uint32 Aurora::BZFFile::getResourceSize ( uint32  index ) const

virtual

Return the size of a resource.

Reimplemented from Aurora::Archive.

Definition at line 139 of file bzffile.cpp.

References getIResource(), and Aurora::BZFFile::IResource::size.

Here is the call graph for this function:

load()

void Aurora::BZFFile::load ( Common::SeekableReadStream &  bzf )

private

Definition at line 53 of file bzffile.cpp.

References Aurora::AuroraFile::_id, _iResources, Aurora::AuroraFile::_version, Common::StackException::add(), Common::debugTag(), kBZFID, kVersion1, Aurora::AuroraFile::readHeader(), Common::ReadStream::readUint32LE(), and readVarResTable().

Referenced by BZFFile().

Here is the call graph for this function:

Here is the caller graph for this function:

mergeKEY()

void Aurora::BZFFile::mergeKEY ( const KEYFile &  key, uint32  dataFileIndex  )

virtual

Merge information from the KEY into the data file.

Without this step, this data file archive does not contain any resource names at all.

Parameters

key	A KEYFile with information about this data file.
dataFileIndex	The index this data file has within the KEY file.

Implements Aurora::KEYDataFile.

Definition at line 101 of file bzffile.cpp.

References _iResources, _resources, Aurora::KEYFile::getResources(), Aurora::Archive::Resource::name, and warning().

Here is the call graph for this function:

readVarResTable()

void Aurora::BZFFile::readVarResTable ( Common::SeekableReadStream &  bzf, uint32  offset  )

private

Definition at line 83 of file bzffile.cpp.

References _iResources, Common::ReadStream::readUint32LE(), Common::SeekableReadStream::seek(), Common::SeekableReadStream::size(), and Common::SeekableReadStream::skip().

Referenced by load().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

_bzf

Common::ScopedPtr<Common::SeekableReadStream> Aurora::BZFFile::_bzf

private

Definition at line 93 of file bzffile.h.

Referenced by BZFFile(), and getResource().

_iResources

IResourceList Aurora::BZFFile::_iResources

private

Internal list of resource offsets and sizes.

Definition at line 99 of file bzffile.h.

Referenced by getIResource(), load(), mergeKEY(), and readVarResTable().

_resources

ResourceList Aurora::BZFFile::_resources

private

External list of resource names and types.

Definition at line 96 of file bzffile.h.

Referenced by getResources(), and mergeKEY().

---

The documentation for this class was generated from the following files:

• src/aurora/bzffile.h
• src/aurora/bzffile.cpp
