Inheritance diagram for Sound::PacketizedVorbisStream:

Collaboration diagram for Sound::PacketizedVorbisStream:

[legend]

Public Member Functions
	PacketizedVorbisStream ()

	~PacketizedVorbisStream ()

bool	parseExtraData (Common::SeekableReadStream &stream)

bool	parseExtraData (Common::SeekableReadStream &packet1, Common::SeekableReadStream &packet2, Common::SeekableReadStream &packet3)

int	getChannels () const
	Return the number channels in this stream. More...

int	getRate () const
	Sample rate of the stream. More...

size_t	readBuffer (int16 *buffer, const size_t numSamples)
	Fill the given buffer with up to numSamples samples. More...

bool	endOfData () const
	End of data reached? If this returns true, it means that at this time there is no data available in the stream. More...

bool	endOfStream () const
	End of stream reached? If this returns true, it means that all data in this stream is used up and no additional data will appear in it in the future. More...

void	queuePacket (Common::SeekableReadStream *packet)
	Queue the next packet to be decoded. More...

void	finish ()
	Mark this stream as finished. More...

bool	isFinished () const
	Is the stream marked as finished? More...

Public Member Functions inherited from Sound::PacketizedAudioStream
virtual	~PacketizedAudioStream ()

Public Member Functions inherited from Sound::AudioStream
virtual	~AudioStream ()

Private Attributes
vorbis_info	_vorbisInfo

vorbis_dsp_state	_dspState

vorbis_block	_block

vorbis_comment	_comment

ogg_packet	_packet

bool	_init

Common::Mutex	_mutex

std::queue< Common::SeekableReadStream * >	_queue

bool	_finished

bool	_hasData

Additional Inherited Members
Static Public Attributes inherited from Sound::AudioStream
static const size_t	kSizeInvalid = SIZE_MAX

Detailed Description

Definition at line 257 of file vorbis.cpp.

Constructor & Destructor Documentation

◆ PacketizedVorbisStream()

Sound::PacketizedVorbisStream::PacketizedVorbisStream ( )

Definition at line 292 of file vorbis.cpp.

References _comment, _finished, _hasData, _init, _packet, and _vorbisInfo.

◆ ~PacketizedVorbisStream()

Sound::PacketizedVorbisStream::~PacketizedVorbisStream ( )

Definition at line 301 of file vorbis.cpp.

References _block, _comment, _dspState, _init, _queue, and _vorbisInfo.

Member Function Documentation

◆ endOfData()

bool Sound::PacketizedVorbisStream::endOfData ( ) const

virtual

End of data reached? If this returns true, it means that at this time there is no data available in the stream.

However there may be more data in the future. This is used by e.g. a rate converter to decide whether to keep on converting data or stop.

Implements Sound::AudioStream.

Definition at line 490 of file vorbis.cpp.

References _hasData, _mutex, and _queue.

Referenced by endOfStream().

Here is the caller graph for this function:

◆ endOfStream()

bool Sound::PacketizedVorbisStream::endOfStream ( ) const

virtual

End of stream reached? If this returns true, it means that all data in this stream is used up and no additional data will appear in it in the future.

This is used by the mixer to decide whether a given stream shall be removed from the list of active streams (and thus be destroyed). By default this maps to endOfData()

Reimplemented from Sound::AudioStream.

Definition at line 495 of file vorbis.cpp.

References _finished, _mutex, and endOfData().

Here is the call graph for this function:

◆ finish()

void Sound::PacketizedVorbisStream::finish ( )

virtual

Mark this stream as finished.

That is, signal that no further data will be queued to it. Only after this has been done can this stream ever 'end'.

Implements Sound::PacketizedAudioStream.

Definition at line 506 of file vorbis.cpp.

References _finished, and _mutex.

◆ getChannels()

int Sound::PacketizedVorbisStream::getChannels ( ) const

inlinevirtual

Return the number channels in this stream.

Implements Sound::AudioStream.

Definition at line 266 of file vorbis.cpp.

References _vorbisInfo.

Referenced by readBuffer().

Here is the caller graph for this function:

◆ getRate()

int Sound::PacketizedVorbisStream::getRate ( ) const

inlinevirtual

Sample rate of the stream.

Implements Sound::AudioStream.

Definition at line 267 of file vorbis.cpp.

References _vorbisInfo.

◆ isFinished()

bool Sound::PacketizedVorbisStream::isFinished ( ) const

virtual

Is the stream marked as finished?

Implements Sound::PacketizedAudioStream.

Definition at line 511 of file vorbis.cpp.

References _finished, and _mutex.

◆ parseExtraData() [1/2]

bool Sound::PacketizedVorbisStream::parseExtraData ( Common::SeekableReadStream & stream )

Definition at line 317 of file vorbis.cpp.

References _block, _comment, _dspState, _init, _packet, _vorbisInfo, Common::ScopedPtrBase< T, Deallocator >::get(), Common::SeekableReadStream::pos(), Common::ReadStream::read(), Common::ReadStream::readByte(), Common::ReadStream::readUint16BE(), Common::ScopedPtrBase< T, Deallocator >::reset(), Common::SeekableReadStream::seek(), Common::SeekableReadStream::size(), and warning().

Here is the call graph for this function:

◆ parseExtraData() [2/2]

bool Sound::PacketizedVorbisStream::parseExtraData	(	Common::SeekableReadStream &	packet1,
		Common::SeekableReadStream &	packet2,
		Common::SeekableReadStream &	packet3
	)

Definition at line 394 of file vorbis.cpp.

References _block, _comment, _dspState, _init, _packet, _vorbisInfo, Common::ScopedPtrBase< T, Deallocator >::get(), READ_WHOLE_STREAM, and warning().

Here is the call graph for this function:

◆ queuePacket()

void Sound::PacketizedVorbisStream::queuePacket ( Common::SeekableReadStream * data )

virtual

Queue the next packet to be decoded.

Implements Sound::PacketizedAudioStream.

Definition at line 500 of file vorbis.cpp.

References _finished, _mutex, and _queue.

◆ readBuffer()

size_t Sound::PacketizedVorbisStream::readBuffer	(	int16 *	buffer,
		const size_t	numSamples
	)

virtual

Fill the given buffer with up to numSamples samples.

Returns the actual number of samples read, or kSizeInvalid if a critical error occurred (note: you must check if this value is less than what you requested, this can happen when the stream is fully used up).

Data has to be in native endianness, 16 bit per sample, signed. For stereo stream, buffer will be filled with interleaved left and right channel samples, starting with a left sample. Furthermore, the samples in the left and right are summed up. So if you request 4 samples from a stereo stream, you will get a total of two left channel and two right channel samples.

The same holds true for more channels. Channel configurations recognized:
